Summary of Contents for BURL BDA4M
- Page 1 BDA4M MOTHERSHIP 3 rev F and later BDA4M DAUGHTER CARD Quick Start Guide...
- Page 2 In default mode with no jumpers set (Image 1), the BDA4M uses the Short Delay Filter with the classic “Burl Sound”. A jumper on A (Image 2) will switch to the Long Delay Filter, with longer latency and a more forward mid-range.
- Page 3 Installing the BDA4M into B16 MOTHERSHIP Chassis Image 9: With the B16 lid removed, in- Image 10: Pull the cables through to the stall the BDA4M into the card guides as front of the chassis. Attach the 4-pin shown here. Make sure the metal Daugh-...
- Page 4 Image 12: BDA4M Rear Panel BDA4M Analog Output Level Switch Attenuation The BDA4M is designed to be a multi-purpose DAC used for mixing, mastering, and monitoring. When monitoring a full scale, mastered file, you can turn the analog sig- nal down for increased headroom and cleaner output.
