One Lux ONE-LED ONE-CONNECT PLUS CASAMBI Manual

EMERGENCY | ONE-LED
TM
ONE-CONNECT PLUS
| CASAMBI WIRELESS EMERGENCY TEST AND MONITORING
TM
SUPPLEMENTARY INSTALLATION & OPERATION (/CW Versions)
System overview
One-Connect-Plus 'Casambi products enable wireless communication
TM '
with a remote DALI emergency test system without the need for
additional hardware or traditional DALI bus wiring.
Our Casambi Wireless emergency products are equipped with Casambi's
proven 2.4GHz radio mesh technology and once paired with the remote
gateway, are able to communicate with virtually any existing DALI
emergency lighting test system as if it were wired.
Features
> Wide range of existing One-LUX emergency solutions now available
One-Connect-Plus enabled
> Built-in radio node eliminates the need for extra components and wiring
in the luminaire
> Emergency products are easily paired using the existing Casambi App
> Easy upgrade for existing luminaires without a change of layout
> Easiliy view the luminaires signal strength and identify emergency
devices from within the Casambi App
> Product endorsed and tested by Casambi
> Designed and manufactured in Great Britain
Omni-LED with embedded Casambi radio
IssD-Aug 2024 - Product specifications may be subject to change without prior notice.
Common Technical Data
One-LUX Product Code Modifier
Wireless Technology Provider
Wireless Technology
Typical maximum range between luminaires (Line of sight)
Emergency test system protocol
Emergency devices per gateway
One-Connect-Plus
Application
enabled products
Casambi to DALI Gateway. One
OC/CAS/GTWY
needed per 64 emergency devices
Omni-LED Internal conversion module range
IP65 capable remote box. Ideal for
RBC
Highbay convesrions
Articulated remote solution
RBF
where ceiling access is restricted
Solo Stand alone recessed luminaire
Stand alone surface mounted
Solo Surface
luminaire
Stand alone surface mounted
Exit Bulkhead
luminaire
Stand alone surface mounted or
Exit Blade
recessed luminaire
Stand alone surface mounted
Exit Box
luminaire
/CW
Casambi
2.4GHz Mesh
50m
DALI
64
Casambi to DALI Gateway 'OC/CAS/GTWY'
Emergency
Lamp Voltage Range
Power
-- --
2-4W 12-200V
2-4W 12-200V
2-4W 12-200V
1.5W 3V
1.5W 3V
2.8W --
1.2W --
1.2W --
Product Web Page
--
OMNI-LED LFP
LED-COMPACT REMOTE
OMNI-LED FLEXI
ONE-LED SOLO
SOLO SURFACE
BULKHEAD
BLADE
BOX
www.one-lux.com 1
