- Page 1 RevivalDRIVE Switcher Interface User Guide...
- Page 2 RevivalDRIVE Switcher Interface User Guide www.origineffects.com ORIGIN EFFECTS is a trademark of Origin Effects Limited and is a registered trademark in the United States, United Kingdom, China and the EU. The ORIGIN EFFECTS Totem Device is a trade mark of Origin Effects Limited and is a registered trademark in the United States, China and United Kingdom.
- Page 3 Safety Instructions: Intended use: This device is intended for use as an controller expansion for the Origin Effects RevivalDrive pedal. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
- Page 4 RevivalDRIVE Switcher Interface User Guide Introduction The RevivalDRIVE Switcher Interface allows a remote switching system, such as the GigRig G2 or Boss ES-8, to remotely toggle the following functions on the RevivalDRIVE pedal: Active channel Bypass state Mid engage Blend override functions The unit works by converting the four latching control switches to the combination of latching and momentary switching used by the RevivalDRIVE.
-
Page 5: Appendix A - Connections
RevivalDRIVE Switcher Interface User Guide event of power loss, the user may find that switcher-to-pedal synchronisation is lost. To re-sync the set- up the user should toggle the affected function directly on the pedal, by pressing the appropriate footswitch. Appendix A - Connections... -
Page 6: Appendix B - Physical Specification
RevivalDRIVE Switcher Interface User Guide Appendix B – Physical Specification BOXED UNBOXED WEIGHT 185 g 0.40 lb 184 g 0.40 lb LENGTH 130 mm 5.11 inch 115 mm 4.53 inch WIDTH 85 mm 3.34 inch 65 mm 2.56 inch HEIGHT 50 mm 1.96 inch... -
Page 7: Appendix E - Warranty
Appendix E – Warranty This product is covered by a 2-year manufacturer’s warranty from the date of purchase. This applies only to original purchasers who have bought their product from an authorised Origin Effects dealer or directly from Origin Effects.
