Korg NTS-1 Manual

NTS-1 Eurorack Conversion Faceplate Kit for Korg Nu:Tekt digital
Thank you for purchasing our NTS-1 Eurorack Conversion Kit! Below is a step-by-step guide on
how to get your NTS-1 into the faceplate and installed into your rack! You can also refer to the
video manual here:
Part 1: Attach your NTS-1 to the faceplate-
Step 1: Set output volume to around 75%
Step 2: Remove the top 4 screws from your Korg NTS-1 with a phillips head screwdriver
Step 3: Plug in the Angled Micro-USB cable to the Korg NTS-1
Step 4: Plug in the attached cables from the faceplate to your Korg NTS-1 as directed below:
● MIDI IN (bottom connector on faceplate) to the MIDI IN
● SYNC OUT to the SYNC OUT
● SYNC IN to the SYNC IN
● L + R INPUT to the AUDIO IN
Step 5: Place the NTS-1 through the faceplate and attach the 4 screws from step 1 through the
faceplate into your NTS-1. Be careful not to scratch the faceplate and you may have to shift the
unit around a bit. Remember, do not overtighten the screws.
Step 6: Plug in the final TRS cable L + R OUTPUT across the unit into the front HEADPHONE
OUTPUT on the NTS-1.
Part 2: Installing your kit into your rack-
Step 1: Plug the 16 PIN connector with the Noise Isolator into your rack and power on your rack
● IMPORTANT! If you do not see a RED LIGHT on the noise isolator, do NOT proceed
and contact us for assistance
Step 2: Power down your rack and plug the USB-A from the NTS-1 into the noise isolator
Step 3: Use a phillips head screwdriver to put the 4x M3 screws into your rack rails
Step 4: Power on your rack and have fun!
Knowledge Base:
● POWER : 16 pin bus board required to supply 5v for the Korg NTS-1. If your rack's power
supply only offers 10 pin, you can use a standard USB cable and wall charger to power
the NTS-1 externally.
● NOISE : NTS-1's are known for having noise issues when powering their unit from the
same device managing the audio signal, if you have this issue, we recommend using the
supplied 16 pin bus board cable with the attached noise isolator if connecting to your
racks power supply.
● SYNC : When both SYNC IN / OUT TRS cables are connected to the unit, the NTS-1 will
only accept a SYNC IN signal through the faceplate, the SYNC OUT then acts as a
THRU. If you wish to use your NTS-1 as a clock via SYNC OUT, leave the SYNC IN TRS
cable disconnected.
● OUTPUT VOLUME : We recommend setting the OUTPUT volume to around 75% to
prevent output distortion.
Synthesizer Manual
Korg NTS-1 Eurorack Conversion Kit Installation Guide
