Quick guide

ALLNET Rugged Tablet PC

Xtrail-100-light

ProductNo.: 10 inch (222807)

Table of Contents

Need help?

Do you have a question about the Xtrail-100-light and is the answer not in the manual?

Questions and answers

Summary of Contents for Allnet Xtrail-100-light

Page 1 Quick guide ALLNET Rugged Tablet PC Xtrail-100-light ProductNo.: 10 inch (222807)
Page 2: General Information
Package Please check the contents of the packaging before continuing to operate the display. • ALLNET Xtrail-100-light 10" Tablet • 5V power supply unit • Printed quick guide General information The device is a display that can be operated with Android or Linux. Power is supplied via a power supply unit or PoE (power via network cable).
Page 3 The signal word "WARNING" indicates a warning of possible danger to life and/or serious irreversible injuries! The signal word "CAUTION" indicates a warning of possible moderate or minor injuries! The signal word "CAUTION" indicates possible material damage. "Note" indicates useful or important information about the product. www.allnet.de...
Page 4: Guidelines And Standards
Eco-Design Directive 2009/125/EC  RoHS Directive 2011/65/EU. Hereby, ALLNET Computersysteme GmbH declares that the ALLNET PoE Displays are in compliance with the essential requirements and other relevant provisions of the following directives and Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following Internet address: http://ce.allnet.de...
Page 5: Disposal Of The Packaging
Permanently installed appliance batteries or rechargeable batteries may remain in the appliance when disposed of via the collection point. www.allnet.de...
Page 6: General Security
Do not pull the plug-in power supply unit out of the socket by the cable.  The appliance remains connected to the mains even when it is switched off. Unplug the mains adapter from the socket if the appliance is to be used for a longer period of time. www.allnet.de...
Page 7 Do not expose the device and the remote control to direct sunlight. This impairs the function and could lead to damage • Do not use the appliance in a damp environment or near gas flames, hotplates or other hot objects. www.allnet.de...
Page 8 Do not use liquid cleaners or cleaning sprays. The appliance may only be cleaned with a damp cloth. • It is prohibited to make modifications to the appliance. • Damaged devices or damaged accessories may no longer be used. www.allnet.de...
Page 9: Intended Use
The device is designed for use in enclosed spaces and must be protected from excessive dust, extreme temperatures, moisture and condensation. The environmental requirements are specified as follows: Operating conditions: Temperature 0° - +40° Humidity 20% - 80% non-condensing Storage conditions: Temperature 0° - +60° Humidity 10% - 90% non-condensing www.allnet.de...
Page 10 Frequency data X-Trail 100 Light www.allnet.de...
Page 11: Technical Details
 Military Drop Test 1.2m  Power supply unit: 12V  Operating temperature: -20° ~ +60 °C Operating humidity: 10% ~ 90% (non-condensing) Storage temperature: 0 ~ 70 °C Storage humidity: 0% ~ 90% (non-condensing)  Labeling: Ce/RoHS  Dimensions 275*179.2*21.8 mm www.allnet.de...
Page 12 Input frequency 50 - 60 Hz Input current strength 1.5A Output voltage Output current Output power 15 W Average efficiency in operation 87,50% Efficiency at low load (10 %) 87,50% Power consumption at no load 0,075 W Energy efficiency class www.allnet.de...
Page 13 5 Type-C port: supports OTG function 6 Headphone socket: for audio output 7 HDMI: high-resolution audio and video output 8 User-defined buttons 9 On/off button 10 Volume + 11 Volume - 12 user-defined buttons 13 TF card slot and SIM card slot www.allnet.de...
Page 14 6. Receiver Rear X-Trail 100 Light • Speakers: two speakers, sound output. • SN label • Rear camera • Flashes • Fingerprint sensor for fingerprint recognition, comparison. • (optional) • NFC reader (optional) Reads data from electronic NFC roll labels. www.allnet.de...
Page 15: Connecting The Power Supply Unit
Plug the DC cable of the power supply unit into the mains socket of the robust tablet. Note: Only use the power adapter supplied with this product. Using other power adapters may damage your computer. The appliance must be connected to the mains when it is switched on without power. www.allnet.de...
Page 16: Battery Use
When unplugging, do not pull on the cable, but hold the plug with your hand to pull it out. www.allnet.de...
Page 17 Remove the rubber stopper from the SIM and TF card and insert the microSD card into the TF card slot as shown in the illustration (the SIM card slot is located above the TF card slot) Note: The metal side of the TF card faces the display. www.allnet.de...
Page 18: Nfc Reader
