  • Page 1 RevivalDRIVE Switcher Interface User Guide V1.0...
  • Page 2 RevivalDRIVE Switcher Interface User Guide Introduction The RevivalDRIVE Switcher Interface allows a remote switching system, such as the GigRig G2 or Boss ES-8, to remotely toggle the following functions on the RevivalDRIVE pedal: Active channel Bypass state Mid engage Blend override functions The unit works by converting the four latching control switches to the combination of latching and momentary switching used by the RevivalDRIVE.
  • Page 3 Provides a 9V DC centre negative “daisy-chain” power barrel connection. 2.1mm Connects an external power supply. 9VDC IN barrel Provides power to unit. 9VDC, centre negative. Connects to F/SWITCH socket on RevivalDRIVE. OUTPUT Controls pedal functions. Page 3 of 4...
  • Page 4 RevivalDRIVE Switcher Interface User Guide Appendix B – Physical Specification BOXED UNBOXED WEIGHT 185 g 0.40 lb 184 g 0.40 lb LENGTH 130 mm 5.11 inch 115 mm 4.53 inch WIDTH 85 mm 3.34 inch 65 mm 2.56 inch HEIGHT 50 mm 1.96 inch...
