- Page 1 Manual Gravity Spray Gun Applies for: Model Code PIPI-420X 11749 PSI - Work pressure PIPI-420X Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Contents CAUTION Technical Data To gain the best performance of Pneumatic Requirements the tool, prolong the duty life, make the Warranty valid if Safety Warnings for the Use of Pneumatic Tools necessary, and to avoid hazards of fatal injuries please read and Safety Warnings for the Use of understand this Manual before Spray Guns... -
Page 3: Safety Warnings
Safety Warnings for the Use of Pneumatic Tools Keep your work area clean, tidy and well lit. Use adequate personal protection. CAUTION Cluttered and dark areas may cause accidents. CAUTION Using safety glasses, anti-dust mask, safety non-skid shoes, helmet and earplugs used in adequate conditions Never use the tool in explosive environments considerably reduce the risk of injury. - Page 4 Safety Warnings for the Use of Spray Guns Substances and Materials While operating the device • The unit is designed to apply covering • Never point the sprayer towards your CAUTION CAUTION materials like paint, varnish, enamel, etc. These should body, passersby or animals.
-
Page 5: Parts
Parts Fluid Volume Adjusting Screw Spring Needle Connector Filter Spray Width Adjusting Screw Sprayer Handle Trigger Liquid Nozzle Inlet Wrench Air Inlet Adjusting Screw Brush ENGLISH... -
Page 6: Preparation
Preparation • To get a good job done it is important to prepare the surface to be sprayed. Thin the paint of fluid to get the right viscosity before applying. • Always confirm that the surface to spray is free of dust, dirt and grease. •... -
Page 7: Start Up
Start Up Volume Selector Start up • Turn the screw (A) to adjust the volume of the fluid to be • Start the compressor. sprayed. Turning counterclockwise the volume diminishes • Press the trigger (E) to open the air flow and starts and turning clockwise the volume increases. -
Page 8: Maintenance
Maintenance Cleansing and Care • It is very important to clean the paint gun thoroughly after each use. WARNING Inadequate cleansing will result in malfunctioning and will cancel the Warranty. • Pour the remaining fluid into an adequate container. • Without removing the jar press the trigger to remove all the fluid inside the system. -
Page 9: Troubleshooting
Troubleshooting Right Mist Pattern Problem Cause Solution Wrong • Remove the obstructions from the nozzle. • Paint build up in the nozzle. CAUTION Do not use metal objects Mist to clean the funnel orifices. Patterns: Half Moon • Paint build up in the nozzle or asperser. •... -
Page 10: Notes
Notes Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Made in/Hecho en China. Tel. 761 782 9100. WWW.TRUPER.COM 10-2019 AD...
