Summary of Contents for GE Profile GSD4112Z02AA
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. GE GSD4112Z02AA Owner's Manual Shop genuine replacement parts for GE GSD4112Z02AA Find Your GE Dishwasher Parts - Select From 6722 Models -------- Manual continues below --------...
- Page 2 GE Appliances Owner’s Manual GSD4010 GSD4020 GSD4030 GSD4112 GSD4114 GSD4122 GSD4124 GSD4132 GSD4134 ® GE Answer Center 800.626.2000 Part No. 165D4700P194 Pub. No. 49-5869 6-99 JR...
- Page 3 Congratulations! You Are Now Part of the GE Family. Welcome to the GE family. We’re proud of our quality products and we are committed to providing dependable service. You’ll see it in this easy-to-use Owner’s Manual and you’ll hear it in the friendly voices of our customer service department.
-
Page 4: Table Of Contents
Safety Information ..4–7 GE & You, A Service Partnership. Ask any GE appliance owner and they will tell you we stand behind our products with unmatched quality service. However, did you know that most questions result from... -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, electric shock, or to prevent property damage, personal injury, or loss of life. WATER HEATER SAFETY Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or... -
Page 6: Proper Installation And Maintenance
Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by calling us toll-free at the GE Answer Center ® , 800.626.2000. Connect to a grounded... - Page 7 IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! DO NOT… Do not tamper with controls. Do not allow children to play inside, on or with this Do not abuse, sit on, or stand appliance or any discarded on the door or dish rack of appliance.
-
Page 8: Safety Information
Dishwashing Detergent has or staining of dishwasher been approved for use in all may result. GE dishwashers. Do not touch the heating Locate sharp items so that they element during or are not likely to damage the immediately after use. -
Page 9: About The Dishwasher Control Panel
About the dishwasher control panel. You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model. CLEAN OPTIONS CYCLE SELECTIONS 2 4 6 LIGHT RINSE HI TEMP HI TEMP HEATED LOCK... -
Page 10: Control Panel And Settings
Options The light above the selected pad will be ON to indicate which OPTION has been selected. HI TEMP RINSE Turns on the heater in all prerinse and final rinse cycles to help prevent spotting on dishware. This option may be turned ON or OFF during the wash cycle. -
Page 11: Cycle Sequence
About the dishwasher cycle sequence. You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model. Cycle Sequence Water Time Cycles (approx.) (approx.) Cycle Sequence NORMAL 8.0 gal. -
Page 12: Flashing Lights
Flashing control panel lights. Flashing Lights Lights What it means What to do This is normal. The Allow the dishwasher to START/RESET pad drain and reset before START has been pressed. you start a new wash cycle. RESET Control error Press the START/RESET CLEAN pad to turn off the beeper. -
Page 13: Using The Dishwasher
Using the dishwasher. Check the Water Temperature The entering water must be at least 120°F. and not more than 150°F., for effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher, place the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising. -
Page 14: Proper Use Of Detergent
Proper Use of Detergent Use only detergent specifically made for use in dishwashers. Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers. Keep your detergent fresh and dry. Don’t put powder detergent into the dispenser until you’re ready to wash dishes. -
Page 15: Loading The Racks
Loading the dishwasher racks. For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack The upper rack is for glasses, cups and saucers. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics. -
Page 16: Lower Rack
Lower Rack When loading the lower rack, do not load large platters or trays in the front right corner. They may prevent detergent from circulating during the wash cycle. The lower rack is best used for plates, saucers, and cookware. Large items such as broiler pans and racks should go along the sides. - Page 17 Loading 10 place settings… Follow these guidelines for loading 10 place settings. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack—10 place setting Lower Rack—10 place setting...
-
Page 18: Optional Accessories
About optional accessories. You can change the door and lower access panel appearance of your dishwasher by ordering one of these optional accessories: Color Panels 1/4” Wood Panel Trim Kit 3/4” Trimless Panel Kit These accessories are available at extra cost (VISA, MasterCard, or Discover cards accepted) by calling 800-626-2002. -
Page 19: Caring For The Dishwasher
Caring for the dishwasher. To clean the control panel use a lightly dampened cloth then dry thoroughly. To clean the exterior use a good appliance polish wax. Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher. Protect Against Freezing If your dishwasher is left in an unheated place during the winter, ask a service technician to:... -
Page 20: Troubleshooting Tips
Before you call for service… Troubleshooting Tips Review the charts on the following pages first and you may not need to call for service. Problem Possible Causes What To Do Each pad must be touched Control panel lights go Time too long between •... - Page 21 Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers. To remove suds from the tub, • open the dishwasher and let suds evaporate. Add 1 gallon of cold water to the tub. Close the door until it locks into place.
- Page 22 Problem Possible Causes What To Do Raise the water heater Dishes and flatware Inlet water temperature • temperature to 120°F. not clean is below 120°F Use HI TEMP WASH. • Turn on a faucet. Is water Water pressure is • coming out more slowly temporarily low than usual? If so, wait until...
- Page 23 Wear rubber gloves. Do not use any type of cleanser other than dishwasher detergent because it may cause foaming or sudsing. Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers.
- Page 24 Problem Possible Causes What To Do Make sure inlet water Dishes don’t dry Low inlet water • temperature is correct. temperature Select HI TEMP RINSE • and/or HEATED DRY. Check the rinse agent Rinse agent dispenser • dispenser. is empty Call for service.
- Page 25 Notes...
- Page 27 Notes...
- Page 29 Notes...
- Page 30 800-626-2224 Place your confidence in GE and call us in the U.S. toll-free at for more information. *All brands covered, up to 20 years old, in the continental U.S.
-
Page 31: Product Registration
Our service number information call the a safety modification. is 800-GE-CARES GE Answer Center ® (800-432-2737). 800.626.2000. Model Number Serial Number Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered. -
Page 32: Warranty
One Year materials or workmanship. During this full one-year From the date of the warranty, GE will also provide, free of charge, all labor original purchase and in-home service to replace the defective part. Any part of the dishwasher which fails due to a defect in Second Year materials or workmanship. -
Page 33: Service Telephone Numbers
Expert GE repair service is only a phone call away. Special Needs Service 800.626.2000 TDD 800-TDD-GEAC (800-833-4322) GE offers, free of charge, a brochure to assist in planning a barrier- free kitchen for persons with limited mobility. Service Contracts 800-626-2224 Purchase a GE service contract while your warranty is still in effect and you’ll receive a substantial discount.
