- Page 1 Quick ALLNET PoE Display Product No.: 10 inch (215110), 12 inch (219234),14 inch (218414),15 inch (219236), 18 inch (219232), 21 inch (219233)
-
Page 2: Table Of Contents
Table of contents Package Contents ________________________________________________________________________ 3 General _________________________________________________________________________________ 3 Target group of the user manual ___________________________________________________________ 3 Conventions and symbols _________________________________________________________________ 3 Chapter title_____________________________________________________________________________ 3 Warnings _______________________________________________________________________________ 4 Guidelines and standards__________________________________________________________________ 5 Disposal of packaging _____________________________________________________________________ 6 Ordinance_______________________________________________________________________________ 6... -
Page 3: Package Contents
Package Contents Please check the contents of the packaging before proceeding with the commissioning of the display. • ALLNET PoE Display with Stand • 12V power supply • Printed Quick Start Guide General The device is a display that can be operated with Android or Linux. The power supply is via power supply or PoE (power via network cable). -
Page 4: Warnings
The signal word "WARNING" indicates a warning of possible danger to life and/or serious irreversible injury! The signal word "CAUTION" indicates a warning of possible medium and/or minor injuries! The signal word "ATTENTION" indicates possible property damage. "Notice" indicates useful or important information about the product. www.allnet.de... -
Page 5: Guidelines And Standards
• RoHS Directive 2011/65/EU. ALLNET Computersysteme GmbH hereby declares that the ALLNET PoE Displays is in compliance with the essential requirements and other relevant provisions of the following Directives and Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following Internet address: http://ce.allnet.de and at the end of the instructions. -
Page 6: Disposal Of Packaging
Permanently installed portable batteries or rechargeable batteries may remain in the device when disposed of at the collection point. www.allnet.de... -
Page 7: General Security
Do not pull the plug-in power adapter out of the socket by the cable. • The device remains connected to the mains even when switched off. Pull the plug-in power adapter out of the socket if the device has been used for a longer period of time. www.allnet.de... -
Page 8: Safety Instructions For The Installation Of The Device
Do not expose the device and remote control to direct sunlight. This impairs function and could lead to damage • Do not use the appliance in a humid environment and do not use it near gas flames, stovetops or other hot objects. www.allnet.de... -
Page 9: Safety Notice For Repair And Maintenance
Do not use liquid cleaners or cleaning sprays. The appliance must only be cleaned with a damp cloth. • It is forbidden to make modifications to the device. • Damaged devices or damaged accessories may no longer be used. www.allnet.de... -
Page 10: Intended Use
The device is designed for use inside enclosed spaces and must be protected from excessive dust, extreme temperatures, wetness and condensation. The environmental requirements are given as follows: Operating conditions: Temperatur 0° - +40° Humidity 20% - 80% non-condensing Storage: Temperatur 0° - +60° Humidity 10% - 90% non-condensing Frequencies www.allnet.de... -
Page 11: Technical Details
50 – 60 Hz Input frequency Input current 0.8A Output voltage 12 V Output 2.5 A Output power 30 W Average efficiency in 87,50% operation Efficiency at low load (10%) 87,50% Power consumption at no- 0.075 W load Energy efficiency class www.allnet.de... -
Page 12: Poe Power Supply
15-21 inches IEEE 802.3at 42,5 - 57 V 600 mA 25.5 W 12.95 - 25.50 W IEEE 802.3bt 42.5 - 57 V 2× 960 mA 45 W 40 W 60 W 51 W 75 W 62 W 90 W 71 W www.allnet.de... -
Page 13: Dimensions
Dimensions Tablet 10 Zoll www.allnet.de... - Page 14 Tablet 12 Zoll www.allnet.de...
- Page 15 Tablet 14 Customs www.allnet.de...
- Page 16 Tablet 15 Customs www.allnet.de...
- Page 17 Tablet 18 Zoll www.allnet.dand...
- Page 18 Tablet 21 Zoll www.allnet.de...
-
Page 19: Service
Service This is a guide for Android in general and about special functions of the ALLNET displays. The display is a certified Google device. Connect the tablet to the power supply. The tablet starts automatically. Switching off the Touch Power Button in the front You can disable the Power Touch button in the software. - Page 20 Then click on the square and on the icon at the top center. Click Share Links. Now select the second app that you want to share on the screen. Now the division ratio can still be changed. Please note that after a restart, this arrangement will be lost. Fixing an APP www.allnet.de...
