- Page 1 Installation manual Washer extractor EUD–615, EUD–618, EUD–625, EUD–630, EUD–645, EUD–660, EUD–680 Compass Pro Type W3..438917551/US 2024.02.12...
- Page 3 Safety WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR MACHINE. MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE REFERENCE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
-
Page 4: Important Safety Instructions
Safety IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of fire, electric shock, or injury to persons when using your appliance, including the following: 1. Read all instructions before using the appliance. 2. This machine must be securely bolted to an uncovered concrete floor. 3. - Page 5 Safety NOTICE TO: OWNERS, OPERATORS AND DEALERS IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND WILLFUL NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCIDENTS OR INJURY. TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE FOLLOWING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS. Prior to operation of the machine, check to make certain that all operating instructions and warning signs are affixed to the machine and legible.
-
Page 6: Notice To Installer
Safety NOTICE TO INSTALLER Improper installation of this machine: • May cause serious damage to the machine. • May result in other property damage. • May cause personal injury. • Will void the manufacturer's warranty. Improper fastening of this machine to its foundation, inferior foundation materials, an undersized foundation, the use of fabricated steel bases not provided by Electrolux Professional or its approved supplier(s), the use of an improper type, number, or size of mounting bolts, or failure to use proper hardware on mounting bolts may result in damage to the machine that will not be covered by the... -
Page 7: Table Of Contents
Contents Contents 1 Safety Precautions ..........................9 General safety information......................9 Commercial use only........................9 Copyright ..........................10 Symbols..........................10 2 Warranty terms and exclusions......................11 3 Technical data...........................12 Drawing ..........................12 3.1.1 EUD-615, EUD-618, EUD-625 ..................12 3.1.2 EUD-630 ........................13 3.1.3 EUD-645, EUD-660, EUD-680 ..................14 Technical data .........................15 Connections ..........................16 4 Setup ...............................17 Unpacking ..........................17... -
Page 9: Safety Precautions
Installation manual 1 Safety Precautions • Servicing shall be carried out only by authorized personnel. • Only authorized spare parts, accessories and consumables shall be used. • Only use detergent intended for water-wash of textiles. Never use dry cleaning agents. •... -
Page 10: Copyright
Installation manual 1.3 Copyright This manual is intended solely for consultation by the operator and can only be given to third parties with the permis- sion of Electrolux Professional AB company. 1.4 Symbols Caution Caution, high voltage Read the instructions before using the machine... -
Page 11: Warranty Terms And Exclusions
Installation manual 2 Warranty terms and exclusions If the purchase of this product includes warranty coverage, warranty is provided in line with local regulations and sub- ject to the product being installed and used for the purposes as designed, and as described within the appropriate equipment documentation. -
Page 12: Technical Data
Installation manual 3 Technical data 3.1 Drawing 3.1.1 EUD-615, EUD-618, EUD-625 fig.X01718 Operating panel Door opening, EUD-615, EUD-618: ⌀ 310 mm / 12 3/16 inch, EUD-625: ⌀ 365 mm / 14 3/8 inch Detergent container Cold water Hot water Cold/Hot water or Re-used water with network pressure (option) Re-used water from tank/pump or Liquid detergent supply Drain Liquid detergent supply... -
Page 13: Eud-630
Installation manual 3.1.2 EUD-630 fig.X01751 Operating panel Door opening, EUD-630: ⌀ 395 mm / 15 9/16 inch Detergent container Cold/Hot water (Detergent container) Cold water Hot water Cold/Hot water or Re-used water with network pressure (option) Re-used water from tank/pump or Liquid detergent supply Drain Liquid detergent supply Electrical connection... -
Page 14: Eud-645, Eud-660, Eud-680
Installation manual 3.1.3 EUD-645, EUD-660, EUD-680 fig.X01752 Operating panel Door opening, EUD-645, EUD-660, EUD-680: ⌀ 435 mm / 17 1/8 inch Detergent container Cold/Hot water (Detergent container) Cold water Hot water Cold/Hot water or Re-used water with network pressure (option) Re-used water from tank/pump or Liquid detergent supply Drain Liquid detergent supply... -
Page 15: Technical Data
Installation manual 3.2 Technical data EUD-615 EUD-618 EUD-625 EUD-630 EUD-645 EUD-660 EUD-680 Weight, net 1235 Drum volume litres 10.6 Drum diameter inch 20 1/2 20 1/2 23 7/16 25 9/16 28 9/16 31 5/16 31 5/16 Drum speed during wash Drum speed during extraction 1245 1245... -
Page 16: Connections
Installation manual 3.3 Connections EUD-615 EUD-618 EUD-625 EUD-630 EUD-645 EUD-660 EUD-680 Water valves 3/4” 3/4” 3/4” 3/4” 3/4” 3/4” 3/4” Recommended water 200–600 200–600 200–600 200–600 200–600 200–600 200–600 pressure 30–90 30–90 30–90 30–90 30–90 30–90 30–90 Continuous operating 50–800 50–800 50–800 50–800... -
Page 17: Setup
Installation manual 4 Setup 4.1 Unpacking 4.1.1 EUD-615, EUD-618, EUD-625 Remove the front and rear panel. Remove the four transport supports. Save the transport supports if the machine needs to be moved in the future. Note! Once the transport supports have been removed, handle the machine carefully to avoid damage to the sus- pension components. - Page 18 Installation manual Remove the machine from the pallet. Note! When moving the machine, handle it with care. Make sure that the machine does not come down on the floor with either of the rear corners first. The side panel of the machine can be damaged. Place the machine on its final position.
