Page 2: Input Jack
DC POWER CONNECTOR OUTPUT JACK INPUT JACK TIME FEEDBACK CONTROL CONTROL KNOB KNOB TIME FEEDBACK LEVEL CONTROL FREQUENCY KNOB SWITCH TYPE LEVEL SWITCH TYPE SWITCH FOOTSWITCH INTERNAL-CONTROL COMPARTMENT SCREW ACCESS ON REAR... - Page 3 B A SS M A N D E L AY ® The Bassman Delay excels in adding large, airy space to your bass’s tone, and it can also add rhythmic repeats to introduce exciting patterns and flare to a groove. It’s engineered to offer both of these effects with two delay modes—ana-...
- Page 4 OUTPUT JACK Low-impedance output connects to amp or next pedal in signal chain. INPUT JACK High-impedance input for bass guitar and other instruments. PAD SWITCH Switch on side of pedal is for active instruments with strong signals; UP position applies -6dB to input. DC POWER CONNECTOR Connect DC adapter here.
- Page 5 INTERNAL CONTROLS (ACCESSIBLE BY REMOVING COVER) Remove cover using a flat-head screwdriver. LOW CUT TRIM POTENTIOMETER adjusts low-frequency content for Low Frequency switch UP position; turn clockwise to remove low frequency. Low cut can be adjusted from -6 dB at 420 Hz (least amount of low frequency) to -6 dB at 40 Hz (most low frequency).
- Page 6 SLAP BACK GROOVE Setting the delay TIME and LEVEL controls to lower settings will provide a slap back effect for more subtle reverb-like delay. TIME: 4 FEEDBACK: 6 LEVEL: 5 SWITCHES: Both down TIME FEEDBACK TYPE LEVEL...
- Page 7 ATMOSPHERIC RUMBLE With the LOW FREQUENCY switch in the down position, notes will cut through even with the LEVEL and FEEDBACK controls set high. TIME: 6 FEEDBACK: 8 LEVEL: 8 SWITCHES: Both down TIME FEEDBACK TYPE LEVEL...
- Page 8 BEAT REPEAT Setting the TYPE and LOW FREQUENCY switches to the up position and turning the LEVEL control to higher settings will act like a beat repeat, playing back notes clearly at full volume. TIME: 6 FEEDBACK: 5 LEVEL: 8 SWITCHES: Both up TIME FEEDBACK...
- Page 11 A PRODUCT OF FENDER MUSICAL INSTRUMENTS CORPORATION 31 1 CESSNA CIRCLE CORONA, CALIF. 92880 U.S.A. Fender and Bassman are registered trademarks of FMIC. ® ® Copyright © 2024 FMIC. All rights reserved. PN 7082000212 REV B IMPORTANT SAFETY INSTRUCTIONS •WARNING: Read these instructions.
- Page 12 © FENDER MUSICAL INSTRUMENTS 2024...
