- Page 1 EzDecap Automated Screw Cap Decapper BRDC-0000 Operation Manual Ver. 2.0 Copyright © 2024 Blue-Ray Biotech Corp. All Rights Reserved.
-
Page 2: Table Of Contents
Table of Contents Safety Precautions ..............1 1.1 Intended Use..............1 1.2 General Safety ..............1 Product Overview ..............2 Installation ................2 Operation Modes ..............2 Decapping / Capping ............. 3 Cycle Time Setting ..............4 Transportation and Storage ..........5 Maintenance ................ -
Page 3: Safety Precautions
Use of the instrument in a manner, or for purposes not specified by Blue-Ray Biotech, may result in personal injury or damage to the instrument. Using the device in a manner not specified by Blue-Ray Biotech may result in personal injury or damage to the device. -
Page 4: Product Overview
Do not place this device where it is difficult to disconnect the power adapter. Product Overview Installation Plug the USB-C jack of the power adapter into the USB-C socket on the back of the device. Plug the power adapter into an external power source. Operation Modes Five operation modes satisfy users with various needs for decapping and capping screw caps. -
Page 5: Decapping / Capping
Indicator Mode Action Cap Only Capping the cap on the top of the tube Decap and Decapping and releasing cap after 1.5 sec Release Decapping / Capping Press the power button for 3 seconds to turn on the device. Press the power button to select the mode. If the cap is too tight, it may need to be manually loosened firstly. -
Page 6: Cycle Time Setting
Cycle Time Setting The EzDecap is built with 3 different cycle times for selection to accommodate most tubes. “Shorter time” setting provides express operation, while “Longer time” setting is for the tubes needing longer cycle time. Follow the procedures to set the cycle time. Press the power button for 3 seconds to turn on the device. -
Page 7: Transportation And Storage
Decapping Cycle Capping Cycle Setting Time (sec) Time (sec) Setting 2- Shorter time Setting 3- Longer time Use a tube again to press up on the center of the disc to trigger the motor and complete the setting. Note The cycle time setting will be kept after rebooting the EzDecap Transportation and Storage This device should be transported and stored in an environment with a temperature between -10 and 60 °C and with a relative humidity of 20 - 80%... -
Page 8: Maintenance
Follow local municipal waste ordinances for proper disposal provisions to reduce the environmental impact of waste electrical and electronic equipment (WEEE). European Union Customers: Call your local Blue-Ray Biotech Distributor’s Customer Service office for device pick-up and recycling. -
Page 9: Appendix A: Technical Specifications
Appendix A: Technical Specifications Dimensions 170 x 240 x 300 mm (W x D x H) Weight 3.8 kg Cycle Time < 3 sec Decap/Cap Compatibility 11 - 40 mm diameter screw cap tubes Sensing Method Pressure sensor Operation Modes Five modes Input: AC100 - 240 V, 50/60 Hz;... -
Page 10: Appendix B: Ce Declaration
Appendix B: CE Declaration BLUE-RAY BIOTECH CORP. 5F., No. 2, Aly. 2, Siwei Ln., Zhongzheng Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) Declaration of Conformity Product Name: EzDecap Model Names: BRDC-0000 All models comply with the following European standards:... -
Page 11: Appendix C: Order Information
Appendix C: Order Information Order No. Description EzDecap BRDC-0000 Automated Screw Cap Decapper BRDC-a001 Gripper set... - Page 12 For more information, visit www.blue-raybio.com EzDecap Product Webpage Blue-Ray Biotech Corp. 5F., No. 2, Aly. 2, Siwei Ln., Zhongzheng Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) P/N: 401-DCBR00-20...
