TABLE OF CONTENTS 1. User Notice .....................p. 4 2. Wired Controller WRCB ..............p. 5 Symbols on LCD ..................p. 5 3. Buttons .....................p. 7 Buttons on the Wired Controller ............p. 7 Function of the Buttons ...............p. 7 4. Operation Instructions ..............p. 8 ON/OFF ......................p. 8 Mode Setting ...................p. 8 Temperature Setting ................p. 8 Fan Setting ....................p. 9... -
Page 4: User Notice
USER NOTICE — Never install the wired controller in the moist circumstance or expose it directly under the sunlight. — Never beat, throw, and frequently disassemble the wired controller and the wireless remote controller. — Never operate the wired controller and the wireless remote controller with wet hands. —... -
Page 5: Wired Controller Wrcb
WIRED CONTROLLER WRCB 2.1 SYMBOLS ON LCD 2.1.1 Outside View of the Wired Controller Fig.1: Outside View of the Wired Controller... - Page 6 2.1.2 LCD of the Wired Controller Fig.2: LCD of the Wired Controller Display Function Indica che è attiva la modalità automatica (in modalità automatica, l’unità interna selezionerà la sua modalità di Automatic funzionamento al variare della temperatura ambiente) Cooling Cooling mode De-Humidification Dry mode Ventilation...
-
Page 7: Buttons
BUTTONS 3.1 BUTTONS ON THE WIRED CONTROLLER Fig. 3: Buttons on the Wired Controller 3.2 FUNCTION OF THE BUTTONS N° Name Function 1. Function selection and cancellation. SWING/ENTER 2. Setting of the up and down swing function. 1. Running temperature setting of the indoor unit, range:16~30°C(61~86°F). 2. -
Page 8: Operation Instructions
OPERATION INSTRUCTIONS 4.1 ON/OFF Press ON/OFF to turn on the unit and turn it off by another press. Note: The state shown in Fig.4 indicates the “OFF” state of the unit after power off. The state shown in Fig.5 indicates the “ON” state of the unit after power on. Fig. -
Page 9: Fan Setting
4.4 FAN SETTING Under the “ON” State of the unit, press Fan and then fan speed of the indoor unit will change circularly as shown in Fig.7. Auto (Low) (Medium Low) (Medium) (Medium-High) (High) Fig. 7 4.5 TIMER SETTING Under the “ON”/”OFF” state of the unit, press Timer to set timer off/on. Timer on setting: press Timer, and then LCD will display “xx.x hour”, with “hour”... -
Page 10: Up & Down Swing Setting
4.6 UP & DOWN SWING SETTING There are two ways for up and down swing mode: simple swing and fixed swing. Under off status, press “SWING/ENTER” button and “ ” button simultaneously for 5 seconds, then switch for simple swing and fixed swing is done. When it is set to be simple swing, under on status, press “SWING/ENTER”... -
Page 11: Sleep Setting
4.8 SLEEP SETTING Sleep on: Press FUNCTION under on state of the unit till the unit enters the Sleep setting interface. Press SWING/ENTER to confirm the setting. Sleep off: When the Sleep function is activated, press FUNCTION to enter the Sleep setting interface. After that, press SWING/ENTER to can this function. Sleep setting is shown as Fig.10. -
Page 12: Turbo Setting
4.9 TURBO SETTING Turbo function: The unit at the high fan speed can realize quick cooling or heating so that the room temperature can quickly approach the setting value. In the Cooling or Heating mode, press FUNCTION till the unit enters the Turbo setting interface and then press SWING/ENTER to confirm the setting. When the Turbo function is activated, press FUNCTION to enter the Turbo setting interface and then press SWING/ENTER to cancel this function. -
Page 13: Energy Saving Function Setting
4.10 ENERGY SAVING FUNCTION SETTING Turn on energy saving function: 1. Energy Saving Setting for Cooling When the unit runs under the COOL or DRY mode, press FUNCTION button to select "SAVE" function option, with "SAVE" flashing, and then press to adjust the lower limit, after that, press the SWING/ENTER button to activate this function. -
Page 14: X-Fan Setting
