- Page 1 B16-BMB6 MOTHERSHIP BMB6 Rear Panel: DSUB25 AES/EBU (Tascam format) Quick Start Guide Revision 1 January 22, 2020...
- Page 2 GETTING STARTED 1. Register Please register serial numbers for your B16 MOTHERSHIP chassis, and all Daughter Cards. You must register to activate your warranty! Please visit: www.burlaudio.com/register. NOTE: Most B16s come pre-assembled. If not, follow steps 2 to 6 for assembly.
- Page 3 DEFAULT JUMPER SETTING: 4 or 8 inputs for slot 1 and 4 or 8 outputs for slot 2 as shown below. Image 4: Default set- Image 5: B16-BMB6 MOTHERSHIP with a BAD8 for 8 inputs, and ting a BDA8 for 8 outputs. JUMPER SETTING EXAMPLE: Jumper on A Jumper set for input channels 1-4 in slot 1, and input channels 5-8 in slot 2 or output chan- nels 1-4 in slot 1, and output channels 5-8 in slot 2 as shown below.
- Page 4 4. Install Daughter Cards See card slot numbers and corresponding Inputs and Outputs on page 3. Daughter Cards will ship with wire assemblies already attached to the Daughter Cards. Make sure the card is inserted into the card guides and properly connects to the backplane.
