SEC/SY/06/24/FM1 PARIS 1 DRAWER BEDSIDE ASSEMBLY INSTRUCTIONS DO NOT FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
SEC/SY/06/24/FM1 PART LIST Part Number Part Code Part Description Quantity Carton S100-103-101-FM1-01 Top Panel S100-103-101-FM1-02 Side Panel (Le ) S100-103-101-FM1-03 Side Panel (Right) S100-103-101-FM1-04 Drawer Front S100-103-101-FM1-05 Drawer Side Panel (Le ) Drawer Side Panel (Right) S100-103-101-FM1-06 Shelf Panel S100-103-101-FM1-07 Crossbar Panel S100-103-101-FM1-08 Drawer Back Board...
SEC/SY/06/24/FM1 HARDWARE LIST Part Name Carton Wooden Dowel 8 x 25mm Plastic Foot Nail x2 Sets Mini Fix 15mm Single Plastic Cap Screw M3.5 x 14mm Screw M4 x 38mm FH Screw M5 x 40mm x1 Set Drawer Metal Slide 350mm TIPS FOR FITTINGS CAM-LOCKS WHEN FITTING CAM NUT.
SEC/SY/06/24/FM1 STEP 1 PARTS REQUIRED TOP PANEL SHELF PANEL CROSSBAR PANEL HARDWARE REQUIRED 8x25mm TOOLS REQUIRED To Assemble the Drawer Slide, Please Follow Step as Below To Assemble the Drawer Slide, Please Follow Step as Below STEP 2 4th to Last Hole First Hole First Hole 4th to Last Hole...
Page 5
SEC/SY/06/24/FM1 STEP 3 PARTS REQUIRED TOP PANEL SIDE PANEL (RIGHT) SHELF PANEL HARDWARE REQUIRED M5x40mm TOOLS REQUIRED STEP 4 PARTS REQUIRED SIDE PANEL (RIGHT) CROSSBAR PANEL HARDWARE REQUIRED M5x40mm TOOLS REQUIRED Page 05...
Page 6
SEC/SY/06/24/FM1 STEP 5 PARTS REQUIRED Hit Softly BACK PANEL HARDWARE REQUIRED TOOLS REQUIRED STEP 6 PARTS REQUIRED Hit Softly HARDWARE REQUIRED TOOLS REQUIRED Page 06...
Page 7
SEC/SY/06/24/FM1 STEP 7 PARTS REQUIRED DRAWER FRONT DRAWER SIDE (LEFT) DRAWER SIDE (RIGHT) HARDWARE REQUIRED 8x25mm TOOLS REQUIRED STEP 8 PARTS REQUIRED DRAWER SIDE (LEFT) DRAWER SIDE (RIGHT) DRAWER BACKBOARD HARDWARE REQUIRED M4x38mm TOOLS REQUIRED Page 07...
Page 8
SEC/SY/06/24/FM1 STEP 9 Nail it after assemble PARTS REQUIRED DRAWER FRONT DRAWER BOTTOM PANEL HARDWARE REQUIRED TOOLS REQUIRED Slot in Lock 2nd Insert Right position STEP 10 PARTS REQUIRED HARDWARE REQUIRED TOOLS REQUIRED Page 08...
Page 9
SEC/SY/06/24/FM1 STEP 11 PARTS REQUIRED HARDWARE REQUIRED TOOLS REQUIRED Roller STEP 12 Stand PARTS REQUIRED HARDWARE REQUIRED TOOLS REQUIRED Insert drawer Page 09...
