Defender Annex GM-038 Operation Manual

OPERATION MANUAL
Wireless/Wired Gaming Mouse
ИНСТРУКЦИЯ ПОЛЬЗОВАТЕЛЯ
Беспроводная/ проводная игровая мышь
Annex GM-038
EN Wireless/Wired Gaming Mouse
OPERATION MANUAL
1. Wired mode connection.
Please connect the cable to the Type C connector of the mouse, and the
USB connector to the PC or laptop.
The mouse will connect to your device in wired mode automatically.
2. Bluetooth mode connection.
Please move the switch on the bottom to the "ON" (up) position.
Then for "wireless Bluetooth" mode connection please make a long
press for DPI button to turn on the BT mode. The LED indicator near the
DPI button will light with blue.
After that press left+right+middle(Scroll) buttons for 3 seconds to enter
the pairing status. The LED indicator will flash with blue light.
Turn on Bluetooth mode on the device you want to connect the mouse
to. Then chose the name of mouse "Annex GM-038" in the list of the
available devices for connection.
To reconnect to your computer or laptop in Bluetooth mode, please
repeat all the steps described above.
Bluetooth channel has version 5.1
3. Wireless 2.4Ghz connection.
Please move the switch on the bottom to the "ON" (up) position.
Then for wireless 2.4G mode connection pleaseplease make a long press
for DPI button to turn on the 2.4G mode. The LED indicator near the DPI
button will light with red. Then Insert the receiver into computer. The
mouse will work normally.
In case if the receiver loses the wireless connection then press left + right
+ scroll wheel buttons for 3 seconds for reset settings and pairing.
To reconnect to your computer or laptop in 2.4G mode, please repeat all
the steps described above.
4. To turn off the mouse.
Please move the switch to the "OFF" (down) position. To turn on the
mouse please move the switch to the "ON" (up) position.
5. DPI changing
To change the mouse resolution, short press the button at the bottom of
the case (on the left side).
Available mouse resolution modes: 800/1600/2400/3200/4800/12000
dpi.
Default DPI 1600
6. Сharging
To charge the built-in battery, connect the mouse to your computer or
laptop using a USB-Type C cable.
EN Wireless/Wired Gaming Mouse
OPERATION MANUAL
Declaration of Conformity
Operation of device (devices) may be affected by strong static, electrical or high-frequency
fields (radio installations, mobile telephones, microwaves, electrostatic discharges)/ If
occurs, Try increasing the distance from the devices causing the interface.
Disposal of batteries, electrical and electronic equipment
This sign on the product, its batteries or package indicates that the product
cannot be disposed together with domestic waste. It should be delivered to an
appropriate batteries, electrical and electronic equipment collecting and
recycling company.
Terms and conditions of safe and efficient use of the product
Usage precautions:
1. Use the product for its intended purpose only.
2. Do not disassemble. This product does not contain parts that are entitled to self-
sufficient repair. On the question of maintenance and replacement of a failed item apply
to a dealer or Defender authorized service center. While receiving the product make sure
that it is unbroken and there are no freely moving objects inside the product.
3. Keep away from children under the age of 3. May contain small parts.
4. Keep away from humidity. Never immerse the product in liquids.
5. Keep away from vibrations and mechanical stresses, which can cause mechanical
damaging of the product. In case of mechanical damage, no warranties are provided.
6. Do not use in the presence of visual damage. Do not use when the product is obviously
defective.
7. Do not use the product at temperatures below and above recommended temperatures
(see the operation manual), under the conditions of humidity evaporation, as well as in
hostile environment.
8. Do not put into the mouth.
9. Do not use the product for industrial, medical or manufacturing purposes.
10. In case when shipment of the product was conducted in subzero temperatures, then
before operating, the product should be kept in a warm placement (+16-25°C or 60-77°F)
within 3 hours.
11. Turn off the device each time, when it is not planned to use it for extended period of
time.
12. Do not use the device while driving the vehicle, if it is diverted attention, and in other
cases when the law obliges you to turn off the device.
Product specifications and features can be found on the packaging and on defender-
global.com
Importer: Defender Technology OÜ, Betooni str 11, 11415, Tallinn, Estonia.
Manufacturer: Zodic Technology Co., Ltd. Address: Building 301, Lushi Industrial Building,
Zone 28, Dalang Community, Xin'an Street, Bao'an District, Shenzhen, China.
Unlimited shelf life. Service life is 2 years. Date of manufacture: see on the package
Manufacturer keeps the right to change package contents and specifications indicated in
this manual. The latest and detailed operation manual is available at www.defender-
global.com
Date of manufacture: see on the package. Made in China.
Warranty service is not effected in the following situations:
1. Expiration of the warranty period (warranty period is settled from the date of sale to the
end user).
2. Incorrect filling in of the warranty card.
3. Incorrect plug in to power grid.
4. Breach to safety of guarantee seals, fixing joint assemblies of the case; presence of
elements of opening on outside and inside parts of the product.
5. If the product designed for household use was used for professional purposes.
6. Damage due to penetration of foreign objects, substances, liquids or insects inside the
product.
7. Damage due to breach to normal work of supply network – 220V +/- 10%. (except of
automatic voltage regulators)
8. If the product was opened and repaired by a person unauthorized for that by the dealer.
9. Incorrect operation or careless handling.
10. Damage to the product due to natural disasters.
11. Presence of elements indicating mechanical damage (fall, hit).
12. Disability of connected devices of other producers.
