TJAmerican TJ02-28V3022BE Use And Care Manual

30" vanity in natural wood finish withblack carrara quartz top
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL #TJ02-28V3022BE
USE AND CARE GUIDE
30" VANITY IN NATURAL WOOD FINISH WITH
BLACK CARRARA QUARTZ TOP
Questions, problems, missing parts?
Before returning, contact us on:
info@tjamerican.com
TJAMERICAN.COM
THANK YOU
We appreciate the trust and confidence you have placed in TJAmerican LLC through the purchase
of this Vanity.
Visit us online to see our full line of products available for your home improvement needs.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TJ02-28V3022BE and is the answer not in the manual?

Questions and answers

Related Manuals for TJAmerican TJ02-28V3022BE

Summary of Contents for TJAmerican TJ02-28V3022BE

  • Page 1 Before returning, contact us on: info@tjamerican.com TJAMERICAN.COM THANK YOU We appreciate the trust and confidence you have placed in TJAmerican LLC through the purchase of this Vanity. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Instruction......................2 Care and Maintenance........................3 Specification............................4 Replacement Parts List........................5 Package Contents..........................6 Assembly............................7 Warranty..........................12 SAFETY INFORMATION DANGER: Please read and understand this entire manual before attempting to assemble, operate, or install the product. Keep small parts away from children during assembly. Failure to follow warning and cautions could result in serious injury.

  • Page 3: Care And Maintenance

    Follow up by cleaning the stone with a mild non-abrasive soap and water. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton during shipment. If parts are missing, contact TJAmerican LLC to obtain any missing parts.

  • Page 4: Specification

    SPECIFICATION 11" 4" 4" 11" 18,3" " thread 0,4" 4,9" 0,9" 18,3" 13,4" U-Shaped Ø2,6" Shelf Ø1,7" 7,1" 15,7" 7,1" SINK HANDLE 30" TOP VIEW 22" 30" 0,75" 12,1" 12,1" 7,7" 17,7" 29,1" 21,5" FRONT VIEW SIDE VIEW 29,9" 4,5" 4,5"...

  • Page 5: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, please contact customer service at info@tjamerican.com. PART DESCRIPTION QUANTITY PART# Backsplash BS-10730400 Right Door 0228V3022BE-RDO Left Door 0228V3022BE-LDO Shelf 0228V3022BE-SH Handle With Bolt HD-02400360 European Hinge For Door EH-09001300 Shelf Bracket SB-00001300 Leveler LV-51622020...

  • Page 6: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART# Vanity With Top 0228V3022BE-VN Backsplash BS-10730400 Touch Up Pen TP-15000000 PRE-ASSEMBLY PLANNING ASSEMBLY Estimated Installation Time: 20-30 minutes (24 hours for silicone caulk to dry). Number of people required: Two adults and several steps are more easily handled with two adults.
  • Page 7 ASSEMBLY 1. Removing top (optional) lf you need to remove the top for any purpose, do so in the following manner: 1.1 Open the doors. *Note: When vanity top is preinstalled. 1.2 Use a screwdriver (not provided) to unscrew these 8 wood screws, and place them face up onto a scratch free surface such as a foam sheet that came in the packaging.
  • Page 8 ASSEMBLY 2. Re-installing or replacing the top (optional) Use a screwdriver to secure these 8 wood screws. Screws for fixing top layout 8 screws Vanity top 3. Adjusting the levelers Adjust the leg levelers to ensure that the vanity is even.
  • Page 9 ASSEMBLY 4. Adjusting the doors left or right (optional) 4.1 Left or right. Turn screws (1pc/ hinge) on both hinges to adjust the door left or right. 4.2 Up or down. Loosen screws (4pcs/ hinge) on both hinges. Adjust door up or down. Retighten screws.
  • Page 10 ASSEMBLY 5. Adjusting the shelf (optional) 5.1 Remove the shelf screws securing the 5.2 Remove the shelf from the vanity. shelf to the shelf supports (4 screws). 5.3 Insert the shelf supports into the desired 5.4 Gently insert the shelf into the vanity. holes.
  • Page 11 ASSEMBLY 6. Applying silicon to the Backsplash 6.2 Remove silicon to the backsplash. 6.1 Apply silicone to the unpolished Gently remove excess glue from the back side and bottom of the connecting area. backsplash (B). Place the backsplash (B) on the vanity (A). Be sure to align the backsplash (B) with the top of the vanity (A).

  • Page 12: Warranty

    TJAmerican LLC products are manufactured to superior quality standards and workmanship, and are backed by our limited lifetime warranty. TJAmerican LLC products are warranted to the original consumer purchaser to be free of defects in materials or workmanship. We will replace FREE OF CHARGE any product or part that proves defective.
