USER MANUAL
EMDCB (REVISION DB)
BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR
EMDCB (Revision DB)
Bluetooth Low Energy Motion Detector And Light Level Sensor
30.11.2018
Observe precautions! Electrostatic sensitive devices!
Patent protected:
WO98/36395, DE 100 25 561, DE 101 50 128,
WO 2004/051591, DE 103 01 678 A1, DE 10309334,
WO 04/109236, WO 05/096482, WO 02/095707,
US 6,747,573, US 7,019,241
© 2024 EnOcean | www.enocean.com
EMDCB User Manual | v2.0 | August 2024 | Page 1/56
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EnOcean EASYFIT EMDCB
Summary of Contents for EnOcean EASYFIT EMDCB
- Page 1 WO98/36395, DE 100 25 561, DE 101 50 128, WO 2004/051591, DE 103 01 678 A1, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 1/56...
- Page 2 As far as patents or other rights of third parties are concerned, liability is only assumed for modules, not for the described applications, processes and circuits. EnOcean does not assume responsibility for use of modules described and limits its liability to the replacement of modules determined to be defective due to workmanship. Devices or systems containing RF components must meet the essential requirements of the local legal authorities.
-
Page 3: Table Of Contents
Backup battery interface ................22 Product label ....................22 Radio transmission ..................23 Radio channel parameters ................23 Default radio transmission sequence .............. 24 © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 3/56... - Page 4 Waste treatment .................. 46 11.2 FCC (United States) ..................47 11.2.1 FCC (United States) certificate............... 47 11.2.2 FCC (United States) regulatory statement ..........48 © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 4/56...
- Page 5 Receiver configuration ................. 54 A.1 Scanning parameters ................... 54 A.1.1 Advertising interval .................. 55 A.1.2 Scan window ................... 55 A.1.3 Scan interval................... 56 A.1.4 Summary ....................56 © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 5/56...
-
Page 6: General Description
BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR General description This document describes EMDCB in product revision DB. For documentation about previous revisions of EMDCB, please contact EnOcean. Basic functionality EMDCB is a ceiling-mounted motion and illumination sensor that reports its status using Bluetooth Low Energy (BLE) advertising telegrams. -
Page 7: Technical Data
113,2 mm L x 65,5 mm W x 30,7 mm H Dimensions (4.46” L x 2.58” W x 1.21” H ) CE / RED (EU) FCC (US) Approvals ISED (Canada) ARIB (Japan) © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 7/56... -
Page 8: Environmental Conditions
36.5 °C / 98 F. Packaging information Packaging Unit 12 units Packaging Method Box / pallet Ordering information Type Ordering Code Frequency 2.4 GHz (BLE) EMDCB-W-EO E6221-K515:DB © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 8/56... -
Page 9: Functional Description
BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR Functional description EMDCB product overview The energy harvesting ceiling-mounted motion and illumination sensor EMDCB from EnOcean provides wireless motion and illumination sensing functionality without batteries. Power is provided by a built-in solar cell harvesting available light from the environment. -
Page 10: Basic Functionality
PIR lens) that together can be used for simple configuration and test activities. The internal NFC antenna (not visible from the outside) provides access to the NFC configu- ration interface. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 10/56... -
Page 11: Internal Product Interface
(or similar) with the opening slot. If the EMDCB wall mount plate is already attached to the ceiling, then EMDCB can be removed by gently pulling the housing. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 11/56... -
Page 12: Functional Modes
Walk test mode can only be executed if the energy store of EMDCB is sufficiently charged. Alternatively, a backup battery can be fitted for the duration of the walk test mode. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 12/56... -
Page 13: Illumination Test Mode
Factory reset is triggered by pressing and holding the LRN button for more than 7 seconds as described in chapter 4.2 or by using the NFC interface as described in chapter 9. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 13/56... -
Page 14: Reporting Interval
(2 minutes). This interval can be adjusted using the NFC interface as described in chap- ter 9. Figure 4 below illustrates the use of the unoccupied reporting interval. UNOCCUPIED_TX_INTERVAL UNOCCPUIED_TX_INTERVAL Figure 4 – Unoccupied reporting interval © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 14/56... -
Page 15: Occupied Reporting Interval
Figure 5 below illustrates the use of the occupancy-controlled reporting interval. Immediately STANDARD_TX_INTERVAL OCCUPIED_TX_INTERVAL OCCUPIED_TX_INTERVAL OCCUPIED_TX_INTERVAL STANDARD_TX_INTERVAL Figure 5 – Occupied versus unoccupied reporting interval © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 15/56... -
Page 16: Illumination-Controlled Reporting Interval
