4-IN-1 MOUNT PIR MOTION SENSOR
Thank you for purchasing an INTEGRAL LED product. When installed correctly this unit will provide years of service – with no
replacements required. For support or warranty information please see integral-led.com. Always turn off circuit power at the
distribution unit before installation and maintenance. Please ensure that the power cannot be connected inadvertently.
General Safety Instructions
• T his sensor must be installed by a qualified electrician in accordance with the instructions provided and in compliance with
recognised electrical and safety regulations relevant to the country it is being installed.
• This is a Class II sensor. Earth connection is not required.
• The input voltage of this sensor is 220-240VAC, 50/60Hz.
• T his sensor is suitable for Wall, Ceiling, In-Corner and On-Corner surface mount. Adequate for installation on surfaces with
normal flammability e.g. wood, masonry. Before making the fixing hole(s), check that there are no obstructions hidden beneath
the mounting surface, such as pipes or cables. Do not use on highly flammable surfaces or in flammable atmosphere.
• This sensor is designed to be installed on a ceiling tile/solid material, with a minimum thickness of 3mm.
• This product is IP54-rated and suitable for Indoor or Outdoor use.
• This product is not suitable for dimming.
• Ensure mains supply is isolated before starting any work.
• Operating Temperature: -20°C to +40°C. Do not exceed.
• S hould the unit malfunction, return to distributor or reseller. No user serviceable parts inside. Do not disassemble or attempt
to repair the sensor outside of the installation guidelines.
• Do not install or use the sensor if the housing is found to be broken.
Installation Instructions
•
Ensure the AC/mains power is not connected and cannot be reconnected during installation.
•
Determine the installation method and make sure the fixing devices used are adequate for the substrate where the sensor will be fixed.
•
Mark the fixing points on the substrate, aligning the cable adequately in the cable entry of the supplied surface bracket.
•
Remove the front part of the sensor with a slotted head screwdriver using a twisting motion.
•
Pass the cable through the cable entry and fix the surface bracket to the substrate using adequate fixing devices, ensuring the sensor
body can later be securely attached to the surface bracket.
•
Unscrew the connection terminals and connect the Mains power and the Load cables according to the wiring diagram.
•
Install the terminal connector in its position, carefully aligning its slots with the leading plastic pins located inside the surface bracket,
switch on the Mains power supply and conduct a function test.
•
Once tested and in good working order, attach the sensor body to the surface bracket with a gentle push.
Installation Advice
As the detector responds to changes in ambient temperature, avoid the following situations:
•
pointing the detector towards objects with highly reflective surfaces, such as mirrors, windows, etc.
•
mounting the detector near heat sources, such as heating vents, air conditioning units, lights, etc.
•
pointing the detector towards objects that may move in the wind such as curtains, trees or plants.
Manual Override Function
With the sensor in auto detection mode and the light in ON state, if you wish to keep the connected luminaires constantly ON,
simply switch power off and back on twice (OFF-ON-OFF-ON) within 5 seconds. During Override mode, the built-in red indicator
light in the sensor dome will stay on and the connected light(s) will illuminate continuously. Sensor is now in 8-hour override mode.
INSTALLATION INSTRUCTION
ILSENPIR016
DUAL DETECTOR
EN
Advertisement
Related Manuals for Integral LED ILSENPIR016
Summary of Contents for Integral LED ILSENPIR016
- Page 1 DUAL DETECTOR Thank you for purchasing an INTEGRAL LED product. When installed correctly this unit will provide years of service – with no replacements required. For support or warranty information please see integral-led.com. Always turn off circuit power at the distribution unit before installation and maintenance.
- Page 2 After 8 hours the sensor will return to automatic operation mode. To restore PIR sensing capabilities prior to the 8-hour time-out, switch off the power for over 10 seconds and switch back ON again. Remote control function 1.”OPEN SENSOR MODE” button - sensor will operate in a 24-hour mode: 10 sec delay time, 100% distance, no daylight detection threshold. After initial warm up of 30sec, the load and the indicator light should turn on synchronously. In the case of no induction signal received, the load should stop working within 10±3 seconds, the red indicator light will be off, after the first induction signal is received and over, the load will enter working state after 10 ± 3 seconds after any further motion detected. In case of any consecutive motion detected in the meantime, Time-Delay is added continually based on the consecutive motion detections after the initial detection - this will restart the hold time from the moment of last motion detection. After pressing “OPEN SENSOR MODE” button, the following functions can be further selected: • HOLD TIME ZONE delay: 10S, 30S, 5MIN,10MIN, 20MIN, 30MIN. • SENSITIVITY ZONE: LOW button ~ 2M, MEDIUM button ~ 6m, HIGH button ~ 12M. • “ DAYLIGHT LUX ZONE: NIGHT button <10LUX, LOW button ~ 25LUX, MEDIUM button ~ 250LUX, HIGH button ~ 500LUX, DAY/24H button – continuous operation, disregards daylight threshold. 2. Press”OFF POWER LOAD” button turn off the light. 3. P ress”P&S MODE” button to activate Photocell mode, the connected luminaire will turn ON and OFF once to indicate the Photocell function is activated. Natural light under 10 LUX will switch the light ON, and natural light over 150 LUX will switch the light OFF. During operation in this mode, the built-in red indicator light will be ON and OFF in 1- second intervals to indicate operation. Note: Each time a remote button is pressed, the sensor load will toggle between on and off state, indicating that a function has been changed.
- Page 3 b. Please check for obstructions in front of the sensor, affecting the signal reception. c. Please check if the signal source is in the detection field. d. Please check the installation height. The sensor doesn’t switch the load off: a. Check for continual signals in the detection field. b. Check if time delay isn’t set to the longest, adjust setting accordingly. c. Ensure the power connections correspond to the wiring instructions. d. Check if any objects moving in the wind may be triggering the sensor. e. Check if sensor isn’t triggered by nearby heat sources. f. Check surroundings for highly reflective objects. Fig. 01 Fig. 02 Fig. 03 Fig. 04 Fig. 05 Fig. 06 Good sensitivity Poor sensitivity...
- Page 4 Fig. 07 ON POWER LOAD connected luminaire will switch on OFF POWER LOAD OPEN SENSOR MODE connected luminaire will switch off 10sec delay time, 100% detection range, 24H operation (no daylight sensing) OPEN PHOTOCELL MODE activates Photocell <10lux ON / >150lux OFF HOLD TIME 10sec, 30sec, 5min, 10min, 20min, 30min...