-
Page 19: Eud-630, Eud-645, Eud-660, Eud-680
Installation manual 4.1.2 EUD-630, EUD-645, EUD-660, EUD-680 Note! Two persons are recommended for the unpacking. Remove the side panels. Remove the front and rear panel. Remove the transport securities. Save the transport securities if the machine needs to be moved in the future. Note! Once the transport securities have been removed, handle the machine carefully to avoid damage to the sus- pension components. - Page 20 Installation manual Remove the machine from the pallet. Note! When moving the machine, handle it with care. Place the machine on its final position. Mount the supporting feet. EUD-630, EUD-645, EUD-660 EUD-680 Remount the panels.
-
Page 21: Recycling Instruction For Packaging
Installation manual 4.2 Recycling instruction for packaging fig.X02395 Fig. Description Code Type Wrapping film LDPE 4 Plastics Corner protection PS 6 Plastics Cardboard packaging PAP 20 Paper Pallet FOR 50 Wood Screw FE 40 Steel FE 40 Steel Plastic bag PET 1 Plastics... -
Page 22: Siting
Installation manual 4.3 Siting Install the machine close to a floor drain or open drain. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. Failure to respect the prescribed distances will prevent easy access for maintenance and service operations. -
Page 23: Mechanical Installation
Installation manual 4.4 Mechanical installation If the machine is not to be mounted on a base the machine must be fastened to the floor with the enclosed expansion bolts. The table shows the correct position of feet and drilling points. EUD-615, EUD-618, EUD-625: Mark and drill two holes (⌀... - Page 24 Installation manual Place the machine over the two drilled holes. The holes are at the front of the machine. Level the machine with the feet of the machine. Screw in the feet as much as possible before starting to level the ma- chine.
-
Page 25: Water Connection
Installation manual 5 Water connection All water intake connections to the machine should be fitted with manual shut-off valves and filters, to facilitate instal- lation and servicing. Water pipes and hoses should be flushed clean before installation. The machine shall be connected with new water hoses. Re-used water hoses must not be used. Hoses are to be of an approved type and grade and comply with national regulations. -
Page 26: Connection Of External Dosing Systems
Installation manual 6 Connection of external dosing systems 6.1 Connection of the hoses The machine is prepared for connection of external dosing systems or water re-use systems etc. The connections are closed at delivery. Open any of the connections that shall be used by drilling a hole where the hoses shall be connected. -
Page 27: Electrical Connection Of External Dosing System
Installation manual 6.2 Electrical connection of external dosing system The power supply to the external dosing system must never be connected to the machine’s incoming terminal block or to the edge connectors on the I/O-board. 6.2.1 Machine with connectors Connect the external dosing system to connections A and B on the machine. Connect the signal cable to B and the power supply to A. -
Page 28: Machine Without Connectors
Installation manual 6.2.2 Machine without connectors Connect the external dosing system to the I/O board, which is located to the right of the incoming power supply. The I/O board has edge connectors for connecting external dosing systems. Edge connectors on the I/O board can be loosened for connecting cables. fig.6572 11 = N 18 = Program run... -
Page 29: Outputs
Installation manual 6.2.3 Outputs Connect the power supply (e.g. 24V DC) for the external liquid supplies to 9 and 10. If an internal power supply (from the machine) is being used, it can be taken from 1 (N) and connected to 9 and from 2 (L) and connected to 10. Max load on the outputs 0.5 A. -
Page 30: Inputs
Installation manual 6.2.4 Inputs The signal level can be 5-24V DC/AC or 100- 240V AC. For 5-24V, the signal reference is connected to 3 and for 100-240V to 4. Potentials on the inputs cannot be mixed. Note! The I/O board will be damaged if the voltage on connection 3 is too high > 24V. Connection 8 may be connected if the program is to pause, e.g. -
Page 31: Drain Connection
Installation manual 7 Drain connection Connect a 75 mm / 3 inch (50 mm / 1 15/16 inch for models EUD-615, EUD-618, EUD-625) pipe or rubber hose to the machine’s drain pipe, ensuring a downward flow from the machine. Avoid sharp bends which may prevent proper draining. -
Page 32: Electrical Connection
