SOFTLINK WACO WM868 Manual

Wireless communication system
Hide thumbs Also See for WACO WM868:
Table of Contents

Advertisement

Quick Links

Download this manual
WIRELESS COMMUNICATION SYSTEM
WM868 WACO
WM868-RFG
Revision 1.0
SOFTLINK s.r.o., Tomkova 409, 278 01 Kralupy nad Vltavou, Czech Republic
Phone.: +420 315707111,
e-mail:
sales@softlink.cz,
www.softlink.cz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WACO WM868 and is the answer not in the manual?

Questions and answers

Related Manuals for SOFTLINK WACO WM868

Summary of Contents for SOFTLINK WACO WM868

  • Page 1 WIRELESS COMMUNICATION SYSTEM WM868 WACO WM868-RFG Revision 1.0 SOFTLINK s.r.o., Tomkova 409, 278 01 Kralupy nad Vltavou, Czech Republic Phone.: +420 315707111, e-mail: sales@softlink.cz, www.softlink.cz...

  • Page 2: Table Of Contents

    Contents 1 Introduction 1.1 WACO communication system ........1.2 Module usage .
  • Page 3 General structure of NEP variable ........Structure of a message from the WM868-RFG gateway containing a WACO packet .

  • Page 4: Introduction

    IP/UDP frame and sends them to the set IP address and port number of the central system. When encoding messages into IP/UDP frames, the WM868-RFG module uses Softlink’s proprietary ”NEP” encoding system, so the module can only be used for those central applications that use the ”NEP” encoding system. In the opposite direction, the module receives complete radio packets wrapped in IP/UDP datagrams from the superior central system, which are to be sent to the WACO radio network.

  • Page 5: Module Characteristics

    Module characteristics The core of the module is a microcomputer with one Ethernet 10/100 Mb/s communication port, one mini USB configuration port, an integrated 868 MHz radio modem and an integrated GSM/LTE modem. The communication ports serve these purposes: Ethernet 10/100 Mb/s port - the module does not use this port; mini USB 2.0 port - module configuration port;...

  • Page 6: Overview Of Technical Parameters

    Overview of technical parameters An overview of the technical parameters of the WM868-RFG module is given in Table 1. Table 1: Overview of technical parameters of the WM868-RFGmodule Transmitter and receiver parameters Frequency 868.0 868.6 Modulation type Number of channels in the band WACO channel width 100 KHz (3 channels)

  • Page 7: Module Configuration

    Module Configuration The parameters of the WM868-RFG module can be checked and set from a computer or tablet in the following ways: - by direct connection of a computer to the module’s configuration connector using a standard USB cable - visually, using the built-in display and control buttons; - wirelessly, using an optical converter of the ”USB-IRDA”...

  • Page 8: Using The "Putty" Program For Module Configuration

    This connects the computer to the module and prepares it for configuration. If the Windows operating system doesn’t find a suitable driver, install the ”ugw3.inf” type driver according to the procedure described in the manual ”Configuration of wacoSystem product line devices”, specifically in paragraph 5.2 of that document.

  • Page 9: General Rules For Entering Configuration Commands

    General rules for entering configuration commands Activate the terminal window for configuration using the configuration cable according to the above procedure. The following general rules apply for entering commands into the command line of the terminal window: enter a command only if there is a command prompt (”prompt”) in the format ”GW33H7-2136#” before the cursor mark (colored or flashing square) (see Figure 4);...

  • Page 10: Setting Parameters Of The Wm868-Rfg Module Using A Configuration Cable

    Eth MASK : 0.0.0.0 NTP server[0]: 0.0.0.0 NTP server[1]: 0.0.0.0 NTP server[2]: 0.0.0.0 *** ConfigGsm (88 bytes) *** Dirty : No : gprsa.softlink Use GPS : No Sync Time : No Use IP : No *** ConfigWaco (28 bytes) ***...

  • Page 11: Displaying A Summary Of Configuration Commands ("Help")

    3.4.2 Displaying a summary of configuration commands (”HELP”) The summary of configuration commands can be displayed by using the ”?”command. The following listing will appear in the terminal window: GW33H7-2136#? - help write - write configuration show - show configuration network - network configuration system...
  • Page 12 only in the operational configuration. If the current operational configuration is not saved to FLASH memory, after a reset, the module will ”return” to the set of configuration parameters stored in FLASH. When setting a parameter only temporarily (e.g. turn on debug outputs) it is not necessary to save the operational configuration to FLASH memory (after finishing work the debug outputs will be turned off...