If more than one condition for a lower reporting interval applies – e.g. if a room is both oc- cupied and brightly lit – then the lowest of the corresponding reporting intervals will be se- lected. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 16/56... -
Page 17: Sensor Functionality
3 m (10 ft). Figure 7 below shows the PIR detection pattern. Figure 7 – EMDCB PIR detection pattern © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 17/56... -
Page 18: Illumination Measurement
The solar cell has been factory calibrated for universal use and offers a wide field of view and a broad spectral sensitivity, covering LED, fluorescent, incandescent and natural light sources with a light level between 0 and 1000 lux. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 18/56... -
Page 19: Energy Level
By default, the backup battery voltage is reported if a backup battery is present. Otherwise, the energy level of the internal energy store is reported instead. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 19/56... -
Page 20: User Interface
If in Standard Operation Mode: Send Commissioning Telegram 2 blink green If in Sleep Mode: Wake up to Standard Operation Mode Send Commissioning Telegram 2 blink green © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 20/56... -
Page 21: Lrn Button Timing Indication
One short red blink after 3 seconds Very long > 7 seconds Two short red blinks after 7 seconds Table 2 – LED timing indication © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 21/56... -
Page 22: Sensitivity Selection Switch
Backup battery interface The backup batter interface allows supplying EMDCB by means of a CR2032 battery in case the available ambient light is insufficient for energy harvesting operation. EnOcean recom- mends using Renata batteries due to their low self-discharge characteristics. -
Page 23: Radio Transmission
Custom Radio Channel 2405 MHz Custom Radio Channel … 2477 MHz Custom Radio Channel 2479 MHz Custom Radio Channel Table 3 – EMDCB supported radio channels © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 23/56... -
Page 24: Default Radio Transmission Sequence
The default interval setting is 20 ms; an alternative setting of 10 ms can be configured by using the NFC interface as described in chapter 9. Figure 10 – Default radio transmission sequence © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 24/56... -
Page 25: User-Defined Radio Transmission Sequences
One-channel sequence ◼ In this sequence the radio telegram is transmitted using nine transmissions on one radio channel. It is described in chapter 5.3.3 below. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 25/56... -
Page 26: Three-Channel Sequence
CH_REG1 CH_REG2 CH_REG1 CH_REG2 CH_REG1 CH_REG2 (20 ms or 10 ms) (20 ms or 10 ms) Figure 12 – Two channel radio transmission sequence © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 26/56... -
Page 27: One-Channel Sequence
10 ms can be configured by using the NFC interface as described in chapter 9. INTERVAL INTERVAL CH_REG1 CH_REG1 CH_REG1 (20 ms or 10 ms) (20 ms or 10 ms) Figure 13 – Single channel radio transmission sequence © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 27/56... -
Page 28: Telegram Format
Figure 15 below shows specific properties used by EMDCB within the general BLE advertising frame structure. Figure 15 – BLE frame structure The content of these fields is described in more detail below. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 28/56... -
Page 29: Preamble
EMDCB uses by default Static Source Address mode. Resolvable Private Address mode can be selected by using the NFC interface as described in chapter 9. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 29/56... -
Page 30: Static Source Address Mode
By default, EMDCB uses static source addresses meaning that the source address is constant during normal operation. The structure of EMDCB static addresses is as follows: The upper 2 bytes of the source address are for EnOcean Bluetooth sensors always ◼ set to 0xE500 to enable filtering according to product type The lower 4 bytes are uniquely assigned to each device. -
Page 31: Resolvable Private Address Mode
So conceptually the IRK takes the role of the device source address while prand and hash provide a mechanism to select the correct IRK among a set of IRK. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 31/56... -
Page 32: Check Sum
The 3 byte BLE Check Sum is used to verify data integrity of received BLE radio telegrams. It is calculated as CRC (cyclic redundancy check) of the BLE Header, Source Address and Payload fields. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 32/56... -
Page 33: Payload
BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR Payload The payload of EnOcean BLE sensor data telegrams can be up to 31 bytes long (depending on the size of the sensor data) and consists of the following fields: Length (1 byte) ◼... -
Page 34: Sensor Status Encoding
In this case, the sensor can use the length information provided by this field to determine the start of the next sensor descriptor field (which might contain usable data). © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 34/56... -
Page 35: Data Size
65 533 (Enabled by default) unsigned int Optional Data 0x3C 0, 1, 2, 4 User-defined data (Disabled by default) Table 4 – Supported parameters © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 35/56... -
Page 36: Telegram Authentication
