Defender BLAZE GM-148 Operation Manual

OPERATION MANUAL
Wireless/Wired Gaming Mouse
ИНСТРУКЦИЯ ПОЛЬЗОВАТЕЛЯ
Беспроводная/ проводная игровая мышь
BLAZE GM-148
EN Wireless/Wired Gaming Mouse
OPERATION MANUAL
1. Wired mode connection.
Please plug in the cable to the mouse with Type C connector and with PC
or Notebook with USB connector.
IMPORTANT: regardless of the position of the switch on the bottom of
the mouse (2.4G/OFF/BT), when connected via the cable, this mode is
considered a priority.
The mouse will connect to your device in wired mode automatically.
2. Bluetooth mode connection.
For "wireless Bluetooth" mode connection please move the switch on the
bottom of the mouse to the "BT" position.
Turn on Bluetooth mode on the device you want to connect the mouse
to. Then chose the device name "Blaze" in the list of the available devices
for connection.
To reconnect to your computer or laptop in Bluetooth mode, please
repeat all the steps described above.
Bluetooth channel has version 5.1
3. Wireless 2.4Ghz connection.
For wireless 2.4G mode connection please move the switch on the bottom
of the mouse to the "2.4G" position and insert the receiver into computer.
The mouse will paired automatically.
IMPORTANT: In case you use several mice working with your device via
2.4G mode, then need to press and hold the left + right + middle (scroll
wheel) buttons for 3 seconds for paring the mouse with the receiver. The
indicator at the bottom of the mouse flash yellow when paired via
2.4GHz radio channel.
To reconnect to your computer or laptop in 2.4G mode, please repeat all
the steps described above.
4. Resetting the mouse settings.
Press left + right + 2 side buttons (backward & forward) for 3 seconds to
reset the settings.
5. To turn off the mouse.
Please move the switch to the "OFF" position (middle position).
6. DPI changing
To change the mouse resolution, click on the button at the bottom of the
case (on the right).
Available mouse resolution modes: 800/1200/1600/2400/5000/26000
dpi. Each resolution mode has a corresponding indicator light:
red/green/blue/yellow/cyan/purple.
Default DPI 1200
7. Charging
To charge the built-in battery, connect the mouse to your computer or
laptop using a USB-Type C cable.
8. Indicator for charging (between left and right buttons)
During charging, the indicator flashes red, after fully charged, the
indicator stops flashing.
EN Wireless/Wired Gaming Mouse
OPERATION MANUAL
Declaration of Conformity
Operation of device (devices) may be affected by strong static, electrical or high-frequency
fields (radio installations, mobile telephones, microwaves, electrostatic discharges)/ If
occurs, Try increasing the distance from the devices causing the interface.
Disposal of batteries, electrical and electronic equipment
This sign on the product, its batteries or package indicates that the product
cannot be disposed together with domestic waste. It should be delivered to an
appropriate batteries, electrical and electronic equipment collecting and
recycling company.
Terms and conditions of safe and efficient use of the product
Usage precautions:
1. Use the product for its intended purpose only.
2. Do not disassemble. This product does not contain parts that are entitled to self-
sufficient repair. On the question of maintenance and replacement of a failed item apply
to a dealer or Defender authorized service center. While receiving the product make sure
that it is unbroken and there are no freely moving objects inside the product.
3. Keep away from children under the age of 3. May contain small parts.
4. Keep away from humidity. Never immerse the product in liquids.
5. Keep away from vibrations and mechanical stresses, which can cause mechanical
damaging of the product. In case of mechanical damage, no warranties are provided.
6. Do not use in the presence of visual damage. Do not use when the product is obviously
defective.
7. Do not use the product at temperatures below and above recommended temperatures
(see the operation manual), under the conditions of humidity evaporation, as well as in
hostile environment.
8. Do not put into the mouth.
9. Do not use the product for industrial, medical or manufacturing purposes.
10. In case when shipment of the product was conducted in subzero temperatures, then
before operating, the product should be kept in a warm placement (+16-25°C or 60-77°F)
within 3 hours.
11. Turn off the device each time, when it is not planned to use it for extended period of
time.
12. Do not use the device while driving the vehicle, if it is diverted attention, and in other
cases when the law obliges you to turn off the device.
Product specifications and features can be found on the packaging and on defender-
global.com
Importer: Defender Technology OÜ, Betooni str 11, 11415, Tallinn, Estonia.
Manufacturer: STARWAVE TECHNOLOGY CO., LIMITED. Address: 15/F Huaide International
Bld, No.73 Guangshen Rd Fuyong Segment, Fuyong Boulevard Bao'an District, Shenzhen,
China.
Unlimited shelf life. Service life is 2 years. Date of manufacture: see on the package
Manufacturer keeps the right to change package contents and specifications indicated in
this manual. The latest and detailed operation manual is available at www.defender-
global.com
Date of manufacture: see on the package. Made in China.
Warranty service is not effected in the following situations:
1. Expiration of the warranty period (warranty period is settled from the date of sale to the
end user).
2. Incorrect filling in of the warranty card.
3. Incorrect plug in to power grid.
4. Breach to safety of guarantee seals, fixing joint assemblies of the case; presence of
elements of opening on outside and inside parts of the product.
5. If the product designed for household use was used for professional purposes.
6. Damage due to penetration of foreign objects, substances, liquids or insects inside the
product.
7. Damage due to breach to normal work of supply network – 220V +/- 10%. (except of
automatic voltage regulators)
8. If the product was opened and repaired by a person unauthorized for that by the dealer.
9. Incorrect operation or careless handling.
10. Damage to the product due to natural disasters.
11. Presence of elements indicating mechanical damage (fall, hit).
12. Disability of connected devices of other producers.