  • Page 13: Section Of Commands For Setting Communication Subsystems

    The commands location, contact and name are used to set auxiliary identification data of the module. These data are optional and serve only as its user-editable description. Example: GW33H7-2136#system location Kladno Location : Kladno GW33H7-2136#system contact SOFTLINK Contact : SOFTLINK GW33H7-2136#system name GW868-Kladno Name...
  • Page 14 From the configuration listing, it is clear that the subsystem configuration is saved (Dirty=0), the APN name is set to ”grp.softlink.cz” and PIN checking is disabled. GPS functions and time synchronization are disabled. The ”gsm apn” command can be used for setting the APN (Access Point Name) gateway name between the GSM network and the connecting IP network.
  • Page 15 The ”gsm pin” command can be used for setting the PIN for the SIM card used by the given module for GSM communication. Example of setting the PIN to ”2583”: GW33H7-2136#gsm pin 2583 SIM pin : ’2583’ GW33H7-2136# Using the commands ”gsm useip”, ”gsm gps” and ”gsm synctime” with parameter ”0/1” the individual services of the ”gsm”...
  • Page 16 GW33H7-2136#waco rfa My RFA: fffeae84 GW33H7-2136# GW33H7-2136#waco rfa fffeae83 My RFA: fffeae83 GW33H7-2136# IMPORTANT NOTE! Changing the radio address should only be done in exceptional cases, and always after consultation with the manufacturer! The command ”waco group” is used to set the group address of the module. In the WACO system, group addresses can be used to create an almost unlimited number (65536) of groups (”virtual buses”).
  • Page 17 The ”waco debug” command can be used for setting the desired level of debug outputs that help in diagnosing the module. Example: GW33H7-2136#waco debug 1 Debug GW33H7-2136# The command ”waco test” can be used to set the period of sending a test message. The period is given in ”intervals”, where one interval is 1/20 second (so a value of ”100 intervals”...
  • Page 18 The WM868-RFG module thus supports both ”fast” WACO type communication, suitable especially for imple- menting virtual buses, and ”slow” WACO NB type communication, suitable for collecting data from meters and sensors in larger objects, where the advantage is approximately 2.5 times greater radio range compared to WACO communication.

  • Page 19: Section Of Commands For Checking The Functionality Of Communication Interfaces

    The commands ”rf cw”, ”rf xtal” and ”rf debug can be used only for initial module setup and for diagnostics in the manufacturer’s workshop. The ”cw” command starts generating the carrier frequency when tuning the crystal, the ”xtal” command is used to correct the crystal frequency. The ”debug” command can be used to set the desired level of debug outputs.

  • Page 20: Displaying Parameters Of The Wm868-Rfg Module On The Lcd Display

    which is also accessible via PPP connection. In the lower part of the listing there is a list of set UDP ports (UDP table). Port 1141 is intended for main application data transfer (NEP protocol), other port numbers are intended for standard IP management services (DHCP, NTP, SNMP and TFTP).

  • Page 21: Checking Module Parameters Using An Optical Converter

    Figure 5: Display of the main screen, menu and system information Right of the display there are four control buttons that are used to select individual menu items. They have the following functions: the ”OK” button displays the selected (marked) item from the menu; the ”ESC”...

  • Page 22: Setting Module Parameters Via The Internet

    In the current version of the WM868-RFG module, no parameters can be changed via the optical interface, only their values can be checked. The description of parameters is given in the ”NEP” Encoding Table, which is maintained centrally by SOFTLINK and is available at the public WEB address Page. A more detailed description of the encoding principle of the ”NEP”...
  • Page 23 C:\Users\99hon>ping 172.1.16.24 Pinging 172.1.16.24 with 32 bytes of data: Reply from 172.1.16.24: bytes=32 time=1ms TTL=64 Reply from 172.1.16.24: bytes=32 time=1ms TTL=64 Reply from 172.1.16.24: bytes=32 time=3ms TTL=64 Reply from 172.1.16.24: bytes=32 time=1ms TTL=64 Ping statistics for 172.1.16.24: Packets: Sent = 4, Received = 4, Lost = 0 (0% loss), Approximate round trip times in milli-seconds: Minimum = 1ms, Maximum = 3ms, Average = 1ms C:\Users\99hon>...

  • Page 24: Structure Of Sent Messages

    UDP message data content The data content of the message is encoded using SOFTLINK’s proprietary ”NEP” encoding system, where each type of variable has its own ”OID” (Object ID) designation, determining the meaning, character and data type of the given variable.

  • Page 25: Nep Variables Table

    Figure 9: NEP variables table For each variable, its decoding information (”Type” and ”Length”) is also transmitted so that each variable can be decoded on the receiving side (i.e. determine the OID, index and value of the variable) even without knowledge of its meaning.

  • Page 26: Operating Conditions

    Operating Conditions This section of the document provides basic recommendations for transport, storage, installation, and operation of WM868-RFG type radio modules. General Operational Risks WM868-RFG radio modules are electronic devices powered by an external power supply that receive radio messages from surrounding radio modules and forward these messages to a superior server via the Internet.

  • Page 27: Safety Precautions

    Safety precautions Warning! Mechanical and electrical installation of the WM868-RFG module can be provided only by a person with necessary qualification in electrical engineering. Environmental protection and recycling The equipment does not contain exchangeable components, which require compliance with specific rules in terms of environmental protection for their replacing, storage and disposal.

  • Page 28: Module Replacement

    record information about the module installation (serial number, position, picture of installation...) to the operational documentation under internal rules. When locating installation site, selecting antenna type and antenna position it is necessary to take into account con- ditions for radio signal propagation in the area of installation. The conditions is possible either estimate empirically on the base of previous experience, or accomplish a measurement of the signal strength by the signal analyzer.

  • Page 29: Troubleshooting

    turning off the module’s power supply, for example, circuit breaker failure, or its unintentional shutdown; non-functionality of the Internet connection caused by a local GSM network outage, or a PPP connection outage in connection with incorrect functionality of authorization servers, or other GSM operator equipment; risk of temporary or permanent antenna shading (for example, due to building modifications);...

  • Page 30: Additional Information

    This manual is focused on description, parameters and configuration options of radio modules WM868-RFG of the WACO RF system, operating in the 868 MHz band, that are a part of the Softlink’s wacoSystem product family. More information about all WM868 (WACO), WB169 (Wireless M-BUS), WS868 (Sigfox), or NB (NB-IoT) series of the modules can be found on the manufacturer website: www.wacosystem.com...

This manual is also suitable for:

Wm868-rfg
