Summary of Contents for Mimosa Cordoba 0583685
- Page 1 Cordoba Charcoal Extension Table Installation Guide...
- Page 3 Cordoba Charcoal Extension Table POWDER COATED ALUMINIUM FRAME 5mm Stone Look Tempered Glass Table Top ITEM NO. : 0583685...
- Page 5 Please carefully read the below warnings and instructions. Save the instructions for future reference. • Please carefully read all instructions before assembly and use. • Please separate and identify all parts, ensuring that you have all parts listed. • Assembly to be carried out by a competent adult. •...
- Page 6 Parts List: Part No. Pictures Description Table frame Table leg Table leg Leg bar Leg strutting part Hardware Kit: Part No. Pictures Description Washer ø16x8.5x1mm Spring washer Bolt M6 x 15 mm Washer ø13x6.5x1mm Adjustable cap Expansion bolt Socket spanner Spanner Allen Key Stake...
- Page 7 Step 1 : Take adjustable caps (J) out of the table legs (B1&B2) . Step 2: Screw the nuts (F) onto the leg bars (C) .
- Page 8 Step 3: Fix the leg bars (C) to the table frame (A) with washers (D) and spring washers (E) . Once all bars are in position tighten securely using socket spanner (M). Step 4: Put 4pcs table legs (B1&B2) on corner of the table frame (A), then screw the washers (D), spring washers (E) and nuts (F) to the leg bars (C).
- Page 9 Step 5: Fix the adjustable caps (J) to the table legs (B1&B2) . Fix the leg strutting parts (G) to table legs (B) with bolts (H) and washers (I). ① Once all bolts are in position tighten securely using Allen Key (O). ②...
- Page 10 Step 6: option 2- use on the grass If you decide to locate your extend table on the grass, please secure the stakes (P) with the leg strutting parts (G). Tips: The stakes can be reused. If the table is not secured with stakes, it can still be used, but don't lean on extended part of table, as it will tip up.
- Page 11 Operation: open Step 1: Pull open the first table top. Step 2: Pull out and lift the second table top. Step 3: Push the second table top forward and align it with the first. Step 4: The extend table is opened.
- Page 12 Operation: close Step 1: Pull open the second table top. Step 2: Push the second table top inward and downward. Step 3: Push the first table top forward and align it with the table rim. Step 4: The extend table is closed.
