Installers &
User guide
Keypad.
1
Version 0.2 08/22
EK1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EK1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Igloohome EK1

  • Page 1 Installers & User guide Keypad. Version 0.2 08/22...
  • Page 2 LinkedIn YouTube Instagram We’re always updating our guides because we want to keep things fresh! You can visit igloohome.co/support periodically to view the latest version, unless, this is the latest version. Hello you, igloohomie from the future, wow!
  • Page 3: Table Of Contents

    Table of Contents What’s Included Specifications Keypad Anatomy Features App Onboarding Installation Instructions Installing / Replacing Batteries Modes of access Manage lock features Compatible igloohome Locks Audio and LED Indications Troubleshoot...
  • Page 4: What's Included

    What’s Included Keypad Mounting Plate Torx Screwdriver (with adhesive tape) Torx Screws x2 AA Alkaline Batteries x2 Mounting Screws and Anchors Battery Cover Screw x1...
  • Page 5: Specifications

    Specifications Model Weight Net: 0.1kg, Gross: 0.2kg Material ABS, PC, Silicone Modes of Access (Entry) PIN codes Modes of Access (Exit) N. A Power Type 2 AA alkaline batteries Battery Life Up to 12 months Emergency Power N. A Battery Operating Temp. -10°C to 50°C / 14°F to 122°F Operation Temp.
  • Page 6: Keypad Anatomy

    User Guide Keypad Anatomy Front Back LED Indicator Keypad Buttons Unlock Mounting Plate (with Adhesive Tape) Battery Cover Clear...
  • Page 7: Features

    Features Lock / Unlock Master PIN Code User PIN Code The igloohome mobile app can The Keypad unlocks with a permanent Master PIN Code. generate multiple types of User Pin codes, e.g. One-Time, Permanent, Recurring & Duration. Manual Relock User can press and hold the “unlock”...
  • Page 8 Features Security / Alarms Security Lockout Activity Logs Keypad is disabled after several PIN Code entries will be logged in incorrect access attempts to ensure the app. PIN Code activity logs are your property is always secure. User updated when the Keypad is synced can configure number of incorrect with the app.
  • Page 9: App Onboarding

    App Store Google Play Register for an igloohome account 1) Launch the igloohome app and tap [Create new account] 2) Fill in the fields shown on the screen. 3) Accept the terms of services and privacy policy. 4) Tap [Create account].
  • Page 10 Pairing The Keypad is designed to work with igloohome locks. Please ensure you have paired your locks to your igloohome account before starting the pairing process for your Keypad. a) Create a property to associate your lock with. and select [Add and manage].
  • Page 11: Installation Instructions

    Installation Instructions Remove the Torx screws with the provided Torx screwdriver. Slide the Keypad unit off the mounting plate.
  • Page 12: Installing/ Replacing Batteries

    Installing/ Replacing Batteries Remove the torx screw with the provided Install or replace with 2 new AA alkaline Torx screwdriver and pull out the battery batteries. cover. Battery Cover Put the battery cover back and secure with the screw.
  • Page 13 Peel off the backing of the adhesive on the back of the mounting plate. Side View Exploded View Adhesive Adhesive Tape Adhesive Backing (Release liner) Mounting Plate Mounting Plate Peel...
  • Page 14 Mounting the Keypad Press the mounting plate against the wall/surface where you want to install the Keypad. Ensure the location is within Bluetooth range of the locks you intend to pair it with. *Before mounting, it is recommended that the Keypad is paired and tested with the locks you want to link to, at the desired installation location.
  • Page 15 Slide the Keypad onto the mounting plate. Secure the Keypad to the mounting plate with the Torx screws and Torx screwdriver provided.
  • Page 16: Modes Of Access

    Modes of access Modes of access (Entry) PIN codes Modes of access (Exit) N. A Unlock 1. Key in a valid PIN code (with or without decoy digits), followed by button. LED indicator will start flashing blue. 2. Paired lock(s) within Bluetooth range (up to 5) will unlock, and LED Indicator will turn green with 4 short ascending tones.
  • Page 17 Lock 1. Press and hold the button on the Keypad until LED Indicator starts flashing blue. 2. Paired lock(s) within Bluetooth range (up to 5) will lock once the LED Indicator turns green with a single beep.
  • Page 18: Manage Lock Features

    *Please ensure you are within Bluetooth range of the lock and your Bluetooth function is turned on. 1. On your igloohome app, tap on 2. Select [Security Lockout]. 3. Select the number of attempts from 1 to 10, or choose to deactivate this function completely.
  • Page 19: Compatible Igloohome Locks

    Compatible igloohome Locks Lock Maximum Keypad to lock distance* Retrofit Lock Less than 30m Deadbolt 2S Metal Grey Less than 30m Keybox 3 Less than 8m Mortise 2/2+ Less than 10m Push-Pull Mortise Less than 30m Rim Lock for Metal Gates...
  • Page 20: Audio And Led Indications

    Audio and LED Indications Actions Indications Bluetooth Connection LED Indicator flashes Blue Successfully unlock/ Ascending 4 fast tones lock all paired locks and flash Green LED 2 times Unsuccessful Descending 4 short tones unlock/lock of all and solid Red LED for 4 seconds paired locks / Error Incorrect PIN Code 4 short beeps and flash Red LED 2 times...
  • Page 21: Troubleshoot

    Troubleshoot Paired locks are not unlocking when valid PIN Code is used • Check that the locks you are unlocking are linked to the Keypad in the app. • Ensure Keypad is within Bluetooth range of the locks with minimal obstruction between devices.
  • Page 22 Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 23 For enquiries go to: igloohome.co/support...
