- Page 1 TENNIS PITCHING MACHINE INSTRUCTION MANUAL ZH-3807BH Please read the user manual carefully before using this product and keep it properly.
-
Page 2: Table Of Contents
CONTENT PRECAUTIONS----------------------------------------------------------------------- SPECIFICATION--------------------------------------------------------------------- PARTS DESCRIPTION------------------------------------------------------------- PACKAGE CONTENT--------------------------------------------------------------- INSTALLATION----------------------------------------------------------------------- MACHINE INSTALLATION--------------------------------------------------------- SWING BASE INSTALLATION---------------------------------------------------- DRY BATTERIES INSTALLATION----------------------------------------------- BUMPER UNIT INSTALLATION-------------------------------------------------- FEATURES ---------------------------------------------------------------------------- BASIC TROUBLESHOOTING---------------------------------------------------- WARRANTY & CUSTOMER SERVICE ---------------------------------------... -
Page 3: Precautions
PRECAUTIONS Thank you very much for choosing Furlihong. Before using your Furlihong tennis machine, please take a moment to review the following important safeguards to ensure safe and optimal operation: • Do not use it in the rain or near dust or salt spray. -
Page 4: Parts Description
Bumper Unit Set X 1 9V Connector x 1 Swing Base x 1 Portable Bag x 1 Screw Driver x 1 Please make sure all parts are complete before use. If any items are missing or damaged, please contact us at services@furlihong.com. -
Page 5: Installation
INSTALLATION MACHINE INSTALLATION Note: Assembly of the machine must be performed by adults. Note：Please gently squeeze the ball tracks if Top Track they are out of shape. ❸ Step ❸ Place the top track onto it, and ensure the ball tracks are firmly snapped into position. -
Page 6: Swing Base Installation
SWING BASE INSTALLATION Secure the swing base to machine. Connect the power plug from the machine to the swing base to trans- mit power. Please follow the arrows to properly secure or unsecure the power plug. Turn on the button to activate the swing mode. (High/Low Speed Adjustable) -
Page 7: Dry Batteries Installation
DRY BATTERIES INSTALLATION ※ The battery box is at the bottom of the machine. ※ Please turn off the machine before putting in the batteries. Unscrew the lid with a screwdriver. Please put batteries by following the positive and negative signs shown in the battery box. -
Page 8: Bumper Unit Installation
Tips for Use: 1. Use dry balls only; wet balls may cause the machine to malfunction. 2. Allow the machine to start and reach full speed before feeding the balls fully. Gradually increase from the lowest to the highest speed. 3. -
Page 9: Features
FEATURES Auto Height Adjusting Mode The ball can automatically move vertically by turning off the machine’s auto height adjustment switch. • Serving height: 1ft to 11ft • Serving distance: 13ft to 52ft Oscillating Mode The machine’s automatic oscillating base has two adjustable speeds, H and L, which can increase training difficulty and improve pickleball skills. -
Page 10: Basic Troubleshooting
Tripod Connectivity You can secure the machine on a camera tripod and adjust the height freely. The screw hole on the bottom of the machine is compatible with a standard camera tripod. NOTE: The bumper unit must be uninstalled before mounting the tripod. BASIC TROUBLESHOOTING PROBLEMS REASONS... -
Page 11: Warranty & Customer Service
Here's what you need to know about our warranty and how to reach us for assistance: Warranty Coverage: Your Furlihong tennis machine is backed by a 12-month warranty against defects in materials and workmanship. This warranty ensures your satisfac- tion and peace of mind with your purchase. - Page 12 Scan the QR code to access the website instantly.
