Envision
INSTALLATION AND SETUP
This is a guide for all GTXpro /Bulk and GTX600 NB/SB users in relation to use Envision on the printer.
The beamer bracket and the beamer must have been mounted beforehand.
CONTENT
1
2
3
1 CONNECTION
Connect the projector to the computer and follow the instruction manual of the projector,
delivered with the beamer. (Instructions may be different with each beamer model.)
The target is to have the projector connected to the PC and identified by the operating system as
additional monitor.
To avoid any problems please make sure that the automatic Keystone (Trapezoid) correction is off.
Usually, this can be set up in the projector menu.
Make sure the source is set to HDMI.
2 WINDOWS SETTINGS
EXTEND THE DESKTOP
2.1
After connecting the beamer open the display settings and set the display mode to
"Extend these displays"like shown below.
This will allow you to use this extended space for Envisioning.
We share our experience to give you the
1
4
1
1
2
5
3
best support
4
4
7
8
8
8
9
1 / 9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Brother Envision GTXpro
Summary of Contents for Brother Envision GTXpro
-
Page 1: Table Of Contents
Envision We share our experience to give you the best support INSTALLATION AND SETUP This is a guide for all GTXpro /Bulk and GTX600 NB/SB users in relation to use Envision on the printer. The beamer bracket and the beamer must have been mounted beforehand. CONTENT CONNECTING THE PROJECTOR SET UP... -
Page 2: Set Screen Scale And Resolution
A: Open the System folder. B: Select “Multiple displays”. C: Set “Extend these displays” from dropown. SET SCREEN SCALE AND RESOLUTION Calibration will not work if the screen is scaled D: Please set the screen scaling of both Displays to 100%. ... -
Page 3: Installation
3 INSTALLATION Please plug the Envision Dongle into the USB port of your computer. Open the Envision Drive, locate install.exe and run it. Follow the prompts in the installation tool. 1: It is very important to install drivers from the dongle if needed. -
Page 4: Set Up
4 SET UP The target of calibration is to synchronise the projected picture with the printed graphics. A calibration process needs to be done each time the physical projector position changes. CALIBRATION Attach your largest platen to the printer and place a white shirt on the platen. Choose platenheight ... - Page 5 Biggest Platen: Please choose the biggest platen on which you would like to print. All smaller sizes are included inside this area. Projection Monitor: Select the output monitor (usually it is Monitor 2) Calibration Matrix: Click on “Print Calibration“. ...
- Page 6 Mark the 4 corners of the print by mouse click. Marked corner A calibration image will be projected. The To achieve congruence between projection black areas of the projection have the same and print, you must activate the corners of the shape as the white areas of the print: projection one after the other and set the exact position of each corner by using the arrow keys.
-
Page 7: Options
OPTIONS Projection Brightness: When set to 0 on left side a full color image will be projected. Increasing to the right side the image will covered with white. According to the light conditions at your place you define your setting. Realtime Control should be activated. -
Page 8: Using Envision
It is possible to fine tune the position of the file print. For this the original png print file is necessary because the file has to be ripped again. It is required that the original file (filename.png) is in the same folder as the existing Brother print file. ... -
Page 9: Update
The new position of the motif can be confirmed by clicking on ENTER. The ripping process will start automatically and integrate the settings of the Brother file and also the new position.
