Summary of Contents for CARDIO STRONG TX30
- Page 1 Assembly and Operating Instructions max. 130 kg ~ 30 Min. 88 kg L 178 | W 89 | H 147 FSUKCSTTX30.02.02 SKU: CST-TX30-2 Treadmill TX30...
- Page 2 TX30...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Rotary Knob Media Management Mode Training Programmes 3.6.1 Pre-Set Programmes 3.6.2 User-Defined Programmes 3.6.3 Body Fat Test Heart Rate Controlled Programmes Lubrication Reminder Function Power Safe Function... - Page 4 5.4.1 Adjusting the Running Mat 5.4.2 Re-tensioning the Running Mat 5.4.3 Lubricating the Running Mat Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT TX30...
- Page 5 Dear customer, thank you for choosing fitness equipment from cardiostrong®. cardiostrong offers high-quality home fitness equipment that is optimally adapted to the conditions at home. Train at home no matter what the weather or time of the day. cardiostrong fitness equipment offers training programmes and a variety of equipment for all training levels and all training goals.
- Page 6 (person with legal responsibility). Class H (home use): use at home. These stationary training devices are intended for the use in private homes where access to the training device is regulated by the owner (person with legal responsibility). TX30...
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ࣑...
-
Page 8: General Information
18 mm Running mat size in cm (L x W): 140 x 51 Motor: Minimum speed: 0.8 km/h Maximum speed: 18 km/h Speed interval: 0.1 km/h Incline: 0 % - 12 % Incline interval: Mains supply: Motor type: Use class: TX30... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Electrical Safety
The software systems on gym equipment with TFT consoles are set up only for the pre- installed apps. Do not install any additional apps. NOTICE The pre-installed apps on TFT consoles are produced and provided by external manufacturers. Fitshop does not take any responsibility for the availability, functionality or contents of these apps. TX30... -
Page 11: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Make sure that there is a safety area behind the treadmill with a length of at least 2 m and a width at least equal to the width of the treadmill. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 12: Assembly
To prevent damage to the equipment and the floor, assemble the equipment on a mat or packaging board. NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. TX30... -
Page 13: Scope Of Delivery
Scope of Delivery ⚠ WARNING There is a transportation lock that prevents the treadmill from opening during transport. This transportation lock must be removed before assembly. The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. -
Page 14: Assembly
Acrobat Reader programme must be installed on your end device in order to open the file. Step 1: Removing the Packaging Remove the main frame (A) and the console (B) from the packaging. Inspect the components for damage and completeness. TX30... - Page 15 Step 2: Folding out the Upright Tubes Fold the left and right upright tube (A06 & A07) into a vertical position. Secure the position of the left and right upright tube (A06 & A07) on the sides with one bolt (D07) and one washer (D28) each.
- Page 16 Secure the console (B) to the left and right upright tube (A06 & A07) with two bolts (D12), two spring washers (D29) and two washers (D32) each. Use the Allen key (B06). Tighten all screws firmly. D12 M8*15 (4X) B06 6# (1X) D29 Ø8 (4X) D32 Ø8 (4X) TX30...
- Page 17 Step 4: Removing the first Transport Lock Cut through the transport lock. ࣑ CAUTION Material damage due to incorrect tools Do not use a carpet knife for cutting. Material damage may result. Use safety scissors to release the transport lock.
- Page 18 Step 5: Removing the second Transport Lock Loosen the transport lock (a) on the lower side of the treadmill belt. Use the Allen key (B05). B05 5# (1X) TX30...
- Page 19 Step 6: Attaching the Covers Attach the left and right upright tube cover (C07 & C08) to the side of the treadmill with three bolts (D39) each. Use the screwdriver (B04). D39 M5*10 (6X) B04 S=13, 14, 15 (1X)
- Page 20 Step 7: Attaching the EMERGENCY STOP Key Attach the EMERGENCY STOP Key (C19) to the console. Ensure that all screws are tightened. → The treadmill is now fully assembled. TX30...
- Page 21 Step 8: Alignment of the feet If the floor is uneven, you can stabilize the treadmill by turning the two setting screws under the main frame. ⚠ WARNING The treadmill is equipped with high-pressure shock absorbers that can cause the treadmill to suddenly open if handled incorrectly.
-
Page 22: Operating Instructions
To enable the safety key to detach from the contact point of the cockpit in the event of a fall, the safety key clip must be firmly attached to your clothing! Make sure that the safety key is not accessible to children. TX30... -
Page 23: Console Display
Console Display Parameter Function TIME Displays the training time. INCLINE Displays the incline. Display and setting range: 0-12 % (in 1 increments). CALORIES Displays the burned calories. Displays the speed. SPEED Display and setting range: 0.8-18 km/h (in 0.1 increments). PULSE Displays the heart rate. -
Page 24: Button Functions
Press the rotary knob to start the training in standby mode. To pause the training, press the rotary knob. The training data will be kept. NOTICE Short press the rotary knob to pause the training. Long press the rotary knob to stop the training. TX30... -
Page 25: Media Management
To continue the training, short press the rotary knob. NOTICE The kept training data will be used for the remaining time. The set speed is 0.8 km/h. The set incline is 0 %. To adjust the speed, turn the rotary knob. 4.1. -
Page 26: Training Programmes
Once the progarmme ends, the device sounds three times and the device stops. TIME TIME INTERVAL= setting time/16 PROG 15 16 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE TX30 SPEED INCLINE SPEED INCLINE SPEED... -
Page 27: User-Defined Programmes
SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE 3.6.2 User-Defined Programmes This device contains 3 user-defined programmes. In Standby Press PROG. 3 user-defined programmes appear on the console. Choose a user-defined programme. To set the training time, press on SPEED +/-, INCLINE +/- or turn the rotary knob. NOTICE The user-defined programmes are devided into 16 segments. -
Page 28: Body Fat Test
In Standby Press on PROG until HP1 and HP2 appear on the display. Choose a programme. NOTICE The maximum speed of HP1 is 10 km/h. The maximum speed of PH2 is 12 km/h. To enter your age, press MODE. TX30... - Page 29 NOTICE The default age on the display is 30 (AG:30). To enter your age, press on SPEED +/- or INCLINE +/-. NOTICE The device recommends you a heart rate suited for your entered age. To enter your heart rate, press on MODE. To adjust your desired heart rate, press on SPEED +/- or INCLINE +/-.
