- Page 1 2 4 / 0 3 - 6 1 8 1 0 1 0 _ 0 1 T r a n s l a t i o n o f O r i g i n a l i n s t r u c t i o n s User manual ELECTRONIC CONTROLLER w w w .
- Page 2 All specifications are subject to change without prior notice. Although every effort has been made to ensure accuracy, Aermec shall not be held liable for any errors or...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Key functions 11 CO2 air quality setting .....................4 ................7 Meaning of selectable icons 12 VOC air quality setting .............5 ................7 Meaning of non-selectable icons 13 "Night" function setting ...........5 ..............7 Language setting 14 Setting of fan speed with control CMF – CCO2 – ..................6 CVOC –... -
Page 4: Key Functions
KEY FUNCTIONS Button Symbol Function • Scrolls up the menu icons • Changing of parameter and set values (in Edit Mode) • Confirm • Enters the menu (selected icon) • Enters Edit Mode • Exits Edit Mode applying the changes Moves cursor to the right (in Edit Mode) •... -
Page 5: Meaning Of Selectable Icons
MEANING OF SELECTABLE ICONS Non-selected icon Selected icon On/Off "Comfort Economy" function Hot/Cold/Auto Alarm Presence Set T °C Set UR % "Night" function MEANING OF NON-SELECTABLE ICONS Mode and status operation Freecooling/Freeheating Adjustment temperature Adjustment humidity Date Block keyboard Time... -
Page 6: Language Setting
LANGUAGE SETTING UNIT ON/OFF With prolonged pressure (3 sec) on key the following menu appears: To turn on the unit press To turn off the unit select the "On/Off" icon using keys and confirm with is present it means DI1 is open. "COMFORT ECONOMY"... -
Page 7: Rh % Setting
10 RH % SETTING Using keys select icon and confirm with and the following menu appears: Using keys select icon and confirm with and the follow- ing menu appears: Using keys select the set to be set (hot humidity in comfort, hot humidity in economy, cold humidity in comfort, cold humidity in economy) and confirm with This operation accesses Edit Mode. -
Page 8: Fan Flow Rate With Cpoc Control Setting
15 FAN FLOW RATE WITH CPOC CONTROL Using keys select the pressure set (auto flow, auto eco flow, auto SETTING return, auto eco return) and confirm with Using keys select icon and confirm with With prolonged pressure (3 sec) on key the following menu appears: Using keys select the flow rate set (auto flow, auto eco flow, auto... -
Page 9: Alarm Presence
17 ALARM PRESENCE With LED (Red) (A): — Permanent: alarm present and not resettable — Flashing: alarm present and resettable Using keys select icon and confirm with to display alarm. If resettable alarms are present, keep pressed to restart the unit. Feature present with Unit On and Off. -
Page 10: Alarm History
19 ALARM HISTORY With prolonged pressure (3 sec) on key the following menu appears: Using keys select icon and confirm with and the following menu appears: Using keys select "log" and confirm with Using keys scroll the alarms. With prolonged pressure on key you will return to previous menu. - Page 11 Daily program Save without exiting Save Daily events On/Off Long period (holidays) events On/Off Using keys select the setting to be modified and confirm with This operation accesses Edit Mode. The cursor indicates the label to be modified. Using keys , move the cursor on the value to be changed.
- Page 12 SCARICA L’ULTIMA VERSIONE: DOWNLOAD THE LATEST VERSION: TÉLÉCHARGER LA DERNIÈRE VERSION: http://www.aermec.com/qrcode.asp?q=5740 http://www.aermec.com/qrcode.asp?q=18778 http://www.aermec.com/qrcode.asp?q=5739 A e r m e c S . p . A . V i a R o m a , 9 9 6 - 3 7 0 4 0 B e v i l a c q u a ( V R ) - I t a l i a T e l .
