SICAM
VDIS, VDIS Pro
V01.00
Manual
E50417-H8940-C661-A1
Preface
Table of Contents
Delivery
Introduction
Hardware Components and Drawings
Mounting, Installation and Connections
Device Functions
Technical Data
Troubleshooting
Literature
1
2
3
4
5
6
A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SICAM VDIS and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens SICAM VDIS

Summary of Contents for Siemens SICAM VDIS

  • Page 1 Preface Table of Contents Delivery SICAM Introduction VDIS, VDIS Pro Hardware Components and Drawings Mounting, Installation and Connections V01.00 Device Functions Manual Technical Data Troubleshooting Literature E50417-H8940-C661-A1...
  • Page 2 Document version: E50417-H8940-C661-A1.00 Trademarks Edition: 05.2024 SIPROTEC, DIGSI, SIGRA, SIGUARD, SIMEAS, SICAM, Insights Version of the product described: V01.00 Hub, and OT Companion are trademarks of Siemens. Any unauthorized use is prohibited.

  • Page 3: Preface

    Preface Purpose of the Manual This manual describes the application, functions, installation, and operation of SICAM VDIS, VDIS Pro. Target Audience This manual is intended for project engineers, commissioning engineers, and operating personnel in electrical systems and substations. Scope This manual applies to SICAM VDIS, VDIS Pro; hardware version BB.
  • Page 4 Preface Humboldtstraße 59 E-mail: poweracademy@siemens.com 90459 Nuremberg Internet: www.siemens.com/poweracademy Germany Notes on Safety This document is not a complete index of all safety measures required for operation of the equipment (module or device). However, it comprises important information that must be followed for personal safety, as well as to avoid material damage.
  • Page 5 Preface Problem-free and safe operation of the product depends on the following: • Proper transport • Proper storage, setup and installation • Proper operation and maintenance When electrical equipment is operated, hazardous voltages are inevitably present in certain parts. If proper action is not taken, death, severe injury or property damage can result: •...
  • Page 6 SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 7: Table Of Contents

    Table of Contents Preface................................3 Delivery.................................9 Delivery..........................10 Introduction..............................11 Overview.......................... 12 Functions and Features..................... 13 Benefits..........................14 Application........................15 Ordering Information......................17 Environmental Protection Hints..................18 Hardware Components and Drawings......................19 Front and Rear Views......................20 Dimensional Drawings...................... 21 Hardware Components..................... 22 Terminal Connections and Plugs..................24 Device Labels........................
  • Page 8 SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 9: Delivery

    Delivery Delivery SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 10: Delivery

    Delivery 1.1 Delivery Delivery The SICAM VDIS, VDIS Pro device is delivered in a cardboard box with the Siemens logo. Contents of Delivery • 1 SICAM VDIS or SICAM VDIS Pro device • 1 product information guide SICAM, VDIS, VDIS Pro, Manual...

  • Page 11: Introduction

    Introduction Overview Functions and Features Benefits Application Ordering Information Environmental Protection Hints SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 12: Overview

    (3.3 kV to 40.5 kV, ±10 %). The device complies with the requirements of the standard IEC 62271-213 for voltage detection and indica- tion systems. SICAM VDIS, VDIS Pro is used as a low-resistance modified interface (LRM) for connecting a short-circuit indicator for voltage measurement.

  • Page 13: Functions And Features

    Introduction 2.2 Functions and Features Functions and Features The functions of SICAM VDIS, VDIS Pro are: • Phase-wise detection and indication of absence or presence of operating voltage (where U = rated voltage): – < 10 %: operating voltage is less than 10 % in all 3 phases –...

  • Page 14: Benefits

    • Long-life cycle – Prevents accidental energization or unauthorized access via an indication. SICAM VDIS, VDIS Pro helps to extend the service life of electrical equipment and reduce potential damage. • Electrical interlocking –...

  • Page 15: Application

    Applicable for solidly, low resistive, high resistive, capacitive, and isolated-grounded systems. • SICAM VDIS, VDIS Pro is used as an LRM interface for connecting a short-circuit indicator. This short-circuit indicator is used measure and detect faults accurately and reliably by interfacing voltage signals.
  • Page 16 Introduction 2.4 Application Phase Comparison SICAM VDIS, VDIS Pro has a front accessible sockets (L1, L2, L3, and ) which are used as a testing point interface. For each phase, the functional use of the interface at the testing points are to deliver a signal for: •...

