- Page 1 PNEUMATIC SHEAR OPERATOR’S MANUAL Part No. 147025 OM147025...
-
Page 2: Specifications
SPECIFICATIONS Speed 2,800 RPM Cutting Capacity 18 ga Air Inlet 1/4” Hose Size 3/8” I.D. (10mm) Air Pressure 90 P.S.I. (6.2 bar) Average Air Consumption 4 CFM (113 L/min) -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Personal Safety • Stay alert, watch what you are doing and use common sense when using a power tool. - Page 4 Tool Use and Care • Use support handle or other method to secure and support the work piece to a stable platform. • Do not force the tool. Use the correct tool for your application. Using the correct tool which is specifically designed for a select job will provide better tool performance and make the job easier.
-
Page 5: Lubrication And Maintenance
OPERATING INSTRUCTIONS • Only use accessories recommended by Blair Equipment Company. • Check the position of the reversing mechanism before operating the tool so as to be aware of the direction of rotation when operating. Lubrication & Maintenance • Lubricate the tool daily with a good grade of air tool oil. - Page 6 BREAKDOWN Part # Description Part # Description 70601 Motor Housing 70616 Rotor Blades (4) 73402 Spring Pin (2.5x22L) 70117 Spring Pin (3) (2x5L) 70103 Air Inlet 70118 Cylinder 70104 Trigger 70619 Frond End Plate 70105 Valve Stem 70935 Set Screw (M4x8L) 70106 Valve Bushing 70123...
-
Page 7: Parts List
PARTS LIST Part # Description Part # Description 70601 Motor Housing 70616 Rotor Blades (4) 73402 Spring Pin (2.5x22L) 70117 Spring Pin (3) (2x5L) 70103 Air Inlet 70118 Cylinder 70104 Trigger 70619 Frond End Plate 70105 Valve Stem 70935 Set Screw (M4x8L) 70106 Valve Bushing 70123... - Page 8 COMMERCIAL / INDUSTRIAL LIMITED WARRANTY Blair Equipment Company warrants its Portable Magnetic Drills and Tornado II Paint Shakers for two (2) years and other products for ninety (90) days from date of purchase against defects due to faulty material or workmanship and will repair or replace (at its option) without charge any items returned.
