Positive Grid Spark 2 User Manual

Hide thumbs Also See for Spark 2:

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Spark 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Positive Grid Spark 2

Summary of Contents for Positive Grid Spark 2

  • Page 3 Spark 2 User Manual...

  • Page 4: Table Of Contents

    Table of Contents Product Spec Hardware Control (Top) 07
 Hardware Control (Rear)
 08
 Pairing Spark 2 and the Spark App 08
 To play music via Bluetooth®
 USB Audio
 Installing Battery
 Pairing With A Spark Control X
 Tuner Mode Factory Default Settings...

  • Page 5: Product Spec

    Product Specification AUDIO SPECIFICATIONS CONTROLS AND CONNECTIVITY FRONT PANEL CONTROLS FREQUENCY RANGE Power Button 20-20000 Hz Eight Programmable Preset Selector Amp Controls (Gain, Bass, Mid, Treble, Master STEREO/MONO Mod, Delay, Reverb, Volume) STEREO Bluetooth/Music Channel Volume
 Looper Controls (Rec/Dub, Play/Stop, Undo/ MAXIMUM SOUND PRESSURE LEVEL Redo/Clear) RMS : 114 dB SPL @ 1m...

  • Page 6: Physical Unit

    Auto Chords 50,000+ Tones On ToneCloud®
 Spark AI
 Simple & Groove Looper Video Recording Tuner INCLUDED IN THE BOX BOX CONTENTS Spark 2 Amplifier USB C to C Cable AC to DC Power Adapter Get Started Card Safety Instructions Card...

  • Page 7: Front Panel

    Front Panel...
  • Page 8 • Signal Detection Mode (Click Off): Free length. It will automatically start recording when Spark 2 detects a guitar signal, users tap on the record button to stop recording. The REC/DUB LED will be yellow when entering Signal Detection Mode.

  • Page 9: Rear Panel

    Rear Panel M - Pair Button
 Press to enter Bluetooth® pairing mode when connecting to a new device.
 Hold to enter pairing mode when connecting to Spark Control X. N - Line Output (1/4”)
 Connect to the input of an external device, such as a PA system, audio interface, etc.
 Use the L/Mono output if only using 1 output.

  • Page 10: Pairing Spark 2 And The Spark App

    Pairing Spark 2 And The Spark App • Download the Spark app using the QR code provided or search 'Spark amp' in the App Store or Google Play
 Store.

 • Turn on Spark 2 by holding the Power button.

  • Page 11: Usb Audio

    USB Audio 1. With Spark 2 turned off, connect to a computer via USB with the included USB cable.
 2. Turn on Spark 2 and select “Spark 2 USB Audio” as the recording/playback device.
 3. Adjust USB playback volume with the Music Volume buttons on Spark 2.
...

  • Page 12: Installing Battery

    Spark 2 is only compatible with Spark Battery (sold separately). Spark 2 will use Spark Battery power when unplugged. Spark Battery features up to 10 hours of play time and automatically starts charging when Spark 2 is plugged into a power outlet.
...
  • Page 13 • Step2. Long press the Pair button on the 2. Long press the Pair button on the Rear Panel of Spark 2 until both Wireless Indicator LEDs on the Front Panel light s o t e o t a e ght •...

  • Page 14: Tuner Mode

    While in tuner mode, the 3 Looper LEDs will display if the string being played is in tune.

 • Note that the output of Spark 2 will be muted while tuner mode is on.

 • To exit tuner mode, press the TAP/ TUNER button again.
...

  • Page 15: Factory Default Settings

    More presets can be downloaded and customized for free on ToneCloud. You can access ToneCloud via the Spark app, search for a custom preset, download it for free, and then save the preset directly to Spark 2 by tapping ‘Save to hardware preset’ in the menu.

  • Page 16: Factory Reset / Force Shutdown & Restart

    Factory Reset Follow the steps below to perform a factory reset. This process will reset all the presets stored on the Spark 2 as well as Bluetooth and power saving settings.

 1. Turn off your Spark 2.

...