  • Page 17: Ordering Information

    1200, 2400, 3900, 5100, 6800, 8000, 9500, 10700, 11200, 16800 pF NOTE The SICAM VDIS, VDIS Pro can be used with various types of Siemens switchgear units. For detailed configuration of other switchgear units, contact Siemens customer support. SICAM, VDIS, VDIS Pro, Manual...

  • Page 18: Environmental Protection Hints

    When disposing of or transferring a mobile storage device, Siemens strongly recommends physically destroying it or completely deleting data from the mobile storage device by using a commercially available computer data erasing software.

  • Page 19: Hardware Components And Drawings

    Hardware Components and Drawings Front and Rear Views Dimensional Drawings Hardware Components Terminal Connections and Plugs Device Labels SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 20: Front And Rear Views

    Hardware Components and Drawings 3.1 Front and Rear Views Front and Rear Views [le_sicamvdispro_front_interface, 2, --_--] Figure 3-1 SICAM VDIS Pro–Front View Liquid crystal display Test button Metal clamps for mounting Protective cap for testing points LEDs (Aux, U=0, U≠0)

  • Page 21: Dimensional Drawings

    Hardware Components and Drawings 3.2 Dimensional Drawings Dimensional Drawings [dw_vdispro_frontview_cd, 2, en_US] Figure 3-3 Front View–Dimensional Details [dw_vdispro_topview_cd, 2, en_US] Figure 3-4 Top View–Dimensional Details SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 22: Hardware Components

    • Auxiliary power supply connection (X2). Applicable for SICAM VDIS Pro variant only. • 2 digital outputs (X3) for remote status indication. Applicable for SICAM VDIS Pro variant only. 2 change-over type monostable potential free contacts. • Cable connection to a short-circuit indicator (L1, L2, L3, and ).
  • Page 23 Hardware Components and Drawings 3.3 Hardware Components [dw_vdis_profile_rearviews_fv, 2, --_--] Figure 3-7 SICAM VDIS Rear View (Fixed)–without Protection Cap [dw_vdis_profile_rearviews_fv1, 2, --_--] Figure 3-8 SICAM VDIS Rear View (Configurable) [dw_vdis_profile_rearview_v, 1, --_--] Figure 3-9 SICAM VDIS Pro Rear View SICAM, VDIS, VDIS Pro, Manual...

  • Page 24: Terminal Connections And Plugs

    Mating connector 4-positions rectangular power connector, discrete wire slot Insertion force 15 N For more information on cable length and type, contact Siemens Customer Support. Fixed Connector (X2) Specifications Mating connector 2 positions, screw type M2 connection with tension sleeve Conductor cross-section 0.14 mm...
  • Page 25 Hardware Components and Drawings 3.4 Terminal Connections and Plugs Table 3-3 Recommended Connectors Information Connector Make Manufacturer Part Number Web page TE Connectivity 794954-4 https://www.te.com/en/home.html Phoenix Contact 1836079 https://www.phoenixcontact.com/en-in/ Phoenix Contact 1840405 SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 26: Device Labels

    Hardware Components and Drawings 3.5 Device Labels Device Labels The device details are located on top of the housing and available C2 value for configuration and check box to mark the configured value. The device label also displays the ordering code, serial number, description, and safety symbols.

  • Page 27: Mounting, Installation And Connections

    Mounting, Installation and Connections Mounting Installation and Connections SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 28: Mounting

    RMU panel. To mount SICAM VDIS, VDIS Pro in the panel, proceed as follows: • SICAM VDIS, VDIS Pro can be installed on swithgear panel with thickness ranging from 1.5 mm to 3 mm. • For horizontal mounting, SICAM VDIS, VDIS Pro is compatible in RMU panel cutout with dimensions: 92 + 0.8 mm x 45 + 0.6 mm (W x H)

  • Page 29: Installation And Connections

    4.2 Installation and Connections Installation and Connections Procedure NOTE • Before installing SICAM VDIS, VDIS Pro to the switchgear unit, check the device display functioning is operational or not. Refer to scenario 7 of 5.1 Indications and Relay Positions. •...
  • Page 30 [dw_sfcm-vdis connection, 1, --_--] Figure 4-4 SICAM FCM and SICAM VDIS, VDIS Pro Connections • Step 5: Connect 2 digital outputs (X3) to external RTUs for remote status indication or electrical inter- locking coils.
  • Page 31 Switchgear panel SICAM VDIS, VDIS Pro • Step 8: Horizontal and vertical mounting of SICAM VDIS, VDIS Pro in switchgear panel is shown below. [dw_sfcm-vdisinstall4, 1, --_--] NOTE Close the connecting points for short-circuit indicator and testing points with protective cap, when they are not in use.
  • Page 32 Mounting, Installation and Connections 4.2 Installation and Connections Disassembly • To unmount the device, insert the flat screwdriver between switchgear panel gap and the device and push outwards. • Repeat step above on other side of the device and then hold to take out the device from panel cutout. [dw_sfcm-vdisinstall3, 1, --_--] Figure 4-6 Device Unmounting from Switchgear Panel...