EMDCB and only accepts messages with higher sequence counter values (i.e. not accepts equal or lower se- quence counter values for subsequent telegrams). © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 36/56... -
Page 37: Authentication Implementation
Figure 25 – Authenticated payload The calculated 32 bit signature is then appended to the data telegram payload as shown in in chapter 6.6 © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 37/56... -
Page 38: Commissioning
EMDCB radio tele- grams. NFC commissioning ◼ Each EMDCB device contains an NFC interface allowing to read device parameters and to configure the device. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 38/56... -
Page 39: Radio-Based Commissioning
EMDC to a receiver. Figure 26 shows an example of such QR code. Figure 26 – EMDCB Commissioning QR code © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 39/56... -
Page 40: Commissioning Qr Code Format
Part 2 and 3 standards. The device address and the security key of EMDCB can be read by using the NFC interface as described in chapter 9. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 40/56... -
Page 41: Nfc Interface
The default pin code shall be changed to a user-defined value as part of the installation process. This can be done by using the NFC interface as described in chapter 0. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 41/56... -
Page 42: Using The Nfc Interface
NFC functionality is available in most Android (e.g. Samsung Galaxy S7 or newer) and iOS (starting from iPhone7 with firmware version 13 or newer) smartphones. EnOcean provides the configuration app “EnOcean Tool” for these devices which can be downloaded directly from the respective app store. -
Page 43: Installation Recommendations
For consistent detection, the mounting site of EMDCB should not be exposed to vibrations or motion. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 43/56... -
Page 44: Illumination Measurement
Consider using the light level reported by the solar cell as an alternative approach if meas- uring a light level over a wider area is desired. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 44/56... -
Page 45: Energy Harvesting
NFC configuration interface by changing the NFC PIN code from its default value to a different (secret) value. Make sure the new PIN code is properly noted down. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 45/56... -
Page 46: Regulatory Notes
11.1.1 Declaration of conformity Hereby, EnOcean GmbH, declares that this radio equipment is in compliance with the essen- tial requirements and other relevant provisions of Directive 2014/53/EU. A copy of the Dec- laration of Conformity can be obtained from the product webpage at www.enocean.com... -
Page 47: Fcc (United States)
USER MANUAL EMDCB (REVISION DB) BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR 11.2 FCC (United States) 11.2.1 FCC (United States) certificate © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 47/56... -
Page 48: Fcc (United States) Regulatory Statement
Thus, EMDCB containing the TCM 515B radio module can be operated in the United States without additional Part 15 FCC approval (approval(s) for unintentional radiators may be re- quired for the OEM’s finished product), under EnOcean’s FCC ID number if the OEM require- ments are met. -
Page 49: Fcc Oem Requirements
BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR 11.2.4 FCC OEM requirements In order to use EnOcean’s FCC ID number, the OEM must ensure that the following conditions are met: The Original Equipment Manufacturer (OEM) must ensure that FCC labeling require- ◼... -
Page 50: Ised (Industry Canada)
USER MANUAL EMDCB (REVISION DB) BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR 11.3 ISED (Industry Canada) 11.3.1 ISED (Industry Canada) certificate © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 50/56... -
Page 51: Ised (Industry Canada) Regulatory Statement
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.” © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 51/56... -
Page 52: Arib (Japan)
USER MANUAL EMDCB (REVISION DB) BLUETOOTH LOW ENERGY MOTION DETECTOR AND LIGHT LEVEL SENSOR 11.4 ARIB (Japan) 11.4.1 ARIB certificate © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 52/56... -
Page 53: Product History
Addition of adaptive reporting via solar cell and light sensor DB-09 August 2024 All functional modes now selectable via NFC Change from single-color to bi-color LED Table 6 – Product History © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 53/56... -
Page 54: Receiver Configuration
Duration for which the receiver will scan within each scanning cycle Figure 28 below illustrates these three parameters. Advertising Interval Time Scan Interval Scan Window Time Figure 28 – Scanning parameters © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 54/56... -
Page 55: A.1.1 Advertising Interval
10 ms (advertising interval) plus 0.5 ms (telegram duration) plus a timing margin to account for the random time offset at the transmitter. Using a scan window of at least 13 ms is recommended for this case. © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 55/56... -
Page 56: Scan Interval
Receiver Scan Interval Advertising Interval (Minimum) (Maximum) 10 ms 23 ms 37 ms 20 ms 13 ms 17 ms Table 7 – Recommended receiver scan settings © 2024 EnOcean | www.enocean.com EMDCB User Manual | v2.0 | August 2024 | Page 56/56...