4.11 X-FAN SETTING X-FAN function: After the unit is turned off, the water in evaporator of indoor unit will be automatically evaporated to avoid mildew. In the Cooling or Dry mode, press FUNCTION till the unit enters the X-fan setting interface (X-FAN) and then press SWING/ENTER to active this function. When the X-FAN function is activated, press FUNCTION to the X-fan setting interface and then press SWING/ENTER to cancel this function. -
Page 15: Quiet Function Setting
4.12 QUIET FUNCTION SETTING This function is available only for MPG_C, MPG_CS and MPG_DH. Turn on quiet function: Under unit on status, press FUNCTION button on the panel to select “Quiet” function option. When “Quiet” or “Auto quiet” flashes, it enters quiet function setting mode. Press button to switch between “Quiet”... -
Page 16: Absent Setting
4.13 ABSENT SETTING Absent on: Press FUNCTION under on state of the unit till the unit enters the Absent setting interface. Press SWING/ENTER to confirm the setting. Absent off: When the Absent function is activated, press FUNCTION to enter the Absent setting interface. After that, press SWING/ENTER to cancel this function. Note: 1. -
Page 17: I-Demand Setting
4.14 I-DEMAND SETTING I-Demand function: under this function the indoor air setting temperature in cooling mode is fixed at 27°C. I-Demand on: Press FUNCTION under on state of the unit till the unit enters the I-Demand setting interface. Press SWING/ENTER to confirm the setting. I-Demand off: When the I-Demand function is activated, press FUNCTION to enter the I-Demand setting interface. -
Page 18: Wifi Function Setting
4.15 WIFI FUNCTION SETTING It is possible to connect remotely to the system using this function and the EWPE Smart App for iOS and Android devices (available free on Apple Store and Google Play). EWPE Smart App can only set some common functions of WiFi wired controller: ON/OFF, mode, set temperature, FAN speed, etc. When using the EWPE Smart App for the first time, please reset the WiFi function of wired controller (reset WiFi to ex-factory setting): Under off status, press “FUNCTION”... -
Page 19: Installation And Dismantlement
INSTALLATION AND DISMANTLEMENT 5.1 CONNECTION OF THE SIGNAL LINE OF THE WIRED CONTROLLER — Open the cover of the electric control box of the indoor unit. — Let the single line of the wired controller through the soleplate of wired controller. —... - Page 20 Fig. 21: Schematic diagram after the connection wire and the patch cord have been connected: connect the terminal 2 of connection wire and the terminal 4 of patch cord WRCB Control Panel can be connected to the CC2 Accessor. WRCB...
-
Page 21: Dismantlement Of The Wired Controller
Fig. 23 Fig. 23 shows schematic diagram of DIP switch. There is a 2-bit DIP switch on the main board of wired controller WRCB. As for the last #n wired controller in the control system, the 1-bit and the 2-bit of the DIP switch should be manually pulled to position “on” and position “off” respectively. The DIP switches of other wired controllers should be kept at the initial ex-factory status (1-bit and 2-bit are set at position “off”. -
Page 22: Set The Indoor Unit Address (Cc2)
SET THE INDOOR UNIT ADDRESS (CC2) It is necessary to set the value of the serial address to the unit as follows: — Press and hold the FUNCTION and MODE buttons simultaneously for 5 seconds; — With keys select the value of the serial address to be given to the unit, in this case from 1 to 36; —... -
Page 23: Errors Display
ERRORS DISPLAY If there is an error occurring during the operation of the system, the error code will be displayed on the LCD, as show in Fig. 24. If multi errors occur at the same time, their codes will be displayed circularly. Note: In event of any error, please turn off the unit and contact the professionally skilled personnel. - Page 24 A e r m e c S . p . A . V i a R o m a , 9 9 6 - 3 7 0 4 0 B e v i l a c q u a ( V R ) - I t a l y P h o n e + 3 9 0 4 4 2 6 3 3 1 1 1 - F a x + 3 9 0 4 4 2 9 3 5 7 7 s a l e s @ a e r m e c .
