- Page 1 Tre Modular - Replicant VCF DIY Assembly Guide (High) Thank you for choosing Tre Modular. In this guide, we will walk you through the process of assembling your very own Tre Modular - Replicant VCF module.
-
Page 2: Before You Begin
Always adhere to proper soldering techniques, work in a well-ventilated space, and handle electronic components with care to ensure the longevity and optimal performance of your Replicant VCF. Ensure you have all the necessary components listed in the Bill of Materials. - Page 3 Legend: Front:...
- Page 4 Back:...
-
Page 5: Assembly Guide
Assembly Guide: Step 1: Identify and Sort Components Organize the components into groups based on their types: resistors, capacitors, diodes, potentiometers, connectors, and jack sockets. Step 2: Diodes (Front) Insert and solder 1N4148 diode according to the legend. Ensure correct orientation, referring to the diode's polarity. Step 3: IC sockets Place and solder IC sockets onto the PCB. - Page 6 Step 8: Trimpot Solder the Trimpot into its designated spot. Start by soldering one pin and reflow the solder if it is not aligned. If everything is aligned, proceed to soldering the rest of the pins. Step 9: Capacitors (Back) Solder capacitors onto the designated positions on the PCB according to legend.
-
Page 7: Additional Information
Connect filters low pass output and check if everything works properly. Insert the module into an available slot in your rack and secure it in place. Enjoy! Additional Information: For any additional questions or support, please contact Tre Modular at support@tremodular.com Happy patching!