-
Page 30: Lubrication Reminder Function
The device has a reminder function that reminds you to lubricate the device after 300 kilometres. A sound will appear every 10 seconds and OIL appears on the display. NOTICE After you have lubricated the treadmill, press the “Stop” button for three seconds. → The lubrication reminder disappears. TX30... -
Page 31: Power Safe Function
Power Safe Function In standby the device will enter the power safe function after 10 minutes of inactivity. To exit the power safe function, press on a button on the console. 3.10 Power Switch The on/off switch is loctaed at the back of the device. NOTICE Switch the device off if you are not using it for a longer period of time. -
Page 32: Wireless Connection And Fitness Apps
Just follow the instructions on the screen to perform the update. Please note: The system is set up only for the pre-installed apps. Do not install any additional apps as their proper functionality can not be guaranteed. The installation of other apps might cause technical issues. Example: Kinomap TX30... -
Page 33: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 34: Folding Up The Treadmill
To release the hydraulic brake lock, use your left foot to push the upper part of the hydraulic brake slightly forward until the lock releases and the treadmill can be pulled back. Keep holding the treadmill. The hydraulic brake lowers itself gently downwards. Once the treadmill has lowered 2/3, you can let go of the treadmill. TX30... -
Page 35: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 36: Error Codes And Troubleshooting
Check the motor, for strange noises or a burning smell . Lubricate the device. E06 Motor failure: Check whether the wires of the motor are connected correctly. Please contact the contract partner for technical support. TX30... -
Page 37: Care And Maintenance
Care and Maintenance The most important maintenance measure is the care of the running mat. This includes adjustment, re tensioning and lubrication of the running mat. Damage resulting from insufficient or neglected care is not covered by the warranty. You should therefore carry out maintenance checks at regular intervals. -
Page 38: Re-Tensioning The Running Mat
Continue turning the belt by hand so that the entire surface between the endless belt and the running plate is lubricated. Wipe off the excess silicone oil or silicone spray. NOTICE This maintenance must also be carried out after prolonged non-use of the equipment. TX30... -
Page 39: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Tension of the running mat Lubrication of the running mat... -
Page 40: Recommended Accessories
Of course, you can also contact our customer service: by telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise you! chest strap floor mat lubricant handrails TX30... -
Page 41: Ordering Spare Parts
The serial number of your equipment is unique. It’s located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: cardiostrong / treadmill Model Name: TX30 SKU: CST-TX30-2... -
Page 42: Parts List
Motor top cover Motor bottom cover Back end cover Adjustable wheel cover Side rail Panel turning sleeve Left upright tube cover Right upright tube cover Console top cover Console bottom cover Console left side cover Console right side cover TX30... - Page 43 Left handle bar Right handle bar Console cover adapter block Panel top cover Panel bottom cover Holder Safety key clip Side rail tension seat Running belt Cushion Cushion Transport Wheel Adjustable wheel Plastic gasket Ring protective plug Foot pad Cylindrical cushion Adjustable foot pad Safety key base Safety key...
- Page 44 Bolt Bolt Bolt Bolt Bolt Bolt Bolt Bolt Bolt Bolt Screw Screw Screw Screw Screw Lock washer Lock washer Lock washer Spring washer Big washer Screw Flat washer Screw Bolt Screw Lock washer Spring washer Screw Bolt DC motor TX30...
- Page 45 Incline motor Switch on-off Power socket Overload protector Magnetic ring Magnetic core Power wire AC signal wire AC signal wire AC signal wire Ground wire Running board Console Control board Left touch button board Right touch button board Switch knob Console top signal wire Console bottom signal wire Hand pulse top signal wire...
- Page 46 USB module USB connecting wire TX30...
-
Page 47: Exploded Drawing
Exploded Drawing... - Page 48 TX30...
-
Page 49: Warranty
WARRANTY Products from cardiostrong® are subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. Error Descriptions Your fitness equipment is developed for long-term, high-quality training. - Page 50 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. TX30...
-
Page 51: Contact
CONTACT �� �� �� TECHNIK TEKNIK OG SERVICE CUSTOMER CARE �� +49 4621 4210-900 80 90 16 50 +44 141 737 2249 or �� �� +44 141 876 3972 �� +49 4621 4210-945 +49 4621 4210-698 �� �� info@fitshop.dk customercare@fitshop.co.uk ��... - Page 52 The company employs numerous sports scientists, fitness trainers and competitive athletes. Visit us also on our social media platforms or our blog! TX30...
- Page 53 Notes...
- Page 54 Notes TX30...
- Page 56 Treadmill TX30...
