CEI-2x10GBASE-T Network Adapter

CEI-2x10GBASE-T

Network Adapter Card for Express-VR7

Page 1

Revision:

1.0

Date:

2024-05-20

Part Number:

50M-79031-1000

User's Guide

PICMG COM.0 R3.1

Table of Contents

Need help?

Do you have a question about the CEI-2x10GBASE-T and is the answer not in the manual?

Questions and answers

Summary of Contents for ADLINK Technology CEI-2x10GBASE-T

Page 1 CEI-2x10GBASE-T Network Adapter PICMG COM.0 R3.1 CEI-2x10GBASE-T User’s Guide Network Adapter Card for Express-VR7 Revision: Date: 2024-05-20 Part Number: 50M-79031-1000 Page 1 Copyright © 2024 ADLINK Technology, Inc.
Page 3: Preface
Product names mentioned herein are used for identification purposes only and may be trademarks / registered trademarks of respective companies. Copyright © 2024 ADLINK Technology Incorporated This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
Page 4 Only install/attach and operate equipment on stable surfaces and/or recommended mountings; • If the equipment will not be used for long periods of time, turn off the power source and unplug the equipment. • Page 4 Copyright © 2024 ADLINK Technology, Inc.
Page 5 Caution: This information indicates the possibility of minor physical injury, component damage, data loss, and/or program corruption. Warning: This information warns of possible serious physical injury, component damage, data loss, and/or program corruption. Page 5 Copyright © 2024 ADLINK Technology, Inc.
Page 6 ADLINK Technology GmbH Hans-Thoma-Strasse 11, D-68163 Mannheim, Germany Tel: +49-621-43214-0 Fax: +49-621 43214-30 Email: emea@adlinktech.com Please visit the Contact page at www.adlinktech.com for information on how to contact the ADLINK regional office nearest you. Page 6 Copyright © 2024 ADLINK Technology, Inc.
Page 7: Table Of Contents
4.1. Input Interface Definitions ..............................................................14 5. Module Interfaces and Configuration ..................................................... 18 5.1. Connector and LED Locations ............................................................18 5.2. LAN LED Behavior.................................................................. 19 5.3. Network Adaptor Card Installation ..........................................................20 6. Mechanical ..............................................................21 Page 7 Copyright © 2024 ADLINK Technology, Inc.
Page 8: List Of Figures
CEI-2x10GBASE-T Network Adapter PICMG COM.0 R3.1 List of Figures Figure 1 – CEI-2x10GBASE-T function diagram .................................................. 13 Figure 2 – Adapter card feature locations .................................................... 18 Figure 3 – Adapter card installation illustration ................................................. 20 Figure 4 – Mechanical dimensions ......................................................21 Page 8 Copyright ©...
Page 9: Introduction
1. Introduction The ADLINK CEI-2x10GBASE-T card is a 10GBASE-T network adapter card that is dedicated to Express-VR7 module. Delivering 10Gbps network within the guidelines of PICMG COM.0 R3.1 specification, the adapter card converts up to two 10GBASE-KR interfaces, and related CEI sideband signals, to two 10GBASE-T interfaces via RJ45 connectors, through Marvell AQR113C PHY and multiple I/O expanders.
Page 10: Specifications
Up to 2x 10GBASE-T interfaces via 2x RJ45 connectors 2.2. 10GbE PHY Marvell AQR113C Converts 10GBASE-KR and sidebands to 10GBASE-T interface PHY Firmware on SPI ROM Dedicated ROM for storing PHY firmware Page 10 Copyright © 2024 ADLINK Technology, Inc.
Page 12: Dimensions
168 mm x 107 mm (PCB only, including edge connector) 2.4. Operating Temperature 0°C to 85°C 2.5. Specification Compliance PICMG COM.0 Rev 3.1 Type 7 2.6. I/O Expander & EEPROM There’re no additional I/O expander and EEPROM required Page 12 Copyright © 2024 ADLINK Technology, Inc.
Page 13: Block Diagram
RJ45 AQR113C connector CEI_MDIO, MDC LED signals CEI_INT# CEI_RST# ETH_PHY_INT# 10G_PHY_MDC_SCL1, SDA1 AQR113C (OEM) RJ45 10G_KR_TX[0] +/- connector LED signals 10G_KR_RX[0] +/- PHY FW SPI ROM Figure 1 – CEI-2x10GBASE-T function diagram Page 13 Copyright © 2024 ADLINK Technology, Inc.
Page 14: Pinout And Signal Descriptions
4.1. Input Interface Definitions The table below is a comprehensible list of all signal pins supported on the 164-pin Edge connector of the CEI-2x10GBASE-T card. Signal names follow the PICMG COM.0 R3.1 specification. Signals described in the specification but not supported on the CEI-2x10GBASE-T card are marked with strikethrough.
Page 15 (or named as 10G_INT0-L on schematic) 10G_PHY_RST_01 10G_KR_RX1+ (or named as L_KR_RX1_P on schematic) 10G_KR_RX1- (or named as L_KR_RX1_N on schematic) 10G_KR_TX1+ (or named as L_KR_TX1_P on schematic) 10G_KR_TX1- (or named as L_KR_TX1_N on schematic) 10G_PHY_MDIO_SDA1 Page 15 Copyright © 2024 ADLINK Technology, Inc.
Page 16 (or named as 10G_PHY_MDIC_SCL0 on schematic) 10G_KR_RX0+ (or named as L_KR_RX0_P on schematic) 10G_KR_RX0- (or named as L_KR_RX0_N on schematic) 10G_KR_TX0+ (or named as L_KR_TX0_P on schematic) 10G_KR_TX0- (or named as L_KR_TX0_N on schematic) Page 16 Copyright © 2024 ADLINK Technology, Inc.
Page 18: Module Interfaces And Configuration
CEI-2x10GBASE-T Network Adapter PICMG COM.0 R3.1 5. Module Interfaces and Configuration This chapter describes connectors, LEDs and switches that are used on the CEI-2x10GBASE-T card. 5.1. Connector and LED Locations Figure 2 – Adapter card feature locations Page 18 Copyright © 2024 ADLINK Technology, Inc.
Page 19: Lan Led Behavior
LED Function LED Color LED State Description Speed Green/Yellow Lower than 1G Green Yellow Status & Activity Yellow No link Steady On Link established, no activity detected Blinking Link established, activity detected Page 19 Copyright © 2024 ADLINK Technology, Inc.
Page 20: Network Adaptor Card Installation
PICMG COM.0 R3.1 5.3. Network Adaptor Card Installation Below is an example (for illustration purposes only) of the CEI-2x10GBASE-T card installed on an Express-BASE7 Plus carrier board with a Type 7 COM Express module. Figure 3 – Adapter card installation illustration Page 20 Copyright ©...
Page 21: Mechanical
CEI-2x10GBASE-T Network Adapter PICMG COM.0 R3.1 6. Mechanical Figure 4 – Mechanical dimensions Note: All dimensions are shown in millimeters with a tolerance of ± 0.25mm unless otherwise noted. Page 21 Copyright © 2024 ADLINK Technology, Inc.
