USER MANUAL
600 // SIDE OPENING ELECTRIC OVEN
TODS609B-R/L
IMPORTANT // Please ensure that you read through this user manual prior to installation and use.
This manual contains important information to ensure optimal performance and keep you safe.
Please retain your proof of purchase, as this will be required in the event that you require warranty
service. Remember to retain this manual for future reference.
tisira | www.tisira.com
pg 1
www.tisira.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tisira TODS609B-R
Summary of Contents for Tisira TODS609B-R
- Page 1 This manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be required in the event that you require warranty service. Remember to retain this manual for future reference. tisira | www.tisira.com pg 1 www.tisira.com...
-
Page 2: Table Of Contents
CONTENTS Warning & Safety Information Product Specifications Product Overview 6 - 7 Electrical Connection Installation 9 - 10 Operating Instructions 11 - 12 Maintenance 13 - 16 Proof of Purchase Contact Details www.tisira.com | tisira pg 2... -
Page 3: Warning & Safety Information
The appliance must be electrically damage your oven’s enamel coating isolated before any maintenance is and void warranty. performed, including changing the light globe. tisira | www.tisira.com pg 3... - Page 4 This is normal, wait to use the oven until oven. the smoke has stopped eminating from the oven. This only occurs the first time the appliance is heating up and won’t reocccur. www.tisira.com | tisira pg 4...
-
Page 5: Product Specifications
220-240V 50Hz Oven Light 15 Watts Thermostat 50-250 °C Total Power 2700 - 3220 Watts Bottom Heating Element 1200 Watts Top Heating Element 1000 Watts Full Grill Heating Element 1900 Watts Rear Heating Element 2100 Watts tisira | www.tisira.com pg 5... -
Page 6: Product Overview
PRODUCT OVERVIEW TODS609B-R/L Included: • 2 sets of telescopic rails • 1 wire rack • 1 baking tray with wire insert www.tisira.com | tisira pg 6... - Page 7 Clock - To set and check the time. (used by the Cooking Timer to determine when oven shuts off.) Cooking Alarm - Set countdown duration when oven is to shut off. Cooking Timer - Set clock when oven is to shut off. tisira | www.tisira.com pg 7...
-
Page 8: Electrical Connection
L. Mains the service agent or similarly qualified connection can also be made by fitting person in order to avoid a hazard. a double pole switch with a minimum gap between the contacts of 3mm, www.tisira.com | tisira pg 8... -
Page 9: Installation
INSTALLATION Fitting Dimensions: Width: 560mm ±1.5 Height: 589mm ±2.5 *all measurements in mm tisira | www.tisira.com pg 9... - Page 10 It is essential to also without the use of a tool. follow the installation instruction for the To ensure that the oven works as hob. intended it is important to install the www.tisira.com | tisira pg 10...
-
Page 11: Operating Instructions
Bottom heat the airflow created. Fan assisted Top, bottom element and fan operate creating a more efficient Top + Bottom and even heat transfer compared to “top + bottom heating” only. heat tisira | www.tisira.com pg 11... - Page 12 5. The oven will automatically turn on, turn off and sound an alarm at completion. 6. Ensure oven dials are turned off manually. NOTE // The clock can only be changed when no timer modes are active. www.tisira.com | tisira pg 12...
-
Page 13: Maintenance
• Wash all accessories in hot soapy water, of the glass. wipe dry with a paper or cloth towel. • If you use your oven for an extended period of time, condensation may form. • Dry using a soft cloth. tisira | www.tisira.com pg 13... -
Page 14: Replacing Oven Lamp
2. Unscrew the glass cover attached to the lamp holder. 3. Remove the lamp, and replace. 4. Screw on glass cover and plug in oven. NOTE // Use protective gloves to handle lamp, and wait for oven to be completely cooled down. www.tisira.com | tisira pg 14... -
Page 15: Switching Door Orientation
Open door to correct angle, as shown. Unscrew screw 1, then push downward. Pull door out from fixed support. Remove door. Door has been removed from door fulcrum. *to be completed by liscensed service technician, in accordance with instructions. tisira | www.tisira.com pg 15... - Page 16 Screw in screw 1, unscrew screw 2. Rotate the door, screw 1 should now be on the bottom. Place spindle into fulcrum at the base of the oven. Screw in screw 2. Door has now been reversed. www.tisira.com | tisira pg 16...
-
Page 17: Proof Of Purchase
PROOF OF PURCHASE tisira | www.tisira.com pg 17... -
Page 18: Contact Details
Dandenong South, VIC 3175 Australia P // 1300 762 219 E // arisit@arisit.com Tisira is committed to ongoing research and development. Every effort has been made to ensure all information in this user manual is correct at time of going to print.
