B16-BMB3 MOTHERSHIP 3 rev E and later
B16-BMB3
MOTHERSHIP
Quick Start Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOTHERSHIP B16-BMB3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BURL MOTHERSHIP B16-BMB3

Summary of Contents for BURL MOTHERSHIP B16-BMB3

  • Page 1 B16-BMB3 MOTHERSHIP 3 rev E and later B16-BMB3 MOTHERSHIP Quick Start Guide...
  • Page 2 B16-BMB3 1. Register Your Device Please register all serial numbers for your B16 MOTHERSHIP chassis and all Daughter Cards. You must register to activate your warranty! Please visit: www.burlaudio.com/register. 2. Remove Lid 1. Remove 9 screws on top and 2 on each side (Image 1). 2.

  • Page 3: Important Installation Notes

    B16-BMB3 4. Install Vent Image 5: B16 MOTHERSHIP with 1U vent above for proper airflow. Important Installation Notes: • Install the 1U vent above the B16 chassis. The MOTHERSHIP MUST run with proper ventilation. • Failure to properly vent the MOTHERSHIP chassis above may cause failure, and will void the warranty. 2.
  • Page 4 B16-BMB3 2.4 Connect BMB3 Ethernet Port 1 to Gigabit Ethernet Switch Image 6: Only Port 1 of the BMB3 card can be used with B16. 2.5 Set BMB3 Front Panel to INT, EXT, or DANTE Image 7: BMB3 front panel. Set Clock Control to INT, EXT, or DANTE For a complete guide to Dante Clocking, see page 9.
  • Page 5 B16-BMB3 2.11 Click on “Routing” Tab (See Image 8) Image 8: Shows routing BMB3 receiver ch. 1-16 to PCIe Card channel 1-16. 2.12 Maximize the Routing View Click on the “+” next to “Dante Receivers” and “Dante Transmitters (See Image 9). Image 9: Shows “Routing”...

  • Page 6: Input Assignment

    B16-BMB3 2.13 Input Assignment Route BMB3 Transmitter channel 1 to PCIe (or CPU if using DVS) Receiver card channel 1. This routes B16 input ch.1 to PCIe (or DVS) card ch. 1 (See Image 10). Image 10: Shows routing BMB3 transmitter channel 1 to PCIe Card channel 1.
  • Page 7 B16-BMB3 2.14 Output Assignment (continued) Continue with output assignments for your MOTHERSHIP configuration. See Image 12 for an example of routing B16 MOTHERSHIP outputs to the PCIe Card. Image 12: Shows routing BMB3 receiver ch. 1 to PCIe Card channel 1. 2.15 Click On “Device Info”...
  • Page 8 B16-BMB3 2.16 Click On “Device Config” Select the sample rate and select preferred latency (See Image 14). Note: Actual latency used between two endpoints is the larger of the two endpoint settings. If using the Dante Virtual Soundcard (DVS), anything to or from DVS will have a 4ms latency in and out. Using a PCIe Card is recommended to get down to 150μs.
  • Page 9 B16-BMB3 3. Dante Clocking There are 3 ways to clock the B16 MOTHERSHIP: 1. BMB3 set to Internal. Brooklyn II (BKII) Card set to External 2. BMB3 set to External Clock, BKII Card set to External 3. BMB3 set to Dante, BKII Card set to Internal 3.1 Clocking BMB3 to Internal Word Clock 1.
  • Page 10 B16-BMB3 3.2 Clocking BMB3 To External Word Clock 1. Set BMB3 front panel to EXT 2. Open Dante Controller, select DEVICE INFO 3. Double Click on device “BMB3-xxxxxx” 4. Click on CLOCK STATUS. (Image 16) 5. Set BMB3 to “Preferred Master”, and “Enable to sync to External” 6.
  • Page 11 B16-BMB3 3.3 Clocking BMB3 To Dante 1. Set BMB3 front panel to DANTE 2. Open Dante Controller, select DEVICE INFO 3. Double Click on device “BMB3-xxxxxx” 4. Click on CLOCK STATUS. (Image 17) 5. Set BMB3 to “Preferred Master”, and deselect “Enable to sync to External” 6.
