INSTRUCTION MANUAL
Colour Television
Please read this Instruction book before using your television.
We wish you many hours of pleasure from your new television.
TV Specifications
Common specification
Power source
AC 220~240V 50Hz
Television system
System I
Colour system
PAL/NTSC4.43
(PAL/NTSC4.43/NTSC3.58 in AV mode)
Channel coverage
UHF: 21-69.
Aerial input impedance
75 ohm
AV terminal
AV1:
CENELEC Standard
Input:
Composite video, RGB and audio-L/R
Output: TV-output with composite video and
audio-L/R
AV2:
CENELEC Standard
Input:
Composite video, RGB, S-VHS and
audio-L/R
Output: Monitor-output with composite video and
audio-L/R
24FWN5-B
CE
Front AV terminal
AV3:
Input:
Headphone socket
Mini Jack
CE24FWN5-B
Sound output
(Continuous)
2 x 3W
Picture tubes
(inches)
24
Dimensions
(WxHxD mm)
612 x 476 x 482
Weight (kg)
25
RCA jacks
Composite video and audio-L/R

Advertisement

loading
Need help?

Need help?

Do you have a question about the CE24FWN5-B and is the answer not in the manual?

Questions and answers

Related Manuals for Sanyo CE24FWN5-B

Summary of Contents for Sanyo CE24FWN5-B

  • Page 1 AC 220~240V 50Hz Television system System I Headphone socket Mini Jack Colour system PAL/NTSC4.43 (PAL/NTSC4.43/NTSC3.58 in AV mode) Channel coverage UHF: 21-69. CE24FWN5-B Aerial input impedance 75 ohm Sound output (Continuous) 2 x 3W AV terminal AV1: CENELEC Standard Picture tubes...
  • Page 2 SAFETY PRECAUTIONS SAFETY PRECAUTIONS CAUTION: Please read and retain for your safety. This unit has been engineered and manufactured to assure your personal safety. But improper use can result in potential electric shock or fire hazards. In order not to defeat the safeguards incorporated in this receiver observe the following basic rules for its installation, use and servicing.

  • Page 3: Installation

    A welcome message will appear, once this has finished the following screen appears. Connect the power cord of the TV set to a wall outlet. Thank you for purchasing your SANYO TV. Auto set-up completed. Now I am searching and storing Happy viewing! all the programmes.

  • Page 4: General Use

    GENERAL OPERA TION - GENERAL OPERA TION - REMOTE CONTROL REMOTE CONTROL General use Programme down/up To select the next programme number or previous pro- gramme number. Also operates as up and down cursor. Standby / Power on-off To switch the TV ON and OFF. Level up/down To adjust the sound volume level.

  • Page 5: Sound Menu

    MENU OPERA TION MENU OPERA TION Many of your TV’s functions are controlled through the menu function. Dyn. Skin tone: Makes the skin tone more realistic. Main menu Picture Level: Rotates between your Personal settings, Standard, Eco and Dynamic . Volume Sound Balance...

  • Page 6: Preset Menu

    MENU OPERA TION MENU OPERA TION Tuning - Frequency (Manual) Preset menu 1. Press the MENU button and select Preset. The preset menu can be used to tune new channels, to reorder channels and their programme positions, and to make fine adjust- 2.

  • Page 7: Operation

    OPERA TION OPERA TION Switching into /from standby mode Zoom 14:9 The Standby mode is used for switching the TV set off for short 14:9 16:9 Letterbox Video periods of time. In standby mode the TV is switched off but is still receiving mains power.
  • Page 8 4: Should the equipment require servicing after the expiry of the Is the programme in colour ? guarantee period, take or send it to the original supplier or any other Sanyo dealer. He will be pleased to give you a quotation WEAK PICTURE for the repair.
