Panasonic ER507-E2 Service Manual

Panasonic ER507-E2 Service Manual

Ac/rechargeable hair trimmer
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
SPECIFICATIONS
CONTENTS
Power source
Power consumption
Motor voltage
Rated time
Charging time
Weight
Supplied accessories
Page
AC/Rechargeable Hair Trimmer
ER507-E2
AC230V, 50Hz
5W
1.2V DC
40 minutes
12 hours
150g (including attachment)
310g (adaptor)
10/20/30/4 0mm Comb Attachment
4mm/Thinning Attachment
Oil
Cleaning Brush
2
2
3
4
© 2002 Matsushita Electric Works Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
ORDER NO. SD0202E33C2
Page
5
6
6

Advertisement

loading
Need help?

Need help?

Do you have a question about the ER507-E2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic ER507-E2

Summary of Contents for Panasonic ER507-E2

  • Page 1: Table Of Contents

    ORDER NO. SD0202E33C2 AC/Rechargeable Hair Trimmer ER507-E2 SPECIFICATIONS Power source AC230V, 50Hz Power consumption Motor voltage 1.2V DC Rated time 40 minutes Charging time 12 hours Weight 150g (including attachment) 310g (adaptor) Supplied accessories 10/20/30/4 0mm Comb Attachment 4mm/Thinning Attachment...

  • Page 2: Schematic Diagram

    ER507-E2 1 SCHEMATIC DIAGRAM 2 WIRING CONNECTION DIAGRAM...

  • Page 3: Disassembly Instructions

    ER507-E2 3 DISASSEMBLY INSTRUCTIONS Follow the procedure below to disassemble the main body. 1. Remove the attachment and the blade. 2. Loosen two screws tightening the blade springs and one housing screw. 3. Separate housing A and B by opening at the blade side.

  • Page 4: Assembly Instructions

    ER507-E2 4 ASSEMBLY INSTRUCTIONS 1. Place the connecting plate and the switch handle onto the housing B with OFF position. NOTE 1: Do not touch the contact metal plate to prevent its deformation. (See Fig.2-A.) NOTE 2: Set the switch handle into the slit of connecting plate firmly. (See Fig.2-B.) 2.

  • Page 5: Troubleshooting Guide

    ER507-E2 5 TROUBLESHOOTING GUIDE (Refer to WIRING CONNECTION DIAGRAM) < TROUBLE > <CHECK.> <REMEDY> Does not operate. → → → → <CHECK CHARGING ADAPTOR.> Replace charging Supply rated voltage to the adaptor. OK if it is approx. DC 1.6 - 2.4V →...

  • Page 6: Exploded View

    ER507-E2 6 EXPLODED VIEW 7 REPLACEMENT PARTS LIST NOTE *A=available as an optional accessory *B=only available as set *C=available individually Ref. No. Part No. Part Name & Description Remarks Per Unit WER507S7458 COMB ATTACHMENT WER507A7398 4MM COMB ATTACHMENT WER936Y BLADE BLOCK...