- Page 21 The way it works is simple and is just a simple protection against unauthorized access. The app can still be terminated by a keyboard shortcut. You can find a professional kiosk app in the Playstore under "FullyKiosk Browser". There please go to the item "Other security settings" and click on Screen fixation. www.allnet.de...
- Page 22 As an option, you can also install a security that locks the tablet when the app is closed. To activate the screen lock, click on the square in the navigation bar, where you will find the most recently opened APPs. Click on the middle icon at the top of the app to use. www.allnet.de...
- Page 23 This screen fixation is no longer active after a restart and the procedure for fixing must be performed again. Setup Ethernet Open the " Settings" Select Network&Internet, then click More www.allnet.de...
- Page 24 Select "Wireless & Network", then click on Wi-Fi and activate the switch Select the desired Wi-Fi network and enter the password if necessary. After a successful connection, the tablet will automatically connect to the network if it is within range. www.allnet.de...
- Page 25 You can set up a static network connection under IP Setting. By clicking on "static" you can set up the IP address, gateway and DNS server. Settings Change language Open the Settings app Under "System", select "Language & Input", then click on Language and select the desired language www.allnet.de...
- Page 26 www.allnet.de...
- Page 27 You can activate the language by dragging the language up on the right edge. Change time zone, date, and time settings Open the "Settings" app and select "System". Select the "Date and Time" menu item from the "System" menu item. www.allnet.de...
- Page 28 You can either obtain the appropriate time zone automatically via the network or change it manually via the "Select time zone" item. www.allnet.de...
- Page 29 www.allnet.de...
- Page 30 Under the item "Device Security/Screen Lock" you can then assign a PIN to unlock the tablet, among other things. Change Volume Setting Open the Settings app Select the "Sounds" menu item from the "Device" menu item. Here you can adjust the volume for media playback, alarms, and notifications. www.allnet.de...
- Page 31 Display settings Open the Settings app Select "Display", then click on Brightness Level, now you can adjust the brightness continuously. In addition to the brightness, you can also change the background or choose a screensaver. www.allnet.de...
- Page 32 Open the Settings app Select Display, then turn off Show NavigationBar/ or Phone StatusBar. You can also operate the tablet with a mouse and keyboard. The left button is the "Mouse click", the right mouse button is the "Back" button www.allnet.de...
- Page 33 Settings "Automatically turn off the display" Open the Settings app Select "Display", then click on Advanced/Hibernation, now you can set the display's power off time. By activating the "Never" menu item, the screen remains active until the tablet is switched off. www.allnet.de...
- Page 34 Internet connection. This app can also be downloaded from external download websites such as APK Mirror. Please note that downloading external pages can be risky. We assume no liability for this! www.allnet.de...
- Page 35 Quit the app Click the rectangular icon in the bottom navigation bar. You will then be shown all active apps, which you can then close if you wish. www.allnet.de...
- Page 36 These must be opened beforehand so that they can be selected. Take a screenshot Under Settings you will find the item "Screenshot". When clicked, a settings window opens. Here you can turn on the function in the navigation bar. www.allnet.de...
- Page 37 Display Rotation The display can be used horizontally and vertically. To do this, please go to the Display/Screen Rotation settings. In the pop-up, select the number of degrees of rotation. The tablet will now restart in the set mode. www.allnet.de...
- Page 38 6 times in a row. The camera will open to scan the MDM code. This can also be typed in manually if the entry is incorrect. A QR code via camera can also be captured. To help, the camera can be rotated and rotated here. This can be done under Settings/Connected Devices. www.allnet.de...
- Page 39 Note: Please check that no other ADB drivers are installed on the system. This can lead to errors in the detection of the tablet. Under Settings/System, the first thing to do is to turn off the Turn on USB Host switch. www.allnet.de...
- Page 40 !! Attention!!! The Google license expires if the firmware is deleted, replaced or changed if the OTA update offered by ALLNET is not used. This is especially true for a reinstallation of Linux on Android. In this case, there is also no entitlement to warranty or replacement.
- Page 41 IEC 62321-4:2 01 3+A1:201 7 2015/8 63 IEC 62321-7-2:2017/ IEC 62321- 6:2015 IEC 62321-7-1:2015/ IEC 62321- 8:2017 This equipment is intended to be operated in all countries. This declaration is made by ALLNET GmbH Computersysteme Maistraße 2 82110 Germering Germany Germering, 20.07.2023 www.allnet.de...
