Figure 38
Proxy server
Analog TV
signals
Digital TV
signals
VC-134
Voice, Video, and Home Applications Configuration Guide
Topology for uBR7246 Universal Broadband
WAN
ATM, 100BT, 10BT
100BT
100BT
100BT
Cisco
uBR7246
IF
US-RF
5-42 MHz
RF
Combiner
Transceiver
Fiber node
(Telephone pole,
underground box)
Internet
ISP
MSO: Multiple Service Organization
Upconverter
DS-RF 54-860 Mhz
Fiber
80 km
1000 ft
Two-way
distribution
amplifier
Drop box
Tap
Cable modem
(Cisco uBR904)
