- Page 1 Installation manual Washer extractor H7–55 Type W.55.H 438905433/EN Original instructions 2019.05.21...
-
Page 3: Table Of Contents
Contents Contents 1 Safety Precautions ..........................5 General safety information......................6 Commercial use only........................6 Symbols............................6 2 Technical data.............................7 Drawing ............................7 Technical data ...........................8 Connections ..........................8 3 Setup ..............................9 Unpacking ..........................9 Siting ............................10 Mechanical installation ......................10 4 Water connection ..........................11 5 Connection of external dosing systems ....................11 Connection of the hoses ...................... -
Page 5: Safety Precautions
Installation manual 1 Safety Precautions • Only use detergent intended for water-wash of textiles. Never use dry cleaning agents. • The machine shall be connected with new water hoses. Re-used water hoses must not be used. • The machine's door lock must under no circumstances be bypassed. •... -
Page 6: General Safety Information
Installation manual supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. • Additional requirements for other countries: –... -
Page 7: Technical Data
Installation manual 2 Technical data 2.1 Drawing fig.8025 Operating panel Detergent container Door opening, ⌀ 255 mm Cold water Hot water Drain valve Drain pump Electrical connection Payment system 832* * Adjustable height: 25 mm. -
Page 8: Technical Data
Installation manual 2.2 Technical data Weight, net Drum volume litres Drum diameter Drum speed during wash 35/54 Drum speed during extraction 1450 Drum speed during extraction, Marine model 1300 G-factor, max. G-factor, max. Marine model Heating: Electricity Heating: Hot water Frequency of the dynamic force 24.2 Floor load at max extraction... -
Page 9: Setup
Installation manual 3 Setup 3.1 Unpacking The machine is delivered bolted onto the transport pallet and packed in a crate or box. Remove packing from the machine. Remove the front panel by undoing the two screws on the bottom edge. Remove the rear panel by undoing the screws. -
Page 10: Siting
Installation manual 3.2 Siting Install the machine close to a floor drain or open drain. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. 500 mm / 70 mm / 70 mm /... -
Page 11: Water Connection
Installation manual Place the machine over the two drilled holes. The holes are at the front of the machine. Level the machine with the feet of the machine. Screw in the feet as much as possible before starting to level the ma- chine. -
Page 12: Electrical Connection Of External Dosing System
Installation manual Cut the top of the hose nipples to be used as showed in the figure. Connect the hoses to the hose nipples. fig.5964A Always connect hoses on connections with a hose clamp. If the hoses are made of a soft material such as silikon or similair, use a cable tie to fasten the hose on the connec- tion. -
Page 13: Machine With Connectors
Installation manual 5.2.1 Machine with connectors Connect the external dosing system to connections A and B on the machine. Connect the signal cable to B and the power supply to A. For Efficient dosing system the cables are delivered with the machine. Connect the power supply cable to the machine A and the other end of the cable together with the cable from Effi- cient Dosing in a connection box or with plug and receptacle. -
Page 14: Machine Without Connectors
Installation manual 5.2.2 Machine without connectors Connect the external dosing system to the I/O board, which is located to the right of the incoming power supply. The I/O board has edge connectors for connecting external dosing systems. Edge connectors on the I/O board can be loosened for connecting cables. 11 13 15 17 19 10 12 14 16... -
Page 15: Outputs
Installation manual 5.2.3 Outputs Connect the power supply (e.g. 24V DC) for the external liquid supplies to 9 and 10. If an internal power supply (from the machine) is being used, it can be taken from 1 (N) and connected to 9 and from 2 (L) and connected to 10. Max load on the outputs 0.5 A. -
Page 16: Inputs
Installation manual 5.2.4 Inputs The signal level can be 5-24V DC/AC or 100- 240V AC. For 5-24V, the signal reference is connected to 3 and for 100-240V to 4. Potentials on the inputs cannot be mixed. Note! The I/O board will be damaged if the voltage on connection 3 is too high > 24V. Connection 8 may be connected if the program is to pause, e.g. -
Page 17: Drain Connection
Installation manual 6 Drain connection Drain valve The drainage pipe should be located over a floor drain, drainage channel or the like so that the distance between the outlet and the drain is at least 25 mm. fig.2036 Drain pump The drainage pipe should be located over a floor drain, drainage channel or the like. -
Page 18: Electrical Connection
Installation manual 7 Electrical connection 7.1 Electrical installation The electrical installation may only be carried out by qualified personnel. In accordance with the wiring rules: mount a multi-pole switch prior to the machine to facilitate installation and service operations. Connect the machine’s cable to the switch. Check that the earth has been connected in the correct way. -
Page 19: Machine Connection
Installation manual 7.3 Machine connection The machine can be switched/reconnected to the following options. Connection option 380–415V/3N~ 4.4 kW Electric heated 303B 303A Connection option 380–415V/3~ 4.4 kW Electric heated 303B 303A Connection option 208–240V/3~ 4.4 kW Electric heated 303B 303A Connection option 208–240V/1~ 4.4 kW Electric heated... - Page 20 Installation manual Connection option 208–240V/1~ 2.2 kW Electric heated 303A 303B Connection option 208–240V/1N~ 2.2 kW Electric heated 303B 303A Connection option 100–240V/1N~ Non heated Connection option 100–240V/1~ Non heated Reconnection/switchover of this type can not be performed on machines fitted with a transformer. The machine can not be switched from 50 Hz to 60 Hz or vice versa.
-
Page 21: Functions For I/O-Cards
Installation manual 7.4 Functions for I/O-cards The electrical schematic can be one of the following: 7.4.1 External coin meter/Central payment (2A) The signal received from external coin meters must be a pulse between 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. fig.6606A... -
Page 22: Central Payment (2B)
Installation manual 7.4.2 Central payment (2B) To start the machine from a central payment system, the payment system must transmit a start pulse to the machine. The start pulse can be either 230V or 24V. In order to receive a feedback signal once the machine has started, 230V or 24V must be connected to connection 19. -
Page 23: Central Payment (2C)
Installation manual 7.4.3 Central payment (2C) The central payment or booking system shall transmit an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the machine door is closed but the program has not started. -
Page 24: Outputs For Detergent Signals And Inputs For Pause Signals, "Empty" Signal And Price Reduction (2D)
Installation manual 7.4.4 Outputs for detergent signals and inputs for pause signals, "empty" signal and price reduction (2D) The figure shows standard function addressing for machines with the coin program package. By maintaining an active (high) signal on connection 5 ("Price red"), the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. -
Page 25: Central Booking/Payment (2F)
Installation manual 7.4.5 Central booking/payment (2F) The central payment or booking system shall provide an active (high) signal to the machine once permission has been granted to start the machine. The signal must remain active (high) until the machine starts. A feedback signal will be present on connection 18 and remain active (high) whilst the program is running. -
Page 26: At First Power Up
Installation manual 8 At first power up When the installation is complete and the power is connected for the first time you will be forced to make the following settings. When one setting is ready you will automatically enter the next one. •... -
Page 27: Function Check
Installation manual 9 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Open the manual water valves. Start a program. •... -
Page 28: Disposal Of Packing
Installation manual 10.2 Disposal of packing The packing must be disposed of in compliance with the current regulations in the country where the appliance is used. All the packing materials are environmentally friendly. They can be safely kept, recycled or burned in an appropriate waste incineration plant. Recyclable plastic parts are marked as following examples. - Page 32 Electrolux Professional AB 341 80 Ljungby, Sweden Share more of our thinking at www.wascomat.com...
