| SERVICE REFERENCE iCombi
A calibration is necessary for:
the following service work:
n
as soon as the fan wheel has been removed, installation of a new air
baffle, modification/type change of the hinging racks
customer complaints about uneven cooking results (but only after
n
checking the installation conditions)
subsequent changes to the installation conditions for extractor
n
hoods or Combi-Duo
subsequent change of the installation site with a change of the in-
n
stallation altitude by more than 300 metres (otherwise only a recal-
ibration is recommended)
Start conditions: Cooking cabinet sensor B1, control sensor B2, humidity
sensor B4: < 40°C. In order to achieve the best possible calibration val-
ues, a closed GN container should be inserted 20 mm deep with the
open side down in the middle in front of each fan wheel.
The calibration values are determined during the self-test or calibration
and stored on the SD card and PCB.
After a successful self-test, a flue gas analysis must be carried out for gas
units!
C
ALIBRATION ERRORS
The following calibration errors can occur during the self-test or a
manual calibration:
(Error step | Error code)
(1 | 2) B1 too hot (1 | 4) B2 too hot (1 | 8) B4 too hot; Combination
n
of error codes is possible!
(2 | 1) Differential pressure too low (2 | 2) Differential pressure too
n
high; Check P1
(4 | 1), (10 | 1), (15 | 1) Determined calibration value too low
n
(4 | 2), (10 | 2), (15 | 2) Determined calibration value too high; Check
n
the hose
(X | 999) Timeout in calibration step; E.g.: cabinet door open, check
n
heating register/SSR
Calibration step 20: Calibration has been successfully completed
n
E
RROR CODE
Beware of electric shock, even when the unit is switched off:
I/O power supply unit (A10), pump PCB (A13), eSTL (A15/A16) and
solenoid valve block.
Service Description
10 SC pump, Combi water box, pump-off hose
11 Level electrode, CDS sensor flow rate, I/O board
12 Check CDS sensor
13
Check level electrode
80.51.872 RTS/Doem V07 - 10/24 en-GB
14
Check level electrode, measure conductivity of water
19.1 Check SD card
20.x Thermocouple:
-1: cooking cabinet B1; -2: control B2; -4: humidity B4;
-8: steam generator B5; -16: cooking cabinet bottom B9
(floor units); -32: installation area B10 (XS); -64: cooling fan
iCareSystem AutoDose
25 No increase in performance at the fan motor when the water
jet hits: Check water supply, pressure, hoses, CDS sensor,
position of hinged racks / mobile oven racks
26
Only XS: Ball valve does not open; test in the function test,
replace if necessary
27 Only XS: Ball valve does not close; test in the function test,
replace if necessary
28.x
Thermal element:
-1: steam generator too hot (B5 > 170 °C [338 °F]);
-2: cooking cabinet too hot (B1 > 350 °C [662 °F]); -4: steam
generator (B5 < 2 °C [36 °F], heating possible again from
4 °C [39 °F])
29 CPU board temperature too high (> 75 °C [167 °F])
30
Humidity control error; Check differential pressure sensor
P1
31.x Thermocouple core temperature B3:
-1: check cooking cabinet core probe; -2: cooking cabinet
core probe emergency mode; -11/12: check USB CT 1 /
emergency mode; -21/22: check USB CT 2 / emergency
mode
32.x Fault in combustion system or gas supply (y = combustion
system):
-1.y (22: HA top, 32: steam, 42: HA bottom):
5x unsuccessful ignition process
-2.y (17/18/49: HA top, 27/28/52: steam,
37/38/55: HA bottom):
Flame current measured with gas valve closed
-3.y (19: HA top, 29: steam, 39: HA bottom):
Burner went out 5 times during the burning phase
-4.y (20: HA top, 30: steam, 40: HA bottom):
The speed of the gas blower deviates from the target speed
by more than 150 rpm
33.x
Error in the control of the combustion system:
-1: Accumulation of combustion system errors; -2: Auto-
matic burner control initialised with incorrect gas speeds (=0
or Min<Start<Max not fulfilled); -3: Mains frequency outside
40...70 Hz; -4: Phase and neutral conductor mixed up;
-5: Check automatic ignition controller
34.x
Bus signal missing:
-1: motor up; ‑2: motor centre; ‑4: motor bottom; ‑8: pump
PCB; ‑16: I/O power supply; ‑32: ignition box; ‑256: chem-
ical controller
35 UltraVent: Bus signal / internal communication
35.x UltraVent error:
-1: voltage missing; -2: filter detection faulty; -3: check ther-
mocouple control; -4: check thermocouple motor protec-
tion; -5: pre-warning (change filter) -6: dirt in filter (immedi-
ate replacement); -7: Filter not inserted/no differential pres-
sure measured
36
Check differential pressure sensor (no signal output of 0.5V;
check input signal 12V at P1); P1 must be installed horizont-
ally
37 Climate control malfunction: Check hose connections
40 iCombi Pro:
Error in iCareSystem, hose to steam generator (partially)
blocked or kinked
iCombi Pro with iCareSystem AutoDose option:
Error in iCareSystem, hose to steam generator (partially)
blocked or kinked, steam generator outlet (Y21) does not
open (valve jams and always remains closed)
42.x Incorrect water flow or incorrect flow detection via valve:
-1: filling Y1 to steam generator; -2: control Y2 to control
solenoid; -3: moistening Y3 to moistening nozzle; -4: care
Y4 to care container; -6: flushing Y14 to control box
43 Solenoid valve does not close
44
Malfunction steam heating system
45.x Malfunction on:
-1: cartridge valve 1; -2: cartridge valve 2; -3: cartridge valve
3; -4: cartridge valve 4; -5: outlet cleaner box; -6: outlet
steam generator
46.1 SC-pump (M4): incorrect rpm/power consumption
