Axis Camera Station S11 Series User Manual

Racked recorder

Hide thumbs Also See for Camera Station S11 Series:

User manual (39 pages)

Table Of Contents

Quick Links

Download this manual

AXIS Camera Station S1116 Racked Recorder

User manual

Table of Contents

Need help?

Do you have a question about the Camera Station S11 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Axis Camera Station S11 Series

Page 1 AXIS Camera Station S1116 Racked Recorder User manual...
Page 2: Table Of Contents
Configure AXIS Camera Station ........
Page 3: About Your Device
Camera Station video management software including licenses plus all necessary system software. The system configuration can easily be imported from AXIS Site Designer, and AXIS Camera Station lets you take full advantage of Axis wide range of video surveillance devices. With redundant enterprise-grade hard disks, operating system stored on solid-state drive (SSD), the recorder series provides high-performance and reliability for your system.
Page 4: Get Started
If your system is offline: go to axis.com and download the latest version. 6. Register you AXIS Camera Station licenses. 7. Connect your system to the AXIS Camera Station mobile viewing app. See Configure AXIS Secure Remote Access To watch this video, go to the web version of this document.
Page 5 AXIS Camera Station S1116 Racked Recorder Install your device Install your device...
Page 6 AXIS Camera Station S1116 Racked Recorder Install your device...
Page 7 AXIS Camera Station S1116 Racked Recorder Install your device...
Page 8 AXIS Camera Station S1116 Racked Recorder Install your device...
Page 9 AXIS Camera Station S1116 Racked Recorder Install your device...
Page 10 AXIS Camera Station S1116 Racked Recorder Install your device...
Page 11 AXIS Camera Station S1116 Racked Recorder Install your device...
Page 12 AXIS Camera Station S1116 Racked Recorder Install your device...
Page 13: Configure Your Device
If your device is not connected to a network or there is no DHCP server available, enter the IP address, subnet mask, gateway, and preferred DNS manually depending on the network requirements. 4. Click Finish. If you have changed the computer name, AXIS Recorder Toolbox will prompt you to restart the device. Configure AXIS Camera Station This Get started tutorial will walk you through the basic steps to make your system up and running.
Page 14 Start the video management system Double-click the AXIS Camera Station client icon to start the client. When you start the client for the first time, it attempts to log in to the AXIS Camera Station server installed on the same computer as the client.
Page 15: Network Configuration
See Signed video and the camera’s user manual for more information. Network configuration Configure proxy or firewall settings before using AXIS Camera Station if the AXIS Camera Station client, AXIS Camera Station server, and the connected network devices are on different networks. Client proxy settings When a proxy server separates the client and the server, configure the client proxy settings.
Page 16: Server Port Configuration
When a NAT, firewall, or similar separates the client and the server, configure the NAT or firewall to ensure that the HTTP port, TCP port, and streaming port specified in AXIS Camera Station Service Control can pass through the firewall or NAT. Contact the network administrator for instructions on configuring the NAT or firewall.
Page 17 11. Under License keys, click Download license file and save the file to a USB flash drive. 12. In AXIS Camera Station client, go to Configuration > Licenses > Management. 13. Click Import license file and select the license file on your USB flash drive.
Page 18: Manage Windows® User Accounts
AXIS Camera Station S1116 Racked Recorder Manage Windows® user accounts Manage Windows® user accounts Create a user account To help keep your personal data and information more secure, we recommend that you add a password for each local account. Important Once you create a password for a local account, don't forget it.
Page 19: Change A User Account's Password
AXIS Camera Station S1116 Racked Recorder Manage Windows® user accounts 1. Go to Settings > Accounts > Other people. 2. Go to the account you want to remove and click Remove. Change a user account's password 1. Log in with an administrator account.
Page 20: Manage Axis Camera Station User Accounts
Manage AXIS Camera Station user accounts Manage AXIS Camera Station user accounts Configure user permissions Go to Configuration > Security > User permissions to view the users and groups that exists in AXIS Camera Station S1116 Racked Recorder. Note Administrators of the computer that runs AXIS Camera Station S1116 Racked Recorder server are automatically given administrator privileges to AXIS Camera Station S1116 Racked Recorder.
Page 21: User Or Group Privileges
Operator - Select cameras, views, and I/O ports to get access to live and recorded. An operator has full access to all functionality of AXIS Camera Station S1116 Racked Recorder except system configuration. Viewer - Access to live video of selected cameras, I/O ports, and views. A viewer doesn’t have access to recorded video or system configuration.
Page 22 The following access privileges are available for users or groups with the Operator or Viewer role. You can select multiple views and set the access privileges. Access Allow access to the views in AXIS Camera Station S1116 Racked Recorder. Edit Allow to edit the views in AXIS Camera Station S1116 Racked Recorder.
Page 23 AXIS Camera Station S1116 Racked Recorder Manage AXIS Camera Station user accounts Configuration of system health monitoring Allow configuration of the system health monitoring system. Access to system health monitoring Allow access to the system health monitoring system.
Page 24: Manage Your Device
AXIS Camera Station S1116 Racked Recorder Manage your device Manage your device Update Windows® Windows® periodically checks for updates. When an update is available, your device automatically downloads the update but you've to install it manually. Note Recording will be interrupted during a scheduled system restart.
Page 25: Configure Raid
Physical Disks. Note Only RAID 0 and RAID 1 are available on the AXIS S1116 MT recorders because there is only physical space for an additional single drive. 2. In the Intel(R) Rapid Storage Technology menu, select Create RAID Volume and press ENTER.
Page 26 AXIS Camera Station S1116 Racked Recorder Manage your device 5.3 Repeat until you have selected all the disks you want to use. 6. Leave Stripe Size and Capacity to the default values unless specified. 7. Select Create Volume and press ENTER.
Page 27: Troubleshooting
4. After the ISO to USB tool is complete, take the USB drive and plug it into your device. 5. Start your device and before the AXIS splash screen appears press F12. We recommend that you tap the F12 key repeatedly as the device boots fast.
Page 28: Product Overview
AXIS Camera Station S1116 Racked Recorder Product overview Product overview Front and rear sides Hard drive slot Universal audio jack USB 3.1 Type-C USB 3.1 SD card reader Drive activity LED System power LED/power button USB 3.1 Type-C/DisplayPort™ Remote power switch connector...
Page 29 AXIS Camera Station S1116 Racked Recorder Product overview Power supply unit indicators Description Green A valid power source is connected to the PSU and the PSU is operational. Blinking amber Indicates a problem with the PSU Not illuminated Power is not connected.
Page 30: Need More Help
Need more help? Need more help? Useful links • AXIS Camera Station user manual • Configure Axis Secure Remote Access • What to include in an Antivirus allowlist for AXIS Camera Station Contact support If you need more help, go to axis.com/support.
Page 31 User manual Ver. M7.2 AXIS Camera Station S1116 Racked Recorder Date: October 2024 © Axis Communications AB, 2019 - 2024 Part no. T10133057...
