SERVICE MANUAL
• This set is the tuner, deck, CD
and amplifier section in MHC-MC1.
Manufactured under license from Dolby Laboratories
Licensing Corporation.
"DOLBY" and the double-D symbol a are trademarks
of Dolby Laboratories Licensing Corporation.
Amplifier section
U.S.A models:
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 8 Ω loads both channels driven, from 70 – 20,000 Hz; rated 80 W per
channel minimum RMS power, with no more than 0.9% toral harmonic
distortion from 250 mW to read output.
Continuous RMS power output
80 + 80 W(8Ω at 1kHz, 10% THD)
Tortal harmonic distortion
less than 0.09%(8Ω at 1kHz, 40W)
Inputs
VIDEO/MD IN (phono jack):
voltage 250mV/450mV,
impedance 47kΩ
Outputs
VIDEO/MD OUT (phono jack):
voltage 250mV,
impedance 1kΩ
PHONES (stereo phone jacks):
accepts headphones of 8Ω or more
SPEAKER : accepts impedance of 8 to 16Ω
REAR SPEAKER :
accepts impedance of 16Ω
SUPER WOOFER :
Voltage 1V, impedance 1kΩ
CD player section
System
Compact disc and digital audio system
Laser
Semiconductor laser (λ =780mm)
Emission duration:
continuous
MICROFILM
All manuals and user guides at all-guides.com
CD
Section
Tape deck
Section
SPECIFICATIONS
HCD-MC1
Model Name Using Similar Mechanism HCD-F150/FR10
CD Mechanism Type
Optical Pick-up Name
Model Name Using Similar Mechanism HCD-DR8AV
Tape Transport Mechanism Type
Laser output
Max. 44.6µW*
*This output is the value measured at a distance of
200 mm from the objective lens surface on the
Optical Pick-up Block with 7 mm aperture.
Frequency response
2Hz – 20kHz (±0.5dB)
Wavelength
780 – 790nm
Signal-to-noise retio
More than 90dB
Dynamic range
More than 90dB
CD OPTICAL DIGITAL OUT
(Square optical connector jack, rear panel)
Output Level
–18dBm
Tape player section
Recording system
4-track 2-channel stereo
Frequency response (DOLBY NR OFF)
40 – 13,000Hz (±3dB),
using Sony TYPE I
cassette
40 – 14,000Hz (±3dB),
using Sony TYPE II
cassette
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
87.5 – 108.0MHz
Antenna
FM lead antenna
Antenna terminals
75Ω unbalanced
Intermediate frequency 10.7MHz
MINI HI-FI COMPONENT SYSTEM
US Model
E Model
CDM-46B1
KSS-213BA/F-NP
TCM-230AWR2/230PWR2
— Continued on next page —

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCD-MC1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sony HCD-MC1

  • Page 1 4-track 2-channel stereo VIDEO/MD IN (phono jack): Frequency response (DOLBY NR OFF) voltage 250mV/450mV, 40 – 13,000Hz (±3dB), impedance 47kΩ using Sony TYPE I Outputs cassette VIDEO/MD OUT (phono jack): 40 – 14,000Hz (±3dB), voltage 250mV, using Sony TYPE II impedance 1kΩ...
  • Page 2: Schematic Diagram

    All manuals and user guides at all-guides.com HCD-MC1 6-4. SCHEMATIC DIAGRAM BD SECTION • See page 71 for Waveforms. • See page 72 for IC Pin Functions. BA/F-NP 1SS133T The components identified by mark ! or dotted line with mark ! are critical for safety.
  • Page 3: Cd Motor Section

    All manuals and user guides at all-guides.com HCD-MC1 6-6. SCHEMATIC DIAGRAM CD MOTOR SECTION — 41 — — 42 —...
  • Page 4: Audio Section

    All manuals and user guides at all-guides.com HCD-MC1 6-8. SCHEMATIC DIAGRAM AUDIO SECTION • See page 80 for IC Block Diagrams. MAIN BOARD CN106 (Page 55) 0.01 The components identified by mark ! or dotted line with mark ! are critical for safety.
  • Page 5: Leaf Sw Section

    All manuals and user guides at all-guides.com HCD-MC1 6-10. SCHEMATIC DIAGRAM LEAF SW SECTION MAIN BOARD CN107 (Page 55) — 49 — — 50 —...
  • Page 6: Main (1/5) Section

    All manuals and user guides at all-guides.com HCD-MC1 6-12. SCHEMATIC DIARGAM MAIN (1/5) SECTION EQUALIZER MICRO PROC. INTERFACE POWER AMP FM/AM TUNER UNIT IS SUPPLIED AS THE ASSEMBLED BLOCK (DECK A) — 53 — — 54 —...
  • Page 7: Main (2/5) Section

    All manuals and user guides at all-guides.com HCD-MC1 6-13. SCHEMATIC DIARGAM MAIN (2/5) SECTION • See page 51 for Printed Wiring Board. • See page 71 for Waveforms. • See page 77 for IC Pin Functions. E MODEL 0.01µF BN1F4M...
  • Page 8: Main (3/5) Section

    All manuals and user guides at all-guides.com HCD-MC1 6-14. SCHEMATIC DIARGAM MAIN (3/5) SECTION • See page 51 for Printed Wiring Board. • See page 71 for Waveforms. • See page 56 for IC Pin Functions. (CD DOOR) 0.33 0.01uF —...
  • Page 9: Main (4/5) Section

    All manuals and user guides at all-guides.com HCD-MC1 6-15. SCHEMATIC DIARGAM MAIN (4/5) SECTION • See page 51 for Printed Wiring Board. • See page 80 for IC Block Diagrams. POWER AMP BN1F4M BN1F4M 0.01uF 0.01uF The components identified by mark ! or dotted line with mark ! are critical for safety.
  • Page 10: Main (5/5) Section

    All manuals and user guides at all-guides.com HCD-MC1 6-16. SCHEMATIC DIARGAM MAIN (5/5) SECTION • See page 51 for Printed Wiring Board. 2SB1375 BN1A4M 1375 2200 — 61 — — 62 —...
  • Page 11: Panel Section

    All manuals and user guides at all-guides.com HCD-MC1 6-18. SCHEMATIC DIAGRAM PANEL SECTION • See page 80 for IC Block Diagrams. • See page 71 for Waveforms. • See page 79 for IC Pin Function Description. R652 — 65 —...
  • Page 12: Power Section

    All manuals and user guides at all-guides.com HCD-MC1 6-20. SCHEMATIC DIAGRAM POWER SECTION US MODEL VOLTAGE CHANGE S991 E MODEL E MODEL 250V US MODEL US MODEL The components identified by mark ! or dotted line with mark ! are critical for safety.
  • Page 13: Ic Block Diagrams

    All manuals and user guides at all-guides.com 6-23. IC BLOCK DIAGRAMS IC603 (PANEL BOARD) BA3833F-E2 IC461 (MAIN BOARD) BA6780 RESET RESET 18 RESET VIN1 VIN2 REFFERENCE PREF 17 f01 CURRENT FIN1 FIN2 LINE 16 f02 RIN1 RIN2 LINE 15 f03 IOUT BIAS 13 f...
