Integral LED ILSENMW001 Installation Instructions

ILSENMW001 MICROWAVE SENSOR 2-IN-1 MOUNT
Thank you for purchasing an INTEGRAL LED product. When installed correctly this unit will provide years of service – with no
replacements required. For support or warranty information please see integral-led.com. Always turn off circuit power at the
distribution unit before installation and maintenance. Please ensure that the power cannot be connected inadvertently.
Important Details – Please read prior to installation
• This sensor must be installed by a qualified electrician in accordance with the instructions provided and in compliance with
recognised electrical and safety regulations relevant to the country it is being installed.
• This is a Class II sensor. Earth connection is not required.
• The input voltage of this sensor is 200-240V~ 50/60Hz
• This sensor is suitable for surface and recess mount. Adequate for installation on surfaces with normal flammability e.g.
wood, masonry. Before making the fixing hole(s), check that there are no obstructions hidden beneath the mounting surface,
such as pipes or cables. Do not use on highly flammable surfaces or in flammable atmosphere.
• This sensor is designed to be installed in a ceiling tile/solid material, with a minimum thickness of 3mm.
• This product is for Indoor use only. It should not be covered with insulation material at any time.
• This product is not suitable for dimming.
• Ensure mains supply is isolated before starting any work.
• Operating Temperature: -20°C to +40°C. Do not exceed.
• Should the unit malfunction, return to distributor or reseller. No user serviceable parts inside. Do not disassemble or attempt
to repair the sensor outside of the installation guidelines.
• Do not install or use the sensor if the housing is found to be broken.
Installation Instructions
• Ensure the AC/mains power is not connected and cannot be reconnected during installation.
• Determine the installation method: surface or recessed. Make sure the fixing devices used are adequate for the substrate where the
sensor will be fixed
Surface mount:
1. Mark the fixing points on the substrate, aligning the cable adequately in the cable entry of the surface bracket.
2. Remove the front bezel cover of the sensor by twisting anti-clockwise (See Fig.1).
3. Pass the cable through the cable entry and fix the surface bracket to the substrate using adequate fixing devices, ensuring the sensor
body can later be securely attached to the surface bracket.
4. Remove the transparent terminal cover, unscrew the connection terminals and connect the Mains power and the Load according to
the wiring diagram (See Fig. 2).
5. Re-install the transparent terminal cover, switch on the Mains power supply and test.
6. Once tested and in good working order, attach the sensor body to the surface bracket and place the front bezel in place with a
clockwise twist
Recess mount:
1. For new installations use cutting tools suitable for the material and carefully cut the required hole to allow installation.
2. For Refurbishment installations ensure that the existing hole is suitable and strong enough to hold the new sensor. Support the
surrounding area if required.
3. Remove the transparent terminal cover, unscrew the connection terminals and connect the Mains power and the Load according to
the wiring diagram (See Fig. 2).
4. Re-install the transparent terminal cover, switch on the Mains power supply and test.
5. Once tested and in good working order, raise the springs, place the sensor into the cut-out ensuring that no power cables are
trapped and position fully into the aperture until sensor is flush to the surface (See Fig.3).
INSTALLATION INSTRUCTION
3 Year Warranty
EN
