Cisco 2811 - Voice Security Bundle Router Operations page 16

1. Clean the cover of any grease, dirt, or oil before applying the tamper evidence
labels. Alcohol-based cleaning pads are recommended for this purpose. The
temperature of the router should be above 10 C.
2. The tamper evidence label should be placed so that one half of the label covers
the front panel and the other half covers the enclosure.
3. The tamper evidence label should be placed over the CF card in the slot so that
any attempt to remove the card will show sign of tampering.
4. The tamper evidence label should be placed so that the one half of the label
covers the enclosure and the other half covers the port adapter slot.
5. The tamper evidence label should be placed so that the one half of the label
covers the enclosure and the other half covers the rear panel.
6. Place tamper evident labels on the opacity shield as shown in Figure 11.
7. The labels completely cure within five minutes.
Figures 9, 10 and 11 show the additional tamper evidence label placements for the 2811.
Figure 10 – 2811 Tamper Evident Label Placement (Front View)
© Copyright 2007 Cisco Systems, Inc.
This document may be freely reproduced and distributed whole and intact including this Copyright Notice.
Figure 9 – 2811 Tamper Evident Label Placement (Back View)
16
