- Page 1 Assembly Manual 1/1 th scale road race car kit...
- Page 2 Thank you for choosing another fine road racing machine from the World Champions at Calandra Racing Concepts. The new MetriCKs 1/12th car is the result of well over a year of testing. The MetriCKs is already the 2024 Snowbird, Canadian National and Trinity Shootout Champion.
- Page 3 Battery plate Attach the plastic battery spacers (3013) to the carbon fiber battery plate (3011) with Bag 1 the #1481 M3 x 5 flat head screws. These screws self-thread into the plastic, so use very to upper deck cont little force, no need to crank them. The plastic is there only as a spacer, so they only need to be lightly secured.
- Page 4 Ultra-tune Front End Bag 3 Welcome to the best front end in 1/12th scale racing; The CRC Ultra-tune Front End. 1489 M3 x 6 Button head Use two M3 x 5mm button heads to mount the 4/-1 CC plate to the upper deck. .
- Page 5 Tweak Assembly Build the vertic al dampers ** Bag 5 Snap the 3069 damper pivot ball into the 3070 damper cup. Carefully snap it in with needle nose pliers. Please NOTE the orientation of the ball and the cup as shown to the left before snapping it in. The CRC 4279 “ball popper” tool works great here for installing and removing the damper ball.
- Page 6 If you have any questions or concerns about any CRC product, feel free to call or e-mail the staff at CRC for assistance. All of our in-house staff at CRC are experts in building, setup, driving and racing R/C model cars. Your new MetriCKs was handled by experienced racers from the moment of design right through the completion of the kit.
- Page 7 Name: Event: Track: Date: 3025 Front end fine tuning Rear Axle Ride height can be altered in 2 ways; # of ** -shim under the kingpin Solid ** -shims under the upper plate Ball Diff When changing shims under the kingpin, be Gear Diff sure to make the corresponding spring pre-load Rear track...
- Page 8 Kit Parts Kit Hardware Option Parts 1208 washer 1479 M3 x 5 Flat Head 3005 Aluminum chassis - 2.5mm 1248 Front bearing 1/8 x 5/16 1480 M3 x 6 Flat Head 3006 Carbon upper deck - 3mm 1378 2” Body post w/ collars 1481 M3 x 5 Button Head 3016 2mm rear ride plt - carbon...