  • Page 33: Device Functions

    Device Functions Indications and Relay Positions Configuration of Capacitance (C2) Checking Configuration and Settings SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 34: Indications And Relay Positions

    It is used to detect and indicate the presence or absence of operating voltage in a medium-voltage distribution system. Following tables describes SICAM VDIS, VDIS Pro ‑ LCD, LED indications, and relay function positions scenarios. Table 5-1 SICAM VDIS, VDIS Pro Indications and Relay Positions...
  • Page 35 ² otherwise touching live parts lead to electric shock. SICAM VDIS, VDIS Pro is designed as integrated system which is used to indicate the presence or absence of operating voltage at interfaces according to IEC 62271-213. SICAM VDIS, VDIS Pro is not intended to distinguish between the state of voltage not present (U <...

  • Page 36: Configuration Of Capacitance (C2)

    Cdev = device capacitance Ccab = connecting cable capacitance The SICAM VDIS, VDIS Pro can be installed in recommended switchgear units as per the coupling element capacitance (C1) values. For configuration with other C1 values which are not in ordering information, contact Siemens customer support.

  • Page 37: Checking Configuration And Settings

    • Factory setting of C2 capacitance: In SICAM VDIS, VDIS Pro the C2 capacitance for each phase is adjusted to match the common operating voltages provided by the switchgear manufacturer. The setting is recognizable from the position indicator cutout provided on each rotor switch.
  • Page 38 SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 39: Technical Data

    Technical Data General Technical Specifications Type Testing Data SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 40: General Technical Specifications

    (applicable for 6MD2330-3xA10-0AA0 only) AC 110 V to 240 V (-20 % to 10 %) Cable to short-circuit indicator Interface cable connection from SICAM VDIS, VDIS Pro Measuring Inputs for Voltage Measuring range (phase-to-phase) 3.3 kV to 40.5 kV, ±10 % –...
  • Page 41 Technical Data 6.1 General Technical Specifications Mounting position Horizontal or vertical Weight 102 g approximately for 6MD2330-1AA00 106 g approximately for 6MD2330-2[B/D]A00 140 g approximately for 6MD2330-3[B/D]A00 Environment Operating temperature -40 °C to +75 °C Storage temperature -40 °C to +75 °C Humidity 0 % to 98 %, non-condensing Altitude above sea level...

  • Page 42: Type Testing Data

    Duration: 3 h Humidity Permissible humidity 93 % ±3 % relative humidity Siemens recommends installing the devices in a place where they are not exposed to direct sunlight or wide temperature variations that could lead to condensation. Electrical Tests Safety Tests...
  • Page 43 Technical Data 6.2 Type Testing Data NOTE In compliance with IEC 62271-213:2021 standard, the voltage limiting element operates within a maximum threshold of AC 90 V and remains dormant when the voltage is less than AC 60 V. Mechanical Tests Tests Standards Test Requirements...
  • Page 44 Technical Data 6.2 Type Testing Data Test Standards Test Requirements Surge immunity test IEC 61000-4-5, Level 3 Auxiliary power supply, DO1, and DO2 IEC 61326-1, Level 3 Differential mode: ± 1 kV Common mode: ± 2 kV Conducted suscepti- IEC 61000-4-6, Level 2 150 kHz to 80 MHz (10 V) on all ports bility test IEC 61326-1, Level 2...

  • Page 45: Troubleshooting

    Troubleshooting Troubleshooting SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...

  • Page 46: Troubleshooting

    Troubleshooting A.1 Troubleshooting Troubleshooting This section provides the common problems of SICAM VDIS, VDIS Pro and the recommended solution to resolve the problem. Observations Action Random display of display indications or The ground connection may not make a proper contact an issue with LEDs •...

  • Page 47: Literature

    Siemens AG, SICAM FCM, User Manual E50417-H8940-C580-B5 Siemens AG, SICAM FCM, Product Information Guide E50417-X8999-C632-A1 Siemens AG, SICAM VDIS, VDIS Pro Catalog E50417-X8940-C664-A1, Edition 1 Siemens AG, SICAM VDIS, VDIS Pro Product Information Guide E50417-X8999-C660-A1 SICAM, VDIS, VDIS Pro, Manual E50417-H8940-C661-A1, Edition 05.2024...
