- Page 1 PICKLEBALL MACHINE INSTRUCTION MANUAL ZH-3802PBH Please read the user manual carefully before using this product and keep it properly.
-
Page 2: Table Of Contents
CONTENT PRECAUTIONS---------------------------------------------------------------------- SPECIFICATION--------------------------------------------------------------------- PARTS DESCRIPTION------------------------------------------------------------- PACKAGE CONTENT--------------------------------------------------------------- INSTALLATION----------------------------------------------------------------------- MACHINE INSTALLATION-------------------------------------------------------- SWING BASE INSTALLATION--------------------------------------------------- DRY BATTERIES INSTALLATION----------------------------------------------- FEATURES --------------------------------------------------------------------------- BASIC TROUBLESHOOTING---------------------------------------------------- WARRANTY & CUSTOMER SERVICE---------------------------------------- WARRANTY--------------------------------------------------------------------------- CUSTOMER SERVICE------------------------------------------------------------... -
Page 3: Precautions
PRECAUTIONS Thank you very much for choosing Furlihong. Before using your Furlihong pickleball machine, please take a moment to review the following important safeguards to ensure safe and optimal operation: • Do not use it in the rain or near dust or salt spray. -
Page 4: Parts Description
Top Tracks x 1 6V Connector x 1 Swing Base x 1 AC Adaptor x 1 Screw Driver x 1 Please make sure all parts are complete before use. If any items are missing or damaged, please contact us at services@furlihong.com. -
Page 5: Installation
INSTALLATION MACHINE INSTALLATION Note Please gently squeeze the ball tracks if they are out of shape. Step ❸ Top Track ❸ Place the top track onto it, and ensure the ball tracks are firmly snapped into position. Step ❷ ❷ Assemble the ball tracks one and the other. -
Page 6: Swing Base Installation
SWING BASE INSTALLATION Use the Velcro strap to secure the swing base and machine and fasten them. Connect the power plug from the machine to the swing base to transmit power. Please follow the arrows to properly secure or unsecure the power plug. Turn on the button to activate the swing mode. -
Page 7: Dry Batteries Installation
DRY BATTERIES INSTALLATION ※ The battery box is at the bottom of the machine. ※ Please turn off the machine before putting in the batteries. Unscrew the lid with a screwdriver. Assemble the battery according to the positive "+" and negative "-" signs. - Page 8 Note If you choose to use a power bank to charge the machine, please use the included 6V connector to connect the machine to the power bank. • The output of the power bank must be at least 2A. Tips for Use: 1.Please use dry balls instead of wet ones, as the machine may not operate properly otherwise.
-
Page 9: Features
FEATURES The wheel angle adjustment switch (On both left & right of the machine) The wheel speed adjustment switch (On both left & right of the machine) Angle adjustment knob Spinning Modes By adjusting different speeds on the left and right sides of the machine at the same time, the ball can spin left or right: ●... - Page 10 By simultaneously adjusting the left and right wheels in different directions, the machine can launch different curve balls: ● Adjust the wheel on the left to "Up" and the wheel on the right to "Down", and the machine can launch curve balls as shown in Figure 3. ●...
- Page 11 Angle Adjustment Knob Tripod Connectivity You can secure the machine on a camera tripod and adjust the height freely. The screw hole on the bottom of the machine is compatible with a standard camera tripod. H OFF H OFF H OFF...
-
Page 12: Basic Troubleshooting
BASIC TROUBLESHOOTING PROBLEMS REASONS SOLUTIONS Doesn't drop Ball chutes not Reinstall for full connection. installed correctly. ball. Low batteries. Replace with fresh ones. Power out. Damaged power adapter. Replace with new one. Inadequate machine Ensure sufficient power/voltage. power/voltage. Insufficient launch height/distance. -
Page 13: Warranty & Customer Service
WARRANTY Warranty Coverage: Your Furlihong pickleball machine is backed by a 12-month warranty against defects in materials and workmanship. This warranty ensures your satisfac- tion and peace of mind with your purchase. - Page 14 Scan the QR code to access the website instantly.
