Portable Badminton Pitching Machine
Parts content
Shuttlecocks holder 2
Machine 1
Launch point
Tripod connectivity
Battery box screws holes
Please use screw drive to excute
Use 4 "D"batteries
Shuttlecocks in
Leave all the Furlihong shuttlecocks
in the holder, additional accessories
can be purchased at our brand store.
(Only use small shuttlecocks )
White shuttlecocks 4
Orange LED shuttlecocks 2
Purple LED shuttlecocks 2
Screw driver 1
AC adaptor 1
How to assemble
Combine 2 holders as below and attach to the machine
Launch frequency adjustment
Speed lauch from 3s to 6s
Angle adjustment knob
AC adaptor port
ON/OFF switch
Please keep this instruction well
The machine only uses Furlihong shuttlecocks
Assemble as shown
Hold 20 shuttlecocks maximum
How to adjust angle
4 differences angle
Please use left hand to pull the pin out meanwhile
steady the holder by right hand.
Push the pin in for the demanding angle.
Note
Squeeze gently the leaf if it out of shapes
Please replace by new one if it's broken,
ZH-23803BH
User instruction
Handle
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Furlihong ZH-23803BH
Summary of Contents for Furlihong ZH-23803BH
- Page 1 ZH-23803BH Portable Badminton Pitching Machine User instruction Please keep this instruction well Parts content The machine only uses Furlihong shuttlecocks White shuttlecocks 4 Orange LED shuttlecocks 2 Purple LED shuttlecocks 2 Shuttlecocks holder 2 Screw driver 1 Machine 1 Assemble as shown...
