- Page 1 SALT WATER CHLORINATOR USER’S MANUAL Ver. 1 1 / 22 Manual CONCEPT-P, ver. 1...
- Page 2 FILL IN THE FOLLOWING FORM WITH THE REGISTRATION DATA THAT IS ON THE SIDE LABEL OF THE UNIT YOU HAVE ACQUIRED YOU WILL NEED THIS DATA IF YOU WISH TO CONSULT YOUR SUPPLIER OR BSV ELECTRONIC S.L. MODEL..……………………………………………… IP………………………………………………………. REF. …………………………………………………..
-
Page 3: General Description
The BSV Electronic S.L. saline chlorinators allow you to keep the water in your pool clean and crystal-clear, without adding chemical disinfectants. The system of saline chlorination for swimming pools, manufactures the... - Page 4 _______________________________________________________________ 1.1 SECURITY In order to avoid that the device operates in abnormal conditions, the control unit measures continuously the parameters and the state of the electrolysis circuit, so that if the water flow in the cell is not correct, if the cell detects a short circuit or an over-voltage, the power circuit automatically disconnects creating a luminous and acoustic alarm till the problem is solved.
-
Page 5: Pool Preparation
_______________________________________________________________ 2. POOL PREPARATION It is necessary to add some salt to the water and ensure that the pH level is adequate. PH and salt levels have to be as follows: WATER POOL PREPATRATION Salt, kg/m3 --------------- 2* - 6, 5 PH -------------------------- 7,0 - 7, 6 * The device starts working from 2gr/L. - Page 6 _______________________________________________________________ 3. SETTINGS Two push buttons, P1 and P2, are used to set chlorine production. Salt excess Lack of salt No water flow Overload With P2 production is increased and with P1 it is decreased. Green LEDs LED1 to LED5 show chlorine production: 0%, 25%, 50%, 75% and 100% of the maximum value.
-
Page 7: Short Circuit
Other Contact with your distributor or BSV Electronic S.L or your supplier. NOTE: Clean the cell at least once a year as detailed in point 8.1.always before summer season. LED6 and acoustic alarm: Flashes showing overload. -“SHORT-CIRCUIT”:... -
Page 8: Running Hours
_______________________________________________________________ Causes: Action: No water flow or overload Restore the water flow circulation or check if there is an overload Cell disconnected. Connect cell. Check that the ambient temperature Let rest the equipment for some does not surpass 40ºC. Check that minutes. -
Page 9: Software Version
_______________________________________________________________ 6. SOFTWARE VERSION To check the software version switch on the unit keeping push button P2 pressed. ED9 flashes for a while and the first digit appears, as in the previous paragraph. This version has 3 digits. 7. INSTALLATION •... - Page 10 _______________________________________________________________ 7.1 HYDRAULIC CIRCUIT / CONNECTIONS 1. From swimming pool. 2. To the pool. 3. Electrolysis cell. 4. Cell cable. 5. Chlorinator CxxP 6. Power supply inlet. 7. Filter. 8. Pump cable. 9. Pump. 10. pH probe. Keep as far as possible from the cell (more than 0.5 m) 11.
-
Page 11: Wiring Diagram
_______________________________________________________________ 7.2 WIRING DIAGRAM earth connection J1: Power supply 220v J2: Switch ON/OFF J3: Not used J4: Not used J5: Not used J7: Cell connection 1- Not used 7- Not used 2- Not used 8- Not used 3- Not used 9- Not used 4- Not used 10- Not used... -
Page 12: Maintenance
_______________________________________________________________ 8. MAINTENANCE The chlorinator has an automatic cleaning system of the electrolytic cell which allows a minimum of maintenance. But it is advisable to clean the cell starting season. The electrolytic cell will age with time. If after a cleaning operation the unit does not work properly, the sensor or the cell has to be replaced. - Page 13 _______________________________________________________________ 8.2 Water chemical balance maintenance: To set chlorine production, it is recommended to check chlorine concentration frequently, mainly during the first’s days of use and increase or decrease the productions depending on its needs. You can see below the balance values for the swimming pool water: Parameter Minimum...
-
Page 14: Warranty And Service
_______________________________________________________________ 9. WARRANTY AND SERVICE BSV Electronic S.L. offers a two years warranty on his chlorinators for the control unit. The electrolysis cell is warranted 2 years or 5 000 hours for any chlorinator model. This warranty is given to the unit owner and cannot be transferred. All chlorinators are fully tested in the factory before being packed. - Page 15 _______________________________________________________________ 10. SPARE PIECES 15 / 19 Manual CONCEPT-P, ver. 1...
- Page 16 _______________________________________________________________ 1 Keyboard cover, ref. CS-1002 2 Keyboard, ref. TECLADO-C 3 Lid’s screws, ref. CL81Z x 4u. 4 Device Lid, ref. CONCEPT-TAPA 4A Lid cover, ref. CS-1001T 5 Control board fixing screws, ref. TCH2.9X9.5 x 3u. 6 Control board, ref. P909-4 7 Power board fixing screws, ref.
- Page 17 _______________________________________________________________ 9 Power board, ref. P927 10 Radiator fixing screws, ref. TCH4.2X16 x 4u. 11 Device basis, ref. CONCEPT-BASE 12 Stuffing boxes M25, ref. M25JSL 13 Stuffing boxes M20, ref. M20JSL 14 Stuffing boxes M16, ref. M16JSL 15 Switch + protector, ref. R13112AAA + F0188LOAAA 16 Box hinge, ref.
- Page 18 _______________________________________________________________ 11. ANNEXE 1 IP65 SYSTEM: It has the following features: -It has a 6 protection against the dust and strange things. Protection against the dust entrance (Dust tightness), total protection against contacts. -It has a 5 protection against the water entrance. Protection against water splashing from any direction.
- Page 19 _______________________________________________________________ ECLARATION OF ONFORMITY : BSV Electronic, S.L. Manufacturer Address : C/ Ribera del Congost, 40 A Pol. Ind. Sector V 08520 Les Franqueses del Vallès Barcelona (España) Certified Products: Salt Water Chlorinators for Swimming Pools BSPOOL Series: Concept-S Models: C10S, C15S, C20S, C25S, C10SK, C15SK, C20SK, C25SK, C10SPH, C15SPH, C20SPH,...