Installation manual 8 Electrical connection 8.1 Electrical installation The electrical installation may only be carried out by qualified personnel. Machines with frequency-controlled motors can be incompatible with certain types of earth leakage circuit break- er. It is important to know that the machines are designed to provide a high level of personal safety, which is why items of external equipment such as earth leakage circuit breakers are not necessary but is recommended. -
Page 33: Electrical Connections
Installation manual 8.2 Electrical connections EUD-615 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 1~ 208-240V 1~ 5.4/7.5 5.7/7.8 30/50 208-240V 3~ 208-240V 3~ 5.4/7.5 5.7/7.8 20/25 440V 3~ 5.4/7.5 5.7/7.8 15/15 480V 3~ 5.4/7.5... - Page 34 Installation manual EUD-645 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 3~ 18.0 18.5 440V 3~ 18.0 18.5 480V 3~ 18.0 18.5 Non heated/Steam heated 208-240V 1~ 440/480V 1/3~ Total power and recommended fuse does not depend on the heating power in those cases. EUD-660 Electrical connections Heating alternative...
-
Page 35: Machine Connection
Installation manual 8.3 Machine connection Connect the earth and other wires as shown. Single-phase connection Three-phase connection 1N/1 L2/N L2 L3... -
Page 36: Machine Connection With Ferrite
Installation manual 8.4 Machine connection with ferrite 8.4.1 EUD-630, EUD-645, EUD-660, EUD-680 To obtain approved level of EMC, it is mandatory to use the ferrite which is enclosed with above listed models. (Note that this is only valid for those models). Before connecting to the machine, the protective earth (PE) wire shall be wrapped around the ferrite. -
Page 37: Functions For I/O-Cards
Installation manual 8.5 Functions for I/O-cards The electrical schematic can be one of the following: 8.5.1 External coin meter/Central payment (2A) The signal received from external coin meters must be a pulse between 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. fig.6606A... -
Page 38: Central Payment (2B)
Installation manual 8.5.2 Central payment (2B) To start the machine from a central payment system, the payment system must transmit a start pulse to the machine. The start pulse can be either 230V or 24V. In order to receive a feedback signal once the machine has started, 230V or 24V must be connected to connection 19. -
Page 39: Central Payment (2C)
Installation manual 8.5.3 Central payment (2C) The central payment or booking system shall transmit an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the machine door is closed but the program has not started. -
Page 40: Outputs For Detergent Signals And Inputs For Pause Signals, "Empty" Signal And Price Reduction (2D)
Installation manual 8.5.4 Outputs for detergent signals and inputs for pause signals, "empty" signal and price reduction (2D) The figure shows standard function addressing for machines with the coin program package. By maintaining an active (high) signal on connection 5 ("Price red"), the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. -
Page 41: Central Booking/Payment (2F)
Installation manual 8.5.5 Central booking/payment (2F) The central payment or booking system shall provide an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the program is running. -
Page 42: Machines With I/O Module Type 3
Installation manual 8.5.6 Machines with I/O module type 3 By maintaining an active (high) signal on connection 3 "Price reduction”, the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. Whilst the sig- nal remains active (high), the price of the program is reduced by the percentage entered in the price programming menu. -
Page 43: Steam Connection
Installation manual 9 Steam connection Inlet pipes connected to the machine must be equipped with a manual shut-off valve to facilitate installation and serv- icing. The connection hose must be of type ISO/1307- 1983 or equivalent. Connection size at filter: DN 15 (BSP 1/2"). Demount the top panel (A). -
Page 44: At First Power Up
Installation manual 10 At first power up When the installation is complete and the power is connected for the first time you will be forced to make the following settings. When one setting is ready you will automatically enter the next one. •... -
Page 45: Function Check
Installation manual 11 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Open the manual water valves. Start a program. •... -
Page 46: Disposal Information
Installation manual 12 Disposal information 12.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. - Page 48 www.electroluxprofessional.com...
