SMART BATTERY CHARGER
& MAINTAINER
WITH RECONDITIONING FUNCTION
12V
| 1/4/6A
100% AUTOMATIC
FOR LEAD ACID
EN USER MANUAL
FR MANUEL D'UTILISATION
DE BENUTZERHANDBUCH
ES
MANUAL DE INSTRUCCIONES
IT
MANUALE D'ISTRUZIONI
PT MANUAL DO UTILIZADOR
FI
KÄYTTÖOHJE
GR ΕΧΓΕΙΡΙΔΙΟ ΧΡΗΣΗΣ
| www.bs-battery.com
Release 2023-01
3
8
13
18
23
28
33
38

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BS 60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BS BATTERY BS 60

  • Page 1 SMART BATTERY CHARGER & MAINTAINER WITH RECONDITIONING FUNCTION | 1/4/6A 100% AUTOMATIC FOR LEAD ACID EN USER MANUAL FR MANUEL D’UTILISATION DE BENUTZERHANDBUCH MANUAL DE INSTRUCCIONES MANUALE D’ISTRUZIONI PT MANUAL DO UTILIZADOR KÄYTTÖOHJE GR ΕΧΓΕΙΡΙΔΙΟ ΧΡΗΣΗΣ Release 2023-01 | www.bs-battery.com...
  • Page 2: Box Content

    - BOX CONTENT AC plug - EU 180 cm 1x CHARGER 122 cm CLIP CLIP 1x Clamps set - 61 cm 1x Eyelets terminals set (m6) - 61 cm...
  • Page 3: Important Safety Advice And Warnings

    User manual THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS Lead acid compatible: AGM, WET, CALCIUM, GEL & VRLA IMPORTANT SAFETY ADVICE AND WARNINGS • The charger is designed to charge and maintain 12V batteries AGM & WET, CALCIUM and GEL. •...
  • Page 4: Temperature & Safety Protection

    TEMPERATURE & SAFETY PROTECTION • INTERNAL OVERHEAT PROTECTION: the charger has a built-in overheat and an overload protection. This protects the charger from being damaged if overheated or overloaded and will automatically decrease the charging current. Once the unit’s internal temperature decreases to a safe level, the charger will resume normal charging.
  • Page 5: Charging Instructions

    CHARGING INSTRUCTIONS STEP 1 - Pre charge check & electrolyte level check • Check the Battery Electrolyte levels (Not required on sealed & maintenance free batteries). If necessary, remove the vent caps and add distilled water so the levels are halfway between the upper and lower fill lines. •...
  • Page 6 CHARGING INSTRUCTIONS 1. Qualification - Battery condition check When the charger is first switched on it checks the battery condition to determine whether the battery needs reconditioning. During this qualification process it checks the internal impedance and initial voltage of the battery and it will determine how much charge current, if any that the battery will accept.
  • Page 7: Charging Curve

    CHARGING CURVE Initial Long term Rejuvenation Soft start Bulk charge Absorption Equalization Battery test Float qualification maintenance VOLTAGE CURRENT (Amps) • Initial qualification: test automatically battery condition and determine if chargers engages rejuvenation or charging cycle. • Rejuvenation: rejuvenates sulphated batteries with a high frequency pulse. •...
  • Page 8 ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ ΑΥΤΟ ΤΟ ΕΓΧΕΙΡΙΔΙΟ ΠΕΡΙΕΧΕΙ ΣΗΜΑΝΤΙΚΕΣ ΟΔΗΓΙΕΣ ΑΣΦΑΛΕΙΑΣ ΚΑΙ ΛΕΙΤΟΥΡΓΙΑΣ Συμβατός με μπαταρίες υγρών: AGM, WET, CACIUM, GEL & VRLA ΣΗΜΑΝΤΙΚΕΣ ΣΥΜΒΟΥΛΕΣ ΚΑΙ ΠΡΟΕΙΔΟΠΟΙΗΣΕΙΣ ΑΣΦΑΛΕΙΑΣ • Ο φορτιστής έχει σχεδιαστεί για να φορτίζει και να συντηρεί μπαταρίες 12V AGM & WET, CACIUM και GEL. •...
  • Page 9 θα παρακολουθεί την τάση της μπαταρίας και θα τη διατηρεί στη μέγιστη απόδοση με ειδική παλμική φόρτιση κατά τη μακροχρόνια συντήρηση. • Προστασία από βραχυκύκλωμα και αντίστροφη πολικότητα. • Βύσματα εξόδου βαρέως τύπου, ανθεκτικά στη διάβρωση. • Κροκοδειλάκια: με μοχλό ταχείας σύνδεσης, βαρέως τύπου, πλήρως μονωμένα καλώσια - κροκοδειλάκια •...
  • Page 10: Τεχνικεσ Προδιαγραφεσ

    ΤΕΧΝΙΚΕΣ ΠΡΟΔΙΑΓΡΑΦΕΣ Έξοδος 6A @ 12V Τάση συντήρησης 13.6V Τάση εισόδου 100-240Vac/1.4A (95W) Τάση εκκίνησης Συχνότητα εισόδου 50-60Hz Θερμοκρασία λειτουργίας -15 έως 50°C Τάση φόρτισης Gel - 14.1V Θερμοκρασία αποθήκευσης -25 έως 85°C AGM & WET - 14.4V Λειτουργία σε υγρασία 90% RH Max.
  • Page 11 • Εάν η μπαταρία είναι ακόμα στο όχημα: 1. Απενεργοποιήστε και αφαιρέστε την πρίζα AC από την πρίζα. 2. Αφαιρέστε το καλώδιο από το πλαίσιο του οχήματος. 3. Αφαιρέστε το καλώδιο από την μπαταρία. Σημείωση: ελέγξτε τα επίπεδα ηλεκτρολυτών εάν είναι δυνατόν μετά τη φόρτιση, καθώς μπορεί να χρειαστεί συμπλήρωση με...
  • Page 12 LED STATUS INDICATOR TABLE Κατάσταση Περιγραφή Τύπος μπαταρίας LED's: CACIUM / AGM / WET / GEL Πράσινο Υποδεικνύει ποιος τύπος μπαταρίας έχει επιλεγεί LED ταχύτητας φόρτισης: 1A / 4A / 6A Πράσινο ΟΝ Υποδεικνύει ποιος ρυθμός φόρτισης / λειτουργία φόρτισης έχει επιλεγεί Λυχνίες...
  • Page 13: Αντιμετωπιση Προβληματων

    ΑΝΤΙΜΕΤΩΠΙΣΗ ΠΡΟΒΛΗΜΑΤΩΝ ΠΡΟΒΛΗΜΑ ΕΝΔΕΙΞΗ ΠΙΘΑΝΗ ΑΙΤΙΑ ΠΡΟΤΕΙΝΟΜΕΝΗ ΛΥΣΗ Ο φορτιστής δεν Δεν υπάρχουν Χωρίς ρεύμα AC Check AC connections and make sure the AC Power supply is switched ON λειτουργεί ενδεικτικές Try a different AC Power supply which you know is λυχνίες...
  • Page 14 The Power you need... www.bs-battery.com...
  • Page 15 SMART BATTERY CHARGER 6V/12V - 1A & MAINTAINER For Lead Acid & Lithium Smart battery charger & maintainer • Auto detect Lead Acid or Lithium technology • Adaptable charging algorithm for Lead Acid & Lithium (LiFePO4) • Safe: connection spark free, reverse polarity, short circuit •...
