- Page 1 Rail Pressure Tester RPT-5 User manual Please read carefully before using the device. Ignorance of this manual may result in damage to the device or components operated by it.
-
Page 2: Table Of Contents
RPT-5 Tester – User manual Table of contents 1. Device parameters........................3 2. Appearance and connection.....................3 2.1 Charging the device......................4 3. Using the device........................4 3.1 Sensor test.........................5 3.2 External sensor (option)....................7 4. Android app..........................9 6. Troubleshooting........................10 © DeltaTech Electronics 2024 Ver.2.1... -
Page 3: Device Parameters
RPT-5 Tester – User manual 1. Device parameters Power supply: built-in Li-ion battery Operating time approx. 8 hours when fully charged Charging connector: 5V, 500mA Operating conditions: temp. 0 – 40°C Voltage measurement: 0..7V External sensor power supply: 5V, max 50mA Do not connect the tester outputs to any voltage sources other than the circuits of the tested sensors. -
Page 4: Charging The Device
RPT-5 Tester – User manual Measuring cable connector – it is used to connect the measuring cable. Mini USB connector – it is used to charge the device's battery and also allows connection to a computer to update the software. [ ] –... -
Page 5: Sensor Test
RPT-5 Tester – User manual battery symbol ( ). If the symbol is visible next to it, it means that the Bluetooth module is active and it is possible to communicate with a compatible device mobile. After starting, the device will go to the main menu. Use [▲] and [▼] buttons to select a chosen function and[OK] to confirm. - Page 6 RPT-5 Tester – User manual Press [OK] to display the option menu: Pressure trend Choose Pressure trend to display the low-speed sampling pressure waveform. Pressure trend screen: The vertical scale of the graph can be changed using the [ ▲] and [▼] buttons. The scale of the time axis is fixed and amounts to 2s/division.
-
Page 7: External Sensor (Option)
RPT-5 Tester – User manual connecting the additional sensor under 3.2 External sensor . During the measurement, the sensor on the rail is connected in parallel to the tester and the tested system (motor controller, test bench), while the additional sensor (external) is connected only to the tester. - Page 8 RPT-5 Tester – User manual test. The setting of new parameters is only necessary when changing the used external sensor. To set the sensor parameters (before the first use) : 1. Select Menu → Settings → External sensor 2. Specify the type of system: CR - Common Rail (Diesel), GDI - Gasoline (also FSI). 3.
-
Page 9: Android App
RPT-5 Tester – User manual Version It displays the device software version. To go back to the previous menu press 4. Android app It is possible to extend the capabilities of the device through cooperation with a dedicated application. To download the application, use the link: http://auto-testers.com/download/rpt/ To download the program it is necessary to provide the serial number of the device. -
Page 10: Troubleshooting
RPT-5 Tester – User manual First connection: • Select a Bluetooth device by selecting Settings → Bluetooth. • When pairing devices, enter the PIN number 7785 (shown in the device menu). All program data is saved in the device's main memory in the RPT5_DATA folder. To back up the database, you must make a copy of this folder. - Page 11 RPT-5 Tester – User manual conducting any workshop activities always conform to vehicle service manuals, applicable laws, regulations, provisions, as well as industrial safety and fire protection rules. The DeltaTech Electronics company shall not be liable for possible damage caused by improper use of the RPT-5 tester.
