- Page 1 Cordoba Charcoal Bar Table Installation Guide...
- Page 3 Cordoba Charcoal Bar Table POWDER COATED ALUMINIUM FRAME 5mm Stone Look Tempered Glass Table Top ITEM NO. : 0583690...
- Page 5 Please carefully read the below warnings and instructions. Save the instructions for future reference. • Please carefully read all instructions before assembly and use. • Please separate and identify all parts, ensuring that you have all parts listed. • Assembly to be carried out by a competent adult. •...
- Page 6 Parts List: Part No. Pictures Description Table-rack Glass table top Table leg Table leg Leg support tube Hardware Kit: Part No. Pictures Description Bolt M8 x 50 mm Washer ø24x8.4x2mm Spring washer Spanner Bolt M6 x 20 mm Washer ø13x6.5x1mm Allen Key...
- Page 7 Step 1: Put 4pcs table legs (C1&C2) on corner of the table-rack (A), then insert bolts (E), washers (F) and spring washers (G) to the holes after tightened by the spanner (L), then put plastic caps (H) on the bolts (E).
- Page 8 Step 1: Put leg support tube (D) on the table legs (C1&C2), then insert bolts (I) and washers (J) to the holes, after tightened by the Allen key (M), then put plastic caps (K) on the bolts (I). C1&C2...
- Page 9 Step 3: Put the glass table top (B) on the table-rack (A). Bar table is now ready for use.