NFC reader If your model has an NFC/RFID reader module, you can use it to read NFC (Near Field Communication) and RFID (Radio Frequency Identification). (Radio Frequency Identification) Data of the electronic roll label. (depending on model) www.allnet.de...
Page 19: Operation
Operation This is a guide for Android in general and for special functions of ALLNET displays. The display is a certified Google device. Switch on the tablet. The tablet starts automatically. Switching off the touch power button on the front You can deactivate the Power Touch Button in the software.
Page 20 Fixing an APP Please note: The functionality is simple and is only a simple protection against unauthorized access. The app can still be closed using a key combination. You can find a professional kiosk APP in the Playstore under "FullyKiosk Browser". www.allnet.de...
Page 21 There, please go to the item "Further security settings" and click on Screen fixation. www.allnet.de...
Page 22 As an option, you can also install a security feature that locks the tablet when the app is closed. To activate the screen lock, click on the square in the navigation bar, where you will find the most recently opened apps. Click on the middle icon at the top. www.allnet.de...
Page 23 This screen fixation is no longer active after a restart and the fixation procedure must be carried out again. Ethernet setup Open the "Settings" Select "Network & Internet", then click on "More" www.allnet.de...
Page 24 Select "Wireless & Network", then click on Wi-Fi and activate the switch Select the desired WLAN network and enter the password if necessary Once the connection has been successfully established, the tablet automatically connects to the network if it is within range. www.allnet.de...
Page 25 You can set up a static network connection under IP setting. By clicking on "static" you can set up the IP address, gateway and DNS server. Settings Change language Open the "Settings" app Under "System", select "Language & input", then click on Language and select the desired language. www.allnet.de...
Page 26 www.allnet.de...
Page 27 Activate the language by dragging the language upwards on the right-hand edge. Change time zone, date and time settings Open the "Settings" app and select "System". Select the "Date and time" menu item from the "System" menu item. www.allnet.de...
Page 28 You can either obtain the appropriate time zone automatically via the network or change it manually via the "Select time zone" item. www.allnet.de...
Page 29 www.allnet.de...
Page 30 You can then assign a PIN to unlock the tablet under "Device security/display lock". Change volume setting Open the "Settings" app Select the "Sounds" menu item from the "Device" menu item. Here you can set the volume for media playback, alarm clock and notifications. www.allnet.de...
Page 31 Display settings Open the "Settings" app Select "Display", then click on Brightness level, now you can adjust the brightness continuously. In addition to the brightness, you can also change the background or select a screen saver. www.allnet.de...
Page 32 Open the "Settings" app Select "Display", then switch off "Show Navigation Bar/ or Phone Status Bar". You can also operate the tablet with a mouse and keyboard. The left button is the "Mouse click", the right mouse button is the "Back" button www.allnet.de...
Page 33 Settings "Switch display off automatically" Open the "Settings" app Select "Display", then click on Advanced/Hibernate, now you can set the display switch-off time. By activating the "Never" menu item, the screen remains active until the tablet is switched off. www.allnet.de...
Page 34 Internet. This app can also be downloaded from external download sites such as APK Mirror. Please note that downloading from external sites can be risky. We assume no liability for this! www.allnet.de...
Page 35 Exit app Click on the rectangular icon in the bottom navigation bar. You will then be shown all active apps, which you can then close as required. www.allnet.de...
Page 36 These must be opened beforehand so that you can select them. Create screenshot Under Settings you will find the item "Screenshot". Click to open a settings window. You can activate the function in the navigation bar here. www.allnet.de...
Page 37 Display rotation The display can be used horizontally and vertically. To do this, please go to the Display/Screen rotation settings. Select the degree of rotation in the pop-up. The tablet will now restart in the set mode. www.allnet.de...
Page 38 The Google-certified displays can be controlled with MDM software. To do this, you must tap a free space in the wizard 6 times in succession. The camera opens to scan the MDM code. This can also be entered manually in the event of an incorrect entry. www.allnet.de...
Page 39 This equipment is intended to be operated in all countries. This declaration is made by. ALLNET GmbH Computer Systems Maistraße 2 82110 Germering Germany Germering, December 08. 2023...
